PQQX14045ZA.book 1 ページ ２００４年２月１９日　木曜日　午後３時４７分
2.4 GHz Digital Cordless Phone

Operating Instructions

KX-TG2313C
Model No.
Pulse-or-tone dialing capability
The unit is Call Display compatible. To display the caller's name and phone number,
you must subscribe to Call Display service.
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for 6 hours before initial use.
For assistance, please call 1-800-561-5505 or visit us at www.panasonic.ca

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TG2313C

Summary of Contents for Panasonic KX-TG2313C

  • Page 1: Operating Instructions

    The unit is Call Display compatible. To display the caller’s name and phone number, you must subscribe to Call Display service. PLEASE READ BEFORE USE AND SAVE. Charge the battery for 6 hours before initial use. For assistance, please call 1-800-561-5505 or visit us at www.panasonic.ca...
  • Page 2 PQQX14045ZA.book 2 ページ ２００４年２月１９日　木曜日　午後３時４７分 Thank you for purchasing your new Panasonic cordless telephone. Call Display, Call Waiting and Voice Mail service, where available, are telephone company services. After subscribing to Call Display this phone will display a caller’s name and phone number. Visual Call Waiting/Call Waiting Deluxe, which displays a second caller’s name and phone number while the user is on another...

  • Page 3: For Best Performance

    PQQX14045ZA.book 3 ページ ２００４年２月１９日　木曜日　午後３時４７分 For Best Performance Battery Charge The handset is powered by a rechargeable Nickel- Metal Hydride (Ni-MH) battery. Charge the battery for 6 hours before initial use (p. 9). Base Unit Location/Noise Calls are transmitted between the base unit and handset using wireless radio waves.

  • Page 4: Table Of Contents

    PQQX14045ZA.book 4 ページ ２００４年２月１９日　木曜日　午後３時４７分 Contents Preparation Advanced Operation Location of Controls ..6 Phone Book ....28 Storing Names and Installation ....8 Numbers .
  • Page 5 PQQX14045ZA.book 5 ページ ２００４年２月１９日　木曜日　午後３時４７分 Contents Useful Information Wall Mounting ... . 43 Belt Clip ....44 Shoulder Rest Attachment .

  • Page 6: Location Of Controls

    PQQX14045ZA.book 6 ページ ２００４年２月１９日　木曜日　午後３時４７分 Location of Controls Base unit Antenna (p. 3) Charge Contacts (p. 10) IN USE Indicator (p. 21) CHARGE Indicator (p. 9) [HANDSET LOCATOR] Button (p. 36) Handset Ringer/Message Alert Back side Indicator (p. 17, 21) Antenna Speaker Receiver Soft Keys (p.
  • Page 7 PQQX14045ZA.book 7 ページ ２００４年２月１９日　木曜日　午後３時４７分 Location of Controls Handset soft keys Two soft keys are used to select functions displayed directly above each key. Functions displayed above the Talk 00-00-32 keys will change depending on the state of use. (VE) Mute On this sample display, “...

  • Page 8: Installation

    Power Outlet (AC 120 V, 60 Hz) AC Adaptor • USE ONLY WITH Panasonic AC ADAPTOR PQLV1. • The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) • If your unit is connected to a PBX which does not support Call Display and voice mail services, you cannot access those services.

  • Page 9: Installing The Battery In The Handset

    PQQX14045ZA.book 9 ページ ２００４年２月１９日　木曜日　午後３時４７分 Installation Installing the Battery in the Handset Insert the battery ( ), and press it down until it snaps into the compartment ( Close the cover. To replace the battery: Press the notch on the cover firmly and slide it as indicated by the arrow.

  • Page 10: Battery Replacement

    “Recharge battery” is displayed and/or “7” continues to flash, or “Charge for 6h” and “8” are displayed, the battery may need to be replaced. Please replace with a new Panasonic HHR-P104 battery. To replace the battery, see page 9.

