This Blue Coat Quick Start Guide describes how to rack-mount the Blue Coat AV210 and explains the initial
configuration methods.
1. Unpack the Blue Coat Appliance
The Blue Coat AV210 is shipped with the following components:
• Blue Coat AV210 appliance
• Side rack-mounting kit
• Packet: Software license sticker
card/software license
agreement
2. Record the Setup Information
For initial configuration, you must have the following information:
❐
IP address, subnet mask, gateway, and DNS server to be assigned
❐
Administration access names and passwords to be assigned to this Blue Coat AV210 appliance
3. Power Up the Blue Coat Appliance
There is no power switch on the Blue Coat AV210. Plug the power adapter into the DC IN socket on the
rear of the appliance.
The Blue Coat AV210 takes approximately two minutes to boot up. During that time, the Power LED
glows solid amber. After boot up, the LED flashes amber and green, indicating the Blue Coat AV210 is
ready for initial configuration.
Document Number: 231-03007 Rev E.0 06/09
AV210 Quick Start Guide
• AC power cord
• Wall mount bracket and screws • Skid-proof rubber pads (4)
• Serial cable
Power LED
• AC power adapter
• Packet: Safety/Conformity
1
