Atmel AT91SAM7X Specification Sheet page 2

AT91SAM7X and AT91SAM7XC ARM Microcontrollers
For Real-time Ethernet Networking
The AT91SAM7X-EK and AT91SAM7XC-EK
development kits enable evaluation capabilities
and code development for applications
r u n n i n g o n t h e AT 9 1 S A M 7 X a n d
AT 9 1 S A M 7 X C m i c ro c o n t ro l l e r s
respectively. The development
kit package contains following
items:
■
an AT91SAM7X
or AT91SAM7XC
Evaluation Board
■
one A/B-type USB cable
■
one crossed serial RS232 cable
■
one RJ45 crossed Ethernet cable
■
universal input AC/DC power supply with US and EU plug
adapter
■
a DVD-ROM containing summary and full datasheets with electrical and
mechanical characteristics, application notes and getting started documents for all
AT91 microcontrollers. An AT91 software package with C and Assembly listings is also provided. All this
allows a user to begin evaluating an AT91 ARM
■
more information on tools and software is available on:
http://www.atmel.com/dyn/products/tools.asp?family_id=605
Open Source Software Offering
FreeRTOS™
NUT/OS
eCOS
Product Flash
AT91SAM7X512 512 KB
AT91SAM7XC512 512 KB
AT91SAM7X256 256 KB
AT91SAM7XC256 256 KB
AT91SAM7X128 128 KB
AT91SAM7XC128 128 KB
(1) Contains crypto hardware. Export restrictions may apply.
Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel
products. EXCEPT AS SET FORTH IN ATMEL'S TERMS AND CONDITIONS OF SALES LOCATED ON ATMEL'S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY
RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY
DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS AND PROFITS, BUSINESS INTERRUPTION, OR LOSS OF INFORMATION) ARISING OUT OF THE
USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no representations or warranties with respect to the accuracy or completeness of the contents of this
document and reserves the right to make changes to specifications and products descriptions at any time without notice. Atmel does not make any commitment to update the information contained herein. Unless specifically provided otherwise, Atmel
products are not suitable for, and shall not be used in, automotive applications. Atmel's products are not intended, authorized, or warranted for use as components in applications intended to support or sustain life.
® Thumb ® 32-bit microcontroller quickly and easily.
Commercial Software Offering
µC/OS-II
Tiny+
®
ThreadX
eCosPro™
IAR PowerPac™
SRAM Package Ordering Code
LQFP100 AT91SAM7X512-AU
128 KB
BGA100 AT91SAM7X512-CU
LQFP100 AT91SAM7XC512-AU
128 KB
BGA100 AT91SAM7XC512-CU
LQFP100 AT91SAM7X256-AU
64 KB
BGA100 AT91SAM7X256-CU
LQFP100 AT91SAM7XC256-AU
64 KB
BGA100 AT91SAM7XC256-CU
LQFP100 AT91SAM7X128-AU
32 KB
BGA100 AT91SAM7X128-CU
LQFP100 AT91SAM7XC128-AU
32 KB
BGA100 AT91SAM7XC128-CU
EmbOS RTL-ARM
Nucleus MQX™ RTOS
AMX™ RTOS RTXC™
smx ® Salvo™
Green Compliance
(1)
(1)
(1)
(1)
(1)
(1)