  • Page 11: Programmable Settings

    PQQX14045ZA.book 11 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Programming Guidelines Handset This unit has several programmable functions which can be selected from the function menu on the display (p. 12). The soft keys selects the Back Select functions displayed above each soft key. [OFF] exits programming.

  • Page 12: Function Menu Table

    PQQX14045ZA.book 12 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Function Menu Table Handset You can use the following functions to customize your unit. See the corresponding pages for function details. • After pressing [MENU], you can also program menu items directly by pressing ([0] to [9], and [#]) instead of using the soft keys (p.

  • Page 13: Display Language

    PQQX14045ZA.book 13 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Display Language Handset You can select either “English” or “Français” (French) as the display language. The factory preset is “English”. Press [MENU]. Scroll to “Initial setting” by pressing [d] Initial setting or [B], then press Select. Back Select Scroll to “Change language”...

  • Page 14: Line Mode

    PQQX14045ZA.book 14 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Line Mode Handset The line mode is preset to “B” and generally should not be adjusted. If “Line in use” is not displayed on the handset properly, the line mode selection is incorrect. Set line mode to “A”. Press [MENU].

  • Page 15: Ringer Volume

    PQQX14045ZA.book 15 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Ringer Volume Handset You can select the handset ringer volume to high, medium, low, or off. The factory preset is HIGH. If the handset ringer is turned off, the handset will not ring. Press [MENU]. Scroll to “Ringer setting”...

  • Page 16: Ringer Tone

    PQQX14045ZA.book 16 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings Ringer Tone Handset You can set the handset ringer to use one of 7 ringer patterns for outside calls. “Tone 1” to “Tone 3” are bell ringer patterns. “Melody 1” to “Melody 4” are melody patterns.

  • Page 17: Lcd Contrast

    PQQX14045ZA.book 17 ページ ２００４年２月１９日　木曜日　午後３時４７分 Programmable Settings LCD Contrast Handset There are 6 levels of LCD contrast. The factory preset is “level 3”. Press [MENU]. Scroll to “Initial setting” by pressing [d] Initial setting or [B], then press Select. Back Select Scroll to “LCD contrast”...

  • Page 18: Making Calls

    PQQX14045ZA.book 18 ページ ２００４年２月１９日　木曜日　午後３時４７分 Making Calls Press [C]. • “Talk” is displayed. Display Dial a phone number. Soft Keys [OFF] • The dialed number is displayed. • After a few seconds, the display will show the length of the call. To hang up, press [OFF] or place the handset on the base unit.

  • Page 19: To Redial The Last Number

    PQQX14045ZA.book 19 ページ ２００４年２月１９日　木曜日　午後３時４７分 Making Calls To dial after confirming the To redial using the redial entered number list (Memory Redial) The last 5 phone numbers dialed are Enter a phone number. stored in the redial list. 3334444| Press [REDIAL]. Clear Pause •...

  • Page 20: Voice Enhancer Technology

    PQQX14045ZA.book 20 ページ ２００４年２月１９日　木曜日　午後３時４７分 Making Calls Voice Enhancer Technology Panasonic’s Voice Enhancer Technology clarifies the voice of the person you are talking to, reproducing a more natural-sounding voice that is easier to hear and understand. Voice Enhancer Technology can be turned on or off. The factory preset is OFF.

  • Page 21: Answering Calls

    PQQX14045ZA.book 21 ページ ２００４年２月１９日　木曜日　午後３時４７分 Answering Calls When a call is received, the unit rings, “Incoming call” is displayed, and the Ringer/Message Alert indicator on the handset and the IN USE indicator on the base unit flash rapidly. If you subscribe to a Call Display service, see page 22. Ringer/Message Alert Press [C] or [s].

  • Page 22: Call Display Service

    PQQX14045ZA.book 22 ページ ２００４年２月１９日　木曜日　午後３時４７分 Call Display Service This unit is compatible with Call Display services offered by your telephone company. If you subscribe to Call Display service, caller names and phone numbers will be displayed and recorded in the Caller List. How caller information is displayed When a call comes in, the unit will ring and the caller Example...

