Oricom FS300 User Manual

Non-contact infrared thermometer
Hide thumbs

Advertisement

Table of Contents

User Manual
FS300
Non-Contact Infrared Thermometer
FS300 is included as a medical device on the Australian
Register of Therapeutic Goods (ARTG No. 198437).
FS300 is intended for use as a measuring device for determining the patient's body temperature.
AlwAyS ReAd The lAbel ANd uSeR Guide, uSe oNly AS diRecTed.
Keep this user guide for future reference. Always retain your proof of purchase in case of warranty
service and register your product on line at AuSTRAliA: www.oricom.com.au
Please visit www.oricom.com.au for the latest copy of this user manual.
oricom customer Support: 1300 889 785 or (02) 4574 8888

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oricom FS300

Summary of Contents for Oricom FS300

  • Page 1 FS300 is included as a medical device on the Australian Register of Therapeutic Goods (ARTG No. 198437). FS300 is intended for use as a measuring device for determining the patient's body temperature. AlwAyS ReAd The lAbel ANd uSeR Guide, uSe oNly AS diRecTed.
  • Page 2 Need Help? if you need assistance setting up or using your oricom product now or in the future, call oricom Support. Australia 1300 889 785 or (02) 4574 8888 www.oricom.com.au Mon-Fri 8am – 6pm AeST New Zealand 0800 67 42 66 www.oricom.co.nz...

  • Page 3: Table Of Contents

    Non-Contact Forehead Infrared Thermometer Table of contents Contents 1. Product description ................9 2. Before first use ...................10 3. Switching on and setting the thermometer ..........10 4. Measuring body temperature ..............10 5. Displaying stored measurements ............12 6. Measuring object temperature ............12 7.
  • Page 4 • do not take the temperature with this product near heat sources such as in direct sunlight, near a fireplace or stove. • do not use this product if it is not working properly, contact oricom support. • There are no user serviceable parts the only service required is battery replacement and general cleaning please follow instructions in this user guide.
  • Page 5 Warning Many people may not have an elevated temperature even if they are ill. in the following cases please consult your medical professional before using this product. • under 90-day-old infants • People on steroids, antibiotics or antipyretics. • People with compromised immune systems. Cautions • The reliability of the measurement cannot be guaranteed if the temperature is measured from parts of body that are not recommended (anywhere other than the...
  • Page 6 Warning Simple Operation Principle emperature is reflected on the temporal artery. The body t • Te artery is the artery located closest to the skin and is spread on the mporal forehead. if the blood with body temperature reflection passes the temporal artery on forehead, corresponding amount of infrared rays will be generated.
  • Page 7 How to Take a Temperature How to Take a Temperature Normal Measurement Point NOTE: Temperature readings may vary according to the location of measurement from forehead to temple. Therefore we recommend to measure the temperature at more than 2 points on the forehead. use the highest temperature rating as the most accurate reading.
  • Page 8 How to Take a Temperature Temperature Ranges body temperature means internal temperature of body. Normal temperature even in a healthy person can vary within a small range. The temperature of a person measured in the evening is normally 0.5oc higher than early morning and is also affected by the environment, time and activity.

  • Page 9: Product Description

    Product description 1. Product description 1 LCD display 4 MODE button 7 Battery cover 2 Probe 5 MEM button 3 Start button 6 Sound boutton buttons Functions Switching the device on. Starting temperature measurement. Setting the measurement method. displaying stored measurements (max 32). Setting the acoustic signal (on/off).

  • Page 10: Before First Use

    Before first use 2. Before first use • before first use, insert the batteries supplied (2 x AAA Alkaline batteries). 3. Switching on and setting the thermometer • Press the Start button briefly. > The device switches on. After two seconds, the display shows that the device is ready for use.
  • Page 11 Before first use • hold the thermometer 2 to 3cm from the measuring point. > The ideal measuring point is the temple area. • Press the Start button briefly. > Keep the distance until you hear the measurement completion beep. >...

  • Page 12: Displaying Stored Measurements

    Displaying stored measurements 5. Displaying stored measurements • Press the Start button briefly. > The device switches on. After two seconds, the display shows that the device is ready for use. • The device automatically stores the last 32 measurements. • Press the MeM button briefly.

  • Page 13: Battery Replacement

    Battery Replacement • Read the temperature from the display. > Measurements in object temperature mode are not stored. • Subject surface temperature and inner temperature can be different. 7. Battery Replacement • The device requires two AAA Alkaline batteries. > open the battery compartment. >...

  • Page 14: Error Messages

    Error messages 8. Error messages display error description Trouble-shooting operating temperature The device temperature approx. is outside the operating 15 ° c to 40 ° c temperature range. (59 ° F to 104 ° F) Measurement range for The temperature of the body temperature measuring point is above 34 °...

  • Page 15: Cleaning And Storage

    Cleaning and Storage 9. Cleaning and Storage • The sensor is a very sensitive part and easily damaged. For accurate measurement please keep the sensor clean. • To clean the sensor please keep it facing down and carefully clean with an alcohol moistened cotton bud, allow to dry for at least one hour before using.

  • Page 16: Product Specifications

    Product Specifications 10. Product Specifications FS300 item details of description infrared(iR) measurement, Measurement method Non-contact measurement Switches for Multi-measurements (body and object temperatures) basic functions Switches for celsius/Fahrenheit, Memory function, Sound controls(on,off) 15 ° c to 40 ° c(59 ° F to 104 ° F), humidity : below 90%...
  • Page 17 62.4(w) x 41.8(d) x 103.1(h) mm weight 120g (without batteries) FS300 is included as a medical device on the Australian Register of Therapeutic Goods (ARTG No. 198437). FS300 is intended for use as a measuring device for determining the patient's body temperature. AlwAyS ReAd The lAbel ANd uSeR Guide, uSe oNly AS diRecTed.

  • Page 18: Customer Support

    Important Please retain your purchase receipt and attach to the back page of this user guide as you will need to produce this if warranty service is required. Take a few moments to register your product online: www.oricom.com.au...

  • Page 19: Express Warranty

    EXPRESS WARRANTY Express Warranty (Australia) This express warranty is provided by oricom international Pty ltd AbN 46 086 116 369, unit 1, 4 Sovereign Place, South windsor NSw 2756, herein after referred to as “oricom”. oricom products come with guarantees that cannot be excluded under the Australian consumer law.
  • Page 20 Spare parts are warranted to be free from defects in material or workmanship for thirty (30) days or for the remainder of the express warranty Period of the oricom branded product in which they are installed, whichever is longer. during the express warranty Period, oricom will where possible repair and if not replace the faulty product or part thereof.
  • Page 21 Please note that if a customer Support Team member advises that your product does not qualify for return, this warranty does not apply to your product. Products that are authorised to be returned to oricom in Australia must include all of the following: • A completed Return Authorisation form • A copy of your Proof of Purchase (please keep your original copy)
  • Page 22 EXPRESS WARRANTY Important Information Repair Notice Please be aware that the repair of your goods may result in the loss of any user- generated data (such as stored telephone numbers, text messages and contact information). Please ensure that you have made a copy of any data saved on your goods before sending for repair.
  • Page 23 Phone: 1300 889 785 or (02) 4574 8888 (Monday to Friday 8am to 6pm AeST) web: www.oricom.com.au Fax: (02) 4574 8898 Contact details for Oricom support and warranty claims in New Zealand email: support@oricom.co.nz Phone: 0800 674 266 (Monday to Friday 10am to 8pm NZST) web: www.oricom.co.nz...
