Led States - Novatel Merlin XU870 User Manual

LED Color
RED
GREEN
VIOLET
BLUE
YELLOW
*
The LED may appear to flash blue and then yellow as the service transitions from UMTS
to HSDPA and then back again.
LED State
SIM Error
No Service
GPRS
EDGE
UMTS
HSDPA

LED States

Description
Flashing: SIM card may be missing
or inserted incorrectly.
Solid: GPRS/EDGE/UMTS/HSDPA
cellular service is currently
not available.
Flashing: GPRS service is available.
Solid: Connected to a network
using GPRS.
Flashing: EDGE service is available.
Solid: Connected to a network
using EDGE.
Flashing: UMTS service is available.
Solid:* Connected to a network
using UMTS.
Solid:* HSDPA service is available
and is being used during
the download.
47