  • Page 23: Using The Caller List

    PQQX14045ZA.book 23 ページ ２００４年２月１９日　木曜日　午後３時４７分 Using the Caller List The unit can record information for up to 30 different callers and store this information in the Caller List. Caller information is sorted by the most recent call to the oldest. When the 31 call is received, the information from the 1 call is deleted.

  • Page 24: Calling Back From The Caller List

    PQQX14045ZA.book 24 ページ ２００４年２月１９日　木曜日　午後３時４７分 Using the Caller List What “,” means “,” indicates that you have already viewed this calling SMITH,JACK information or answered the call. If the same caller calls 3:10P JUN.29 , again, the call entry with the “,” will be replaced with the new call entry.

  • Page 25: Editing The Caller's Phone Number

    PQQX14045ZA.book 25 ページ ２００４年２月１９日　木曜日　午後３時４７分 Using the Caller List Editing the Caller’s Phone Number Handset You can edit a phone number in the Caller List by adding the long distance code “1” or removing its area code. Press Rcvd calls, [ ], or [ ] to enter the Caller List.

  • Page 26: Storing Caller Information In The Phone Book

    PQQX14045ZA.book 26 ページ ２００４年２月１９日　木曜日　午後３時４７分 Using the Caller List Storing Caller Information in the Phone Book Handset Caller names and phone numbers that are in the Caller List can be stored in the phone book. Press Rcvd calls, [ ], or [ ] to enter the 2 missed calls Caller List.

  • Page 27: Erasing Caller Information

    PQQX14045ZA.book 27 ページ ２００４年２月１９日　木曜日　午後３時４７分 Using the Caller List Erasing Caller Information Handset To erase a specific caller Press Rcvd calls, [ ], or [ ] to enter the 2 missed calls Caller List. Rcvd Phone calls book 2 missed calls =Scroll list All erase Scroll to the desired caller by pressing [...

  • Page 28: Phone Book

    PQQX14045ZA.book 28 ページ ２００４年２月１９日　木曜日　午後３時４７分 Phone Book The handset can store up to 30 names and phone numbers in its phone book. You can make a call by selecting a name or number from the phone book. Storing Names and Numbers Handset Press Phone book.

  • Page 29: Selecting Characters To Enter Names

    PQQX14045ZA.book 29 ページ ２００４年２月１９日　木曜日　午後３時４７分 Phone Book Selecting characters to enter names Enter names using the dialing buttons. Press each button until the desired character is displayed. • Pressing each button selects a character in the order shown below. Characters Characters Keys Keys # &...

  • Page 30: Dialing From The Phone Book

    PQQX14045ZA.book 30 ページ ２００４年２月１９日　木曜日　午後３時４７分 Phone Book Dialing from the Phone Book Handset Press Phone book. Press Search. Phone book 7 items Search Scroll to the desired item. To scroll down, 0-9=Name search press [ ]. To scroll up, press [ =Scroll list Phone book items are sorted in the following order: Alphabet letters (Alphabetical)

  • Page 31: Chain Dial

    PQQX14045ZA.book 31 ページ ２００４年２月１９日　木曜日　午後３時４７分 Phone Book Index table Keys Index Keys Index Symbols, 1 M, N, O, 6 A, B, C, 2 P, Q, R, S, 7 D, E, F, 3 T, U, V, 8 G, H, I, 4 W, X, Y, Z, 9 J, K, L, 5 0, Space Chain Dial...

  • Page 32: Editing An Item In The Phone Book

    PQQX14045ZA.book 32 ページ ２００４年２月１９日　木曜日　午後３時４７分 Phone Book Editing an Item in the Phone Book Handset Press Phone book. Press Search. Scroll to the desired item by pressing [ ] or Jane ], then press Edit. 345-6789 Erase Edit • To search for the item by initial, see page 30. Edit the name (p.

