310-e.book Page i Tuesday, October 27, 1998 5:17 PM
Copyright © 1998 Acer Incorporated
All Rights Reserved — Printed in Taiwan
TravelMate 310 Series Notebook Computer User's Guide
Part No. 49.42B01.011
Original Issue: June 1998
Changes may be made periodically to the information in this
publication. Such changes will be incorporated in new editions of
this manual.
Record the serial number, purchase date, and model number in the
space provided below. The serial number and model number are
recorded on the label affixed to the case. All correspondence
concerning your unit should include the serial number, model
number, and date of purchase.
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic,
mechanical, photocopy, recording, or otherwise, without the prior
written permission of Acer Incorporated.
TravelMate Notebook Computer
Model___________Serial No.____________Purchase Date_______________
TravelMate is a trademark and a product of Acer Inc., developed with Texas
Instruments Inc. All other trademarks and registered trademarks are the
property of their respective companies. Microsoft, MS-DOS, and Windows are
registered trademarks of Microsoft Corporation.
