- Page 1 H9108UV...
-
Page 2: Table Of Contents
1.4 – Optional Components …………………………….……………..………….…..3 1.5 – What is the 9108UV? …………………………………………..……………..3 2 – DVR Panels and Controls ……..………………………………………..…..4 2.1 – H9108UV Front Panel …………………………………………………….…..4 2.1.1 – H9108 V Front Panel Navigation…………………………………….…..4 2.2 – H9108UV Rear Panel ……………………………..………………………..4 2.3 – Remote Control ……………………………………………………..….…..5... - Page 3 USER MANUAL USER MANUAL 6.7 – Privacy Zone ..................16 12.2 – User Password ................29 6.7.1 – Privacy Zone Setup ...............16 12.3 – Server Port ..................29 – Configuring Recording Settings...............16 12.4 – Setting Up Your Phone..............29 – Channel ....................17 13 – Motion Detection ................30 7.2 –...
-
Page 4: Safety Instructions
Dropping the DVR on any hard surface may cause a malfunction. If the DVR does 1.2 - DVR SPECIFICATIONS not work properly due to physical damage, please contact Customer Service for repair or exchange. Model DVR-H9108UV-4 CH Standalone DVR Use standard lithium cell battery. (NOTE: Manufacturer has preinstalled battery.) Video Compression H.264... -
Page 5: Package Contents
USER MANUAL USER MANUAL 2 – DVR PANELS AND CONTROLS LAN or Internet Browsing Remote Access Rs-485 PTZ Control 2.1 – 9108UV FRONT PANEL 4CH/1CH Sensor/Alarm C B E HDD Interface SATA, Support up to 1TB Network Function Support to Live View with IE & with Mobile Phone Normal Play, Fast Forward, Fast Rewind, Frame by Playback Mode Frame... -
Page 6: 3- Installing Your Hardware
Table 2-4: 9108UV Remote Control Functions table Important! Do not use any other power sources other than those provided by Zmodo 3- INSTALLING YOUR DVR HARDWARE Your camera has a built-in cord that splits into one (1) BNC video connector and one (1) RCA 12V DC power connector. -
Page 7: Ptz (Pan/Tilt/Zoom) Cameras
Section11-PTZ SETUP. Please do not cut, splice, or otherwise modify the electrical wires on any of the What you will need: Zmodo cameras, DVRs, or power supplies. Doing so will prevent us from · PTZ Camera providing further technical support and will void the equipment warranty. -
Page 8: Connecting A Computer Monitor
The front panel USB port for backup is identified with the universal USB symbol Section 8. You may also visit http://zmodo.net or contact Technical Support. While you can either format the drive as FAT32 first from a Windows PC, you may also format the drive using the USB format command in the HDD Management console. -
Page 9: Main Video Feed Display
USER MANUAL USER MANUAL Connecting the power supply to the DVR Devices – Manage hard drive, alarm, PTZ, mobile phone, and motion detection settings. will begin the startup process. After a few System – Configure date and time, security settings, video options, system language, moments, a message similar to the device information, and automatic maintenance. -
Page 10: Display Setup
USER MANUAL USER MANUAL Menu Option Function Sub-Menus Function Sets a username, password, Color Setup Color Setup permits Display Setup configures the and port for connecting to live view for each channel. adjustment of video for each the DVR remotely via mobile individual camera phone. -
Page 11: Title
USER MANUAL USER MANUAL 6.5 - DISPLAY TIME OPTIONS Provides motherboard version, firmware version, While in Live View and MAC address. Shows or hides current date and time on live video display. While Recording System Shows or hides date and time while recording. Information 6.6 –... -
Page 12: Channel
USER MANUAL USER MANUAL 7.1 - CHANNEL 8 – NETWORK SETUP There is a drop-down menu for each channel. The options are On and Off. Selecting Off will disable the recording for the desired channel. By configuring the network settings, the DVR and cameras can be viewed and controlled remotely 7.2 –... -
Page 13: Subnet Mask
Click Yes or OK to proceed downloading Web Port, a port forwarding rule must be created on the router. Please visit and installing the controls. http://zmodo.net or contact Technical Support for assistance setting up port forwarding. 8.9 – DDNS SETUP Enter local IP Address of DVR according to router's defined range (Section 8.4). -
Page 14: Searching For And Playing Recordings
USER MANUAL USER MANUAL If the DDNS option is not available on the router, 9.3 – PLAYING RECORDINGS download and install the DynDns Updater (www.dyndns.com) on a computer that will be Method 1: running continually. Select the day or hour to be viewed, and then click the Playback button. -
Page 15: Device Management
Important Note! If overwrite is enabled, it is imperative to back up files regularly. Once a and sets sensitivity and detection area. file has been overwritten, neither Zmodo technical support nor the manufacturer can assist in recovering the overwritten file. -
Page 16: Usb Format
The H icon will also appear if For complete instructions on installing external there is no hard drive installed or if it has not been formatted. sensors, please visit http://zmodo.net. HDD SPACE 10.2.1 – I/O Channel When this trigger is enabled, the alarm will be activated when the remaining space on the hard drive is too low to continue recording. -
Page 17: Ptz Setup
Enter an e-mail address to identify that the DVR is sending the alarm notification The options are 5, 6, 7, or 8. The default setting of 8 should be kept for Zmodo (e.g., dvr@emailprovider.com). The e-mail address must be set up as an account PTZ cameras. -
Page 18: Mobile Phone Setup
Fi gur e 13- 42: Mot ion Det ec tion se lec tion gr id Blackberry software can be downloaded from http://zmodo.net. Clicking and dragging the green marker will allow changing multiple pixels Windows Mobile and Nokia Symbian use Qqeye. -
Page 19: System Setup
USER MANUAL USER MANUAL 14 – SYSTEM SETUP Daylight Savings Time begins from 2:00 AM on the second Sunday of March until 2:00 AM on the first Sunday in November. To access the System Setup menu, go to Main Menu > System. 14.1.2 - HOW TO SET DAYLIGHT SAVINGS TIME The System Setup sub-menus feature the following options: Confirm whether or not your area observes DST. -
Page 20: Video System
USER MANUAL USER MANUAL To restore correct video settings, follow these steps: the 9108UV. If using the front panel controls 14.6 – MAINTAIN (SYSTEM MAINTAIN) Menu > FWDx2 > DOWNx1 > SEL > FWDx2 > SELx2 > UPx1 > SEL > DOWNx2 > SEL > wait 5 seconds >... -
Page 21: Programming The Ptz Cameras
Refer to Section 3.1 for instructions on how to ensure the hard drive is properly CUR. POINT installed. Current Point displays the set point currently being If the hard drive continues to appear to be malfunctioning, please contact Zmodo Figure 15-54: Cruise Setup control panel programmed or edited. technical support. -
Page 22: Appendices
All products carry a 1-year warranty unless otherwise indicated. 3 year warranty If the DVR becomes excessively hot, turn it off, unplug it, and contact technical plan is also available for purchase. Zmodo will, at its sole discretion, replace or support.