  • Page 33: Voice Mail Service

    PQQX14045ZA.book 33 ページ ２００４年２月１９日　木曜日　午後３時４７分 Voice Mail Service Voice mail is an automatic answering service offered by your telephone company. If you subscribe to this service, your telephone company’s voice mail system can answer calls for you when you are unavailable to answer the phone or when your line is busy.

  • Page 34: Setting Voice Mail (Vm) Tone Detection

    — your phone is connected to a business or office telephone system (PBX). See below to turn this setting on. If you are not sure which setting is required, consult your local telephone company or contact the Panasonic Customer Call Centre. Press [MENU]. Scroll to “Initial setting” by pressing [d] Initial setting or [B], then press Select.

  • Page 35: Listening To Voice Mail Messages

    PQQX14045ZA.book 35 ページ ２００４年２月１９日　木曜日　午後３時４７分 Voice Mail Service Listening to Voice Mail Messages Handset The unit will let you know that someone has left new voice mail for you: a) “Voice Mail” will be displayed on the handset, and b) the Ringer/Message Alert indicator on the handset will flash slowly if Message Alert is turned on (p.

  • Page 36: Special Features

    PQQX14045ZA.book 36 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features Handset Locator Base Unit You can locate the handset or page the handset user with beep tones from the base unit. Press [HANDSET LOCATOR]. • The IN USE indicator flashes rapidly. • The paged handset beeps for 1 minute and displays “Call from Base”. To stop paging, Base unit: Press [HANDSET LOCATOR] again.

  • Page 37: For Call Waiting Service Users

    PQQX14045ZA.book 37 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features For Call Waiting Service Users Handset Press [FLASH/CALL WAIT] if you hear a call waiting tone during a conversation. • The first call is put on hold and you can answer the second call. •...

  • Page 38: Call Waiting Deluxe Service

    PQQX14045ZA.book 38 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features Call Waiting Deluxe Service Handset This unit is compatible with the Call Waiting Deluxe Service offered by your telephone company. • Availability varies by telephone provider. Contact your telephone company for availability in your area. After subscribing, Call Waiting Deluxe Service not only allows your handset to display the second caller’s information, but also offers you a variety of ways to deal with a second call (p.
  • Page 39 PQQX14045ZA.book 39 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features To use Call Waiting Deluxe Service You can choose from the options on the display as shown below. Display Signification Ans (Answer) Answers the second call, while keeping the first call on hold. The second call is put on hold. The caller will hear the Hold pre-recorded hold message played by the telephone company.
  • Page 40 PQQX14045ZA.book 40 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features After selecting “Ans” (Answer) or “Hold”: You can choose one of the following options: “Return”—to return to the waiting call. “Drop”—to hang up the current call and answer the waiting call. “Conference”—to make a conference call. 1.

  • Page 41: Using The Pause Key (For Pbx Line/Long Distance Calls)

    PQQX14045ZA.book 41 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features Using the PAUSE Key Handset (For PBX Line/Long Distance Calls) We recommend that you press Pause or P if a pause is Example 9P5556667777| required for dial with a PBX or to make a long distance call. e.g.

  • Page 42: Key Tone

    PQQX14045ZA.book 42 ページ ２００４年２月１９日　木曜日　午後３時４７分 Special Features Key Tone Handset You can select whether or not the handset keys will sound tones (key tone, confirmation tone, error tone). The factory preset is ON. Press [MENU]. Scroll to “Initial setting” by pressing [ Initial setting or [ ], then press Select.

  • Page 43: Wall Mounting

    PQQX14045ZA.book 43 ページ ２００４年２月１９日　木曜日　午後３時４７分 Wall Mounting This unit can be mounted on a wall phone plate. Press the tabs in the direction Tuck the telephone line cord of the arrows (1), then remove inside the wall mounting the wall mounting adaptor (2). adaptor, then push the adaptor in the direction of the arrows (1 and 2) while pressing the...

