  • Page 1 A I R 1 ADIO IXING ONSOLE ECHNICAL ANUAL December 2007...
  • Page 2 AIR 1 Radio Mixing Console Technical Manual - 1st Edition AIR 1 Radio Mixing Console Technical Manual - 1st Edition AIR 1 Radio Mixing Console Technical Manual - 1st Edition AIR 1 Radio Mixing Console Technical Manual - 1st Edition AIR 1 Radio Mixing Console Technical Manual - 1st Edition ®...

  • Page 3: Table Of Contents

    Program Outputs ...................... 2-5 Monitor Output ......................2-5 Cue to Monitor ..................... 2-5 Split Cue, Monitor ....................2-6 Split Cue, Headphone ..................2-6 Monitor Mute ......................2-6 On Air Tally ......................2-7 page Contents – 1 AIR 1 / Dec 2007...
  • Page 4 Load Sheet ......................4-11 VUA1-2 Meters PCB Schematic ......................4-12 Load Sheet ......................4-13 Appendices Appendix 1 AIR 1 Console Performance Specifications ......A-3 Appendix 2 Replacement Parts List ............. A-5 page Contents – 2 AIR 1 / Dec 2007...
  • Page 5 LINE 3 IN through LINE 8 IN .................. 1-5 EXT IN ........................1-6 PGM 1 OUT and PGM 2 OUT ................1-6 MONITOR OUT ...................... 1-6 CUE ........................1-6 HDPN ........................1-6 TALLY ........................1-7 SPARE ........................1-7 page 1 – 1 AIR 1 / Dec 2007...

  • Page 6: Unpacking And Installing The Console

    I N S T A L L A T I O N a n d P O W E R Installation and Power Unpacking and Installing the Console The AIR 1 console with its power supply, connecting cable, and technical manual is shipped in one packing box. The console can be NOTE: This console...

  • Page 7: Power Supply

    Energizing Assuming the AIR 1 console mainframe is properly placed, and its power supply correctly connected to the console, you may now energize the power supply adapter by plugging it into the AC mains. The console's switches will assume factory default settings.

  • Page 8: Audio And Control Wiring

    I N S T A L L A T I O N a n d P O W E R Audio and Control Wiring All audio I/O connections to the AIR 1 console are made via TRS and XLR connectors located on the rear panel of the console.

  • Page 9: Unbalanced Connections (Analog Audio)

    (like Belden 9451), just as if you were connecting a balanced source. At the unbalanced source machine’s output, connect the black wire (LO) to the shield. ANALOG OUTPUTS — The AIR 1 console’s PGM 1 and PGM 2 line level analog outputs are electronically balanced, low impedance, outputs, expecting a minimum load of 600 ohms.

  • Page 10: Ext In

    TRS TIP – CUE HI TRS RING – GROUND TRS SLEEVE – CUE SH HDPN Analog stereo, headphone level, unbalanced. TRS TIP – HDPN LEFT TRS RING – HDPN RIGHT TRS SLEEVE – HDPN SH page 1 – 6 AIR 1 / Dec 2007...

  • Page 11: Tally

    TRS TIP – TALLY N.O. TRS RING – TALLY COM TRS SLEEVE – GROUND SPARE Not used. TRS TIP – NO CONNECTION TRS RING – NO CONNECTION TRS SLEEVE – GROUND page 1 – 7 AIR 1 / Dec 2007...
  • Page 12 Program Outputs ....................2-5 Monitor Output ......................2-5 Cue to Monitor ....................2-5 Split Cue, Monitor ....................2-6 Split Cue, Headphone ..................2-6 Monitor Mute ...................... 2-6 On Air Tally ......................2-7 page 2 – 1 AIR 1 / Dec 2007...

  • Page 13: Overview

    Console Features Overview The AIR 1 console consists of an input section with eight faders and associated switches, monitor and headphone section with two faders and associated switches. The basic purpose of the console is to take some of the many audio signals that are wired to the console inputs, and generate several outputs that combine these inputs in various groups and at various degrees of loudness, or signal strength.
  • Page 14 C O N S O L E F E A T U R E S AIR 1 Bottom Panel page 2 – 3 AIR 1 / Dec 2007...

