Section 1 Specifications - Icom IC-2725E Service Manual

SECTION 1
M
GENERAL
• Frequency range
VERSION
[EUR]
[ITR]
• Mode
• Nomber of memory channel
• Usable temperature range
• Frequency resolution
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC)
• Antenna connector
• DATA connector
• Dimensions
(projections not included)
• Weight
M
TRANSMITTER
• Output power
• Modulation system
• Maximum frequency deviation : ±5.0 kHz
• Spurious emissions
• Microphone connector
M
RECEIVER
• Receive system
• Intermediate frequency
(Left/right side band)
• Sensitivity
• Squelch sensitivity
• Selectivity
(wide/narrow)
• Spurious and image rejection : More than 60 dB
• Audio output power
(at 13.8 V)
• External speaker connector
All stated specifications are subject to change without notice or obligation.
SPECIFICATIONS
:
RX (MHz)
144.000–146.000, 430.000–440.000
144.000–146.000
430.000–434.000, 435.000–438.000
: FM, AM (AM range is 118.0 – 135.995 MHz and Rx only for [USA] and [EXP].)
: 212 (including 2 call channels and 10 scan edges)
: –10˚C to +60˚C; +14˚F to +140˚F
: 5, 10, 12.5, 15, 20, 25, 30 and 50 kHz
: ±10 ppm (–10˚C to +60˚C; +14˚F to +140˚F)
: 13.8 V DC ±15 % (negative ground)
: Receive Standby (squelched)
Max. audio output
Transmit at VHF 50 W/UHF 35 W
: SO-239 (50 Ω)
: Mini DIN 6 pin
: Controller 140(W)×50(H)×27(D) mm; 5
Main unit 140(W)×40(H)×187(D) mm; 5
: Controller 150 g; 5.29 oz
Main unit 1.4 kg; 3.0 lb
: VHF 50 W/25 W/5 W (selectable)
UHF 35 W/25 W/5 W (selectable)
: Variable reactance frequency
: Less than –60 dB
: 8-pin modular jack (600 Ω)
: Double-conversion superheterodyne
: 1st IF 38.85 MHz/46.05 MHz
2nd IF 450 kHz/455 kHz
: Less than 0.18 µV (at 12 dB SINAD)
: Less than 0.13 µV (at threshold)
: More than 12 kHz/–6 dB
Less than 30 kHz/ –60 dB
: More than 2.4 W at 10% distortion with an 8 Ω load
: 2-conductor 3.5(d) mm (
TX (MHz)
144.000–146.000, 430.000–440.000
144.000–146.000
430.000–434.000, 435.000–438.000
1.2 A
1.8 A
12.0 A/11.0 A
1 31
⁄ (W)×1 ⁄
2 32
1 9
⁄ (W)×1 ⁄
2 16
")/8 Ω
1
⁄
8
1 - 1
1
(H)×1 ⁄ (D) inch
16
3
(H)×7 ⁄ (D) inch
8
