Lenovo ThinkPad P50 Hardware Maintenance Manual page 97

• "1020 Bottom cover" on page 66
• "1030 Storage drive" on page 66
• "1060 Keyboard" on page 73
• "1100 Keyboard bezel assembly" on page 81
• "1120 Hinge caps" on page 86
• "1130 LCD unit" on page 87
• "1140 Chassis assembly " on page 89
Removal steps of the smart card reader and smart card reader cable
When installing:
Ensure that the connector is attached firmly.
Step Screw (quantity)
3
M2 × 3 mm, flat-head, nylon-coated (2)
Removal steps of the dummy smart card reader
If the computer you are servicing has a dummy smart card reader installed. Follow the following instructions
to remove or replace the dummy smart card reader.
2
11
1
Chapter 9
Torque
Color
Black 0.181 Nm
(1.85 kgf-cm)
.
Removing or replacing a FRU
91