  • Page 15: Inputs

    C O N S O L E F E A T U R E S Inputs The AIR 1 console is designed to handle 6 analog stereo (+4dBu balanced) inputs, two mono microphone (-50dBu balanced) inputs, and one external stereo line level (+4dBu balanced) input that goes directly to control room or meter.

  • Page 16: Outputs

    When SW 11 is DOWN the PGM 2 is in stereo mode. Monitor Output The AIR 1 has a MONITOR output designed to drive a stereo pair of powered speakers, or a stereo amplifier driving separate speakers, to allow the operator to listen to either PGM 1 or PGM 2, or an external signal.

  • Page 17: Split Cue, Monitor

    ON AIR LED in the center of the meterbridge is also turned on, and a closure is provided at the TALLY output to activate the external circuitry for the ON AIR indicator. page 2 – 6 AIR 1 / Dec 2007...

  • Page 18: On Air Tally

    USER-SUPPLIED RELAY TRIGGERED BY CONSOLE MONITOR MUTE CIRCUIT INTERNAL AIR "TALLY" TRS TALLY RELAY CONNECTOR PIN YOUR B40240 1N4002 POWER N.C. or equiv. SUPPLY relay 30VDC – N.O. – RELAY CIRCUIT POWERED BY USER SUPPLIED EXTERNAL SUPPLY page 2 – 7 AIR 1 / Dec 2007...
  • Page 19 Monitor Fader ....................3-5 Cue Level Control ....................3-6 Headphone Fader ....................3-6 Meters ........................3-6 VU Meter Pair ....................3-6 Meter Select Buttons ..................3-7 On Air LED ......................3-7 page 3 – 1 AIR 1 / Dec 2007...

  • Page 20: Input Section

    C O N T R O L S A N D F U N C T I O N S Controls and Functions Input Section The AIR 1 Input section consist of two mono microphone input channels and six stereo analog input channels. The MIC and LINE input channels have the same controls, except that the MIC channels don’t have a CUE switch.

  • Page 21: Source

    C O N T R O L S A N D F U N C T I O N S Source The AIR 1 console accepts two mono mic input signals via female XLR and six stereo line level input signals via TRS connectors.

  • Page 22: Master Section

    C O N T R O L S A N D F U N C T I O N S Master Section The Master section includes the monitor, headphone, and meters controls. page 3 – 4 AIR 1 / Dec 2007...

  • Page 23: Monitor

    NOTE: If the Monitor is muted and you slide the fader all the way up, then remove the condition that has the Monitor muted, the sound in the Monitor speakers will suddenly be VERY LOUD! page 3 – 5 AIR 1 / Dec 2007...

  • Page 24: Cue Level Control

    The more elements lighted, the stronger is the signal being displayed. The right two LEDs in each bargraph are red to indicate when the signal level is approaching a clipping (distorted) level. The next two LEDs page 3 – 6 AIR 1 / Dec 2007...

  • Page 25: Meter Select Buttons

    The ON AIR LED, located in the middle of the meterbridge, lights up when either of the two MIC channels is programmed by slide switch to have the MONITOR MUTE activated, and is also ON. page 3 – 7 AIR 1 / Dec 2007...

