  • Page 1 SURFboard SBV6120 ® DOCSIS 3.0 Digital Voice Modem ® Quick Start Guide...
  • Page 2: Table Of Contents

    Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 SBV6120 Quick Start Guide...
  • Page 3: Before You Begin

    Before You Begin Introduction This document will help you quickly set up your Motorola SURFboard SBV6120 DOCSIS 3.0 Digital Voice Modem. ® ® System Requirements Your computer must meet the following minimum requirements: • An established coaxial cable connection •...
  • Page 4: Product Overview

    Cable Connector LINK TEL 1 TEL 2 Power Connector Front Panel Description The indicator lights on the SBV6120’s front panel provide the following status information: FLASHING POWER Power is disconnected Not applicable Green: Digital voice modem is powered on RECEIVE...
  • Page 5: Rear Panel Description

    • Contact your cable service provider before connecting the Motorola SURFboard Digital Voice Modem to your existing telephone wiring. Do not connect the telephone cable from the TEL port to a traditional telephone service. Note: To prevent damage to the SBV6120 Digital Voice Modem...
  • Page 6: Testing The Connections

    To verify that all the components were properly installed, perform the following connectivity test: Power on the computer and then log on. Check that all the LEDs on the SBV6120 front panel are either on or flashing, except for TEL 1 and TEL 2. The telephony LEDs will be on if the SBV6120 is set up for telephone service.
  • Page 7: Troubleshooting

    Check that the Ethernet cable is properly connected to the SBV6120 and your computer. • Check the LEDs on the front of the SBV6120. Note the first LED from top to bottom that is or flashing. This LED shows where the error occurred; see Front Panel Description on page 2 for more information.
  • Page 8 MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. SURFboard is a registered trademark of General Instrument Corporation, a wholly-owned subsidiary of Motorola, Inc. Microsoft and Windows are registered trademarks and Windows XP and Windows Vista are trademarks of Microsoft Corporation. Netscape is a registered trademark of Netscape Communication Corporation.