  • Page 44: Belt Clip

    PQQX14045ZA.book 44 ページ ２００４年２月１９日　木曜日　午後３時４７分 Belt Clip You can hang the handset on your belt or pocket using the included belt clip. To attach the belt clip To remove the belt clip Shoulder Rest Attachment Use the shoulder rest attachment if you need to keep your hands free during a phone conversation.

  • Page 45: Optional Headset

    PQQX14045ZA.book 45 ページ ２００４年２月１９日　木曜日　午後３時４７分 Optional Headset Connecting an optional headset to the handset allows hands-free phone conversation. Please use only a Panasonic KX-TCA86, KX-TCA91, or KX-TCA92 headset. Connecting an optional headset Open the headset jack cover, and insert the headset plug into the headset jack as shown below.

  • Page 46: Direct Commands

    PQQX14045ZA.book 46 ページ ２００４年２月１９日　木曜日　午後３時４７分 Direct Commands Handset After pressing [MENU], you can also program menu items directly by pressing ([0] to [9], and [#]) instead of using the soft keys. Menu item Command Selection items Page Ringer volume [1] [1] [0] : Off [1] : Low p.

  • Page 47: If The Following Appears On Your Display

    PQQX14045ZA.book 47 ページ ２００４年２月１９日　木曜日　午後３時４７分 If the Following Appears on Your Display... The following will be displayed when the unit needs your attention. Display message Cause & Remedy • The battery needs to be charged. Recharge the Recharge battery battery (p. 9). •...

  • Page 48: Troubleshooting

    PQQX14045ZA.book 48 ページ ２００４年２月１９日　木曜日　午後３時４７分 Troubleshooting If the handset display shows error messages, see “If the Following Appears on Your Display...” (p. 47) for the Cause & Remedy. Problem Cause & Remedy “No link to base. Move • You are too far from the base unit. Walk closer to the base unit.
  • Page 49 PQQX14045ZA.book 49 ページ ２００４年２月１９日　木曜日　午後３時４７分 Troubleshooting Problem Cause & Remedy You cannot redial. • If the last number dialed was more than 48 digits long, the number will not be redialed correctly. You cannot make long • Please make sure that you have long distance calls.
  • Page 50 PQQX14045ZA.book 50 ページ ２００４年２月１９日　木曜日　午後３時４７分 Troubleshooting Problem Cause & Remedy The Ringer/Message Alert • The Message Alert is turned on and new indicator flashes slowly when messages in your voice mailbox have been the handset is not ringing and recorded. Turn the Message Alert off (p. 17) in use.

  • Page 51: Important Information

    PQQX14045ZA.book 51 ページ ２００４年２月１９日　木曜日　午後３時４７分 Important Information NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications. This is confirmed by the registration number. The abbreviation, “IC:”, before the registration number signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met.

  • Page 52: Safety Instructions

    PQQX14045ZA.book 52 ページ ２００４年２月１９日　木曜日　午後３時４７分 Safety Instructions Take special care to follow the safety suggestions listed below. Safety 1) The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the unit. 2) When left unused for a long period of time, the base unit should be unplugged from the household AC outlet.
  • Page 53 If there is any trouble, disconnect the unit from the telephone line and connect a known working phone. If the known working phone operates properly, have your unit repaired by one of the specified authorized Panasonic Factory Servicentres. If the known working phone does not operate properly, consult your telephone...

  • Page 54: Specifications

    PQQX14045ZA.book 54 ページ ２００４年２月１９日　木曜日　午後３時４７分 Specifications ■ Base Unit Power Supply: AC Adaptor (120 V AC, 60 Hz) Power Consumption: Standby: Approx. 2.1 W Maximum: Approx. 5.0 W Frequency: 2.4 GHz – 2.48 GHz Dimensions (H x W x D): Approx. 124 mm x 155 mm x 174 mm "...

  • Page 55: Warranty

    5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PANASONIC PRODUCT—LIMITED WARRANTY Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.
  • Page 56 PQQX14045ZA.book 56 ページ ２００４年２月１９日　木曜日　午後３時４７分 Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PQQX14045ZA F0304-0...
