- Page 1 3MP IR Bullet Camera (4mm) NVC-BM1 Quick Guide V1.3...
-
Page 2: Table Of Contents
Quick Guide Bullet Camera Table of Contents Overview ......................3 Installation ......................5 Setup using Hills’ NVR ..................8 Setup using remote software ................9 Specifications ....................13... -
Page 3: Overview
Quick Guide Bullet Camera Overview Figure 1-1 Bullet camera overview Table 1-1 Description Description Adjustable Bracket Back Box Front Box Lens Sun Shield Power & Network cable Grounding Screw Reset... - Page 4 Quick Guide Bullet Camera Table 1-2 Carton contents Camera Quick Guide Drill template Mounting hardware 3x Expansion screws...
-
Page 5: Installation
Quick Guide Bullet Camera Installation Checklist before you start All carton contents present and are in good conditions. Ensure power supplies are off during installation. Power supply voltage rating as specified in product specifications. Installation environment is as specified. ... - Page 6 Quick Guide Bullet Camera Steps: Attach the drill template on the wall. Ceiling Mounting Hole Hole Hole Figure 2-1 Attach the template Secure the camera to the ceiling with the supplied expansion mounting. Figure 2-2 Secure the camera to the ceiling...
- Page 7 Quick Guide Bullet Camera Adjust the field of view Loosen the adjustable nut on the bracket. Adjust the panning angle [0~360°] of the camera. Adjust the tilting angle [0~90°] of the camera. Rotate 0~360° to adjust angle of the image. Tighten the adjustable nut to complete the installation.
-
Page 8: Setup Using Hills' Nvr
Setup using Hills’ NVR Setup using Hills’ NVR The Hills Video Security IP cameras (NVC-MB1, NVC-DM1, NVC-DT1 and NVC-DF1) have a pre-loaded protocol that works immediately with Hills Video Security NVRs (NVR-CH4, NVR-CH8 and NVR-CH16) as soon as they are connected. -
Page 9: Setup Using Remote Software
Quick Guide Bullet Camera Setup using remote software etup using remote software To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then install the PC client software to search and change the IP address of the network camera. - Page 10 Quick Guide Bullet Camera It displays the total number and information of the searched devices in the Online Devices interface. Go to Device Management, and click Server tab on the top-left of the window, and you can see the online devices listed on the bottom right of the window.
- Page 11 Quick Guide Bullet Camera Edit the modifiable network parameters, e.g. IP address and port number. Enter the admin password in the Manager Password field and click to save the changes. Figure 4-3 Modify network parameters Note: ● By default DHCP is enabled. Camera will search for DHCP server for a duration of 30 seconds.
- Page 12 Quick Guide Bullet Camera ● For accessing the network camera from different subnets, please set the gateway for the network camera after you log in.
-
Page 13: Specifications
Quick Guide Bullet Camera Specifications Specification Camera Image Sensor 1/3" Progressive Scan CMOS 0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR Min. Illumination Shutter Speed 1/3 s to 1/100,000 s 4mm@ F2.0 2048 × 1536: Lens Angle of view: 70° 1920 ×... - Page 14 Quick Guide Bullet Camera Image Max. Resolution 2048×1536 50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × Frame Rate 720) Rotate mode, Saturation, Brightness, Contrast adjustable by Image Settings client software or web browser Backlight Yes, zone optional compensation Support Network...
- Page 15 Ingress Protection IP66 level IR Range Approx. 20 to 30 meters Dimensions 60.4×76.9×139.28 mm (2.4” × 3.0” × 5.5”) Weight 500g (1.1 lbs) Part No. S47090 For further information, including full user and installation manual, and technical support please visit: www.hills.com.au/videosecurity...
