Tray for NVMe solid-state drives
• Ensure that you follow the identification mark on the tray to insert the M.2 solid-state drives.
• If you want to replace the hard disk drive with M.2 solid-state drive, ensure that you remove the sponges
from the hard disk drive slot

1040 Memory module under the bottom cover

For access, remove these FRUs:
• "1010 Battery" on page 65
• "1020 Bottom cover" on page 66
Tray for SATA solid-state drives
first. Then, install the M.2 solid-state drive.
.
Chapter 9 Removing or replacing a FRU
71
