MSH Protos Carbon Instruction Manual

Hide thumbs Also See for Protos Carbon:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
RC Helicopter
Instructions Manual
Main rotor diameter : 965mm
Tail rotor diameter : 192mm
Lenght without main blades : 892mm
Lenght with main blades : 1122mm
Main blades lenght : 425mm
Overall height : 282mm
Tail rotor - Main rotor ratio : 4,65
Main pulley : 93T
Weight ready to y with 6sLipo : 1550g
(may vary with di erent electronics)