  • Page 26: Mba1-1 Mother Board

    Schematic and Load Sheet Drawings Chapter Contents Console Flow Diagram ..............4-2 MBA1-1 Mother Board Schematic ......................... 4-3 Load Sheet ....................... 4-11 VUA1-2 Meters PCB Schematic ........................ 4-12 Load Sheet ....................... 4-13 page 4 – 1 AIR 1 / Dec 2007...
  • Page 27 1/4" RTS PGM 2 LT MONITOR AIR 1 PGM 2 LT OUT System Flow Diagram SLIDE SW PGM 2 ACN PGM 2 RT MONITOR PGM 2 RT OUT 1/4" RTS PROGRAM page 4 - 2 AIR 1 / Dec 2007...
  • Page 28 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 22S1001-1 W# 700928 MBA1-1 PCB 1 OF 8 SCALE SHEET page 4 - 3 AIR 1/ Dec 2007...
  • Page 29 DATE DRAWN 0.1uF 0.1uF 0.1uF 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED AGND AGND ISSUED SIZE FSCM NO. DWG. NO. 22S1001-2 W# 700928 MBA1-1 PCB 2 OF 8 SCALE SHEET page 4 - 4 AIR 1/ Dec 2007...
  • Page 30 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF ISSUED SIZE FSCM NO. DWG. NO. 22S1001-3 W# 700928 MBA1-1 PCB 3 OF 8 SCALE SHEET page 4 - 5 AIR 1/ Dec 2007...
  • Page 31 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY DRAWN IN PHASE OUT OF PHASE 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 22S1001-4 W# 700928 MBA1-1 PCB 4 OF 8 SCALE SHEET page 4 - 6 AIR 1/ Dec 2007...
  • Page 32 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY DRAWN IN PHASE OUT OF PHASE 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 22S1001-5 W# 700928 MBA1-1 PCB 5 OF 8 SCALE SHEET page 4 - 7 AIR 1/ Dec 2007...
  • Page 33 DATE AGND AGND GND AGND +6dB DRAWN 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 22S1001-6 W# 700928 MBA1-1 PCB 6 OF 8 SCALE SHEET page 4 - 8 AIR 1/ Dec 2007...
  • Page 34 -2dBu 22uF C214 PGM1LTMON R306 10.0K R310 4.99K R277 47 PGM1_LT_HI C216 33pF -2dBu C235 33pF R304 4.99K R168 6.19K -2dBu C221 33pF PGM1LTACN 22uF C223 R311 10.0K R194 R239 5532 -2dBu R314 10 R300 4.99K 3.92K 3.32K 5532 C144 33pF GAIN R305 10...
  • Page 35 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY DRAWN IN PHASE OUT OF PHASE 10-20-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 22S1001-8 W# 700928 MBA1-1 PCB 8 OF 8 SCALE SHEET page 4 - 10 AIR 1/ Dec 2007...
  • Page 36 Mother Board Load Sheet page 4 – 11 AIR 1 / Dec 2007...
  • Page 37 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 600 Industrial Drive 9-19-07 New Bern, NC 28562 CHECKED SIZE FSCM NO. DWG. NO. 22S1002 ISSUED W# 700929 SCALE VUA1-2 PCB SHEET 1 OF 1 page 4 - 12 AIR 1 / Dec 2007...
  • Page 38 S C H E M A T I C D R A W I N G S Meters PCB Load Sheet page 4 – 13 page 4 – 2 AIR 1 / Dec 2007...

  • Page 39: Appendices

    A P P E N D I C E S Appendices Appendix 1 AIR 1 Console Performance Specifications ......A-3 Appendix 2 Replacement Parts List ............... A-5 page Appendix – 1 AIR 1 / Dec 2007...

  • Page 40: Appendix 1

    A P P E N D I C E S Appendix 1 Contents AIR 1 Performance Specifications ..........A-3 page Appendix – 2 AIR 1 / Dec 2007...
  • Page 41 11.511” Height (rear) 2.442” Line, +24dBu <0.002% Height (front) 1.283” <0.006% MAXIMUM INPUT Line +28dBu Mic, minimum trim -4dBu MAXIMUM OUTPUT Line +28dBu Specifications and features subject to change without notice. page Appendix – 3 AIR 1 / Dec 2007...

  • Page 42: Replacement Parts List

    Replacement Parts List ............... A-5 For the most part there are no user-replaceable parts in the AIR 1 console. Exceptions are those controls and components that in the course of normal use may need maintenance (i.e., faders, pots, ON switches, etc.). A complete list of available components is shown on the next page.
  • Page 43 A P P E N D I C E S REPLACEMENT PARTS — AIR 1 CONSOLE COMPONENT DESCRIPTION WS P/N MB-A1 LOADED CARD ASSY MOTHERBOARD LOADED CARD ASSEMBLY "009714" VU-A1 LOADED CARD ASSY VU METERS LOADED CARD ASSEMBLY "009715" FADER 100MM LOW PROFILE MASTER TYPE N FADER ROHS COMPLIANT "540061"...
