4. Insert the turntable platter onto the center spindle.
5. Set the turntable mat on the platter.
6. Installing the cartridge: When installing a cartridge,
refer to the operating instructions of that cartridge.
During installation, attach the stylus protector to guard
the stylus tip from damage.
If you have purchased a unit with the cartridge included, then that cartridge is already installed on the
headshell (You may skip to line 8).
a. Connect the lead wires to the cartridge terminals. The terminals of most cartridges are color coded.
Connect each lead wire to the terminal of the same color.
b. Install the cartridge to the headshell and tighten it with screws provided with the cartridge.
7. Insert the headshell into the front end of the tonearm, then turn the locking nut clockwise with the head
shell firmly held horizontally.
8. Slide counterweight onto the rear of the tonearm. Twist it lightly and it will screw onto the rear shaft of the
tonearm.
©2000

Industries

White (L+)
Blue (L-)
Red (R+)
Green (R-)
Tonearm
CENTER SPINDLE
Left channel+
Left channel
Right channel+
Right channel
- The Leader in DJ Technology
- 5 -
Counterweight
