CONTENTS BEFORE USE BEFORE USE IMPORTANT • To ensure proper use, please read through this manual before using this product. It is especially BASICS important that you read and observe Warning and Caution in this manual. • Please keep the manual in a safe and accessible place for future reference. GETTING STARTED 1 Select the display language Warning...
BASICS Faceplate Remote control (RC-406) Volume knob Display window Remote sensor (Do not expose to bright sunlight.) Lights up when Bluetooth connection is established. ( 12) Pull out the insulation sheet when using for the first time. Detach button Flashes when the unit enters searching status. Attach Detach How to reset...
GETTING STARTED Set the clock and date Press the volume knob to enter [FUNCTION]. Turn the volume knob to select [CLOCK], then press the knob. To adjust the clock Turn the volume knob to select [CLOCK ADJUST], then press the knob. Turn the volume knob to make the settings, then press the knob.
• The output sound level may be extremely high or low. UPDATE SYSTEM F/W UP xx.xx YES: Starts upgrading the firmware. ; NO: Cancels (upgrading is not activated). For details on how to update the firmware, see: www.kenwood.com/cs/ce/ FACTORY RESET YES: Resets the settings to default (except the stored station). ; NO: Cancels. ENGLISH...
RADIO Other settings Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then press the knob. Repeat step until the desired item is selected or activated. Press and hold to exit. To return to the previous setting item, press Search for a station Default: XX...
RADIO Preparation: PTY SEARCH 1 Press the volume knob to enter PTY language selection. Select [ON] for [BUILT-IN AUX]. ( 5) 2 Turn the volume knob to select the PTY language (ENGLISH/ FRENCH/ GERMAN), then press the knob. Start listening 3 Turn the volume knob to select the available Program Type (see the Connect a portable audio player (commercially available).
When connecting an Android device, “Press [VIEW] to install KENWOOD MUSIC PLAY APP” is shown. Follow the instructions (commercially available) to install the application. You can also install the latest version of KENWOOD MUSIC PLAY application on your Android device before connecting. ( 23) For ANDROID: Applicable only when [BROWSE MODE] is selected.
While in ANDROID source, press 5 repeatedly. – Not applicable for iPod. BROWSE MODE : Control Android device from this unit via KENWOOD MUSIC PLAY application installed in (or) the Android device. Press S / T to search at a preset skip search ratio. ( 10, [SKIP SEARCH])
Pandora® USB / iPod / ANDROID (Not applicable for Korean models) Preparation: Direct Music Search (using RC-406) Install the latest version of the Pandora application on your device (iPhone/ iPod touch), then Press DIRECT. create an account and log in to Pandora. Press the number buttons to enter a track/file •...
BLUETOOTH® Pandora® (Not applicable for Korean models) BLUETOOTH — Connection Search for a registered station Press Supported Bluetooth profiles Turn the volume knob to select an item, then press the knob. – Hands-Free Profile (HFP) [SORT BY DATE]: According to the registered date –...
Automatic pairing request is activated only if: – Bluetooth function of the connected device is turned on. – [AUTO PAIRING] is set to [ON]. ( 15) – KENWOOD MUSIC PLAY application is installed on the Android device ( 8) and [BROWSE MODE] is selected ( 9).
BLUETOOTH® The following operations may differ or not available depending on the connected phone. Improve the voice quality While talking on the phone... On the faceplate On the remote control Press the volume knob to enter [FUNCTION]. First incoming call... Turn the volume knob to select an item (see the following table), then press the knob.
BLUETOOTH® Default: XX PHONE BOOK (Applicable only if the phone supports PBAP) 1 Turn the volume knob quickly to enter alphabet search mode (if the SETTINGS phonebook contains many contacts). AUTO ANSWER 1 — 30: The unit answers incoming call automatically in the selected The first menu (ABCDEFGHIJK) appears.
BLUETOOTH® Make a call using voice recognition Other settings Press and hold to activate the voice recognition of the Press the volume knob to enter [FUNCTION]. connected phone. Turn the volume knob to select an item (see the following table), then Speak the name of the contact you want to call or the voice press the knob.
BLUETOOTH® BLUETOOTH — Audio Bluetooth test mode You can check the connectivity of the supported profile between the Bluetooth device and the unit. • Make sure there is no Bluetooth device paired. Press and hold “PLEASE PAIR YOUR PHONE PIN 0000” appears. Search and select this unit model name (KMM-BT30 ) on the Bluetooth device.
AUDIO SETTINGS BLUETOOTH® While listening to any source... Internet radio via Bluetooth Press the volume knob to enter [FUNCTION]. Listen to Pandora Turn the volume knob to select [AUDIO CONTROL], then press the knob. Turn the volume knob to select an item (see the following table), then press the knob. You can listen to Pandora on the Android device via Repeat step until the desired item is selected or activated.
AUDIO SETTINGS Crossover settings FADER (Not applicable if 3-way crossover is selected.) R15 to F15 (0): Adjusts the rear and front speaker output balance. Below are the available setting items for 2-way crossover and 3-way crossover. BALANCE L15 to R15 (0): Adjusts the left and right speaker output balance. VOLUME OFFSET –15 to +6 (0): Preset the initial volume level of each source.
DISPLAY SETTINGS Default: XX COLOR SELECT Select color for ALL ZONE, ZONE 1 and ZONE 2 separately. 1 Select a zone. 2 Select a color for the selected zone. VARIABLE SCAN/ CUSTOM R/G/B/ preset colors* To make your own color, select [CUSTOM R/G/B]. The color you have made will be stored in [CUSTOM R/G/B].
TROUBLESHOOTING Symptom Remedy Symptom Remedy • Adjust the volume to the optimum level. Sound cannot be heard. “NA FILE” Make sure the media contains supported audio files. • Check the cords and connections. ( 23) “MISWIRING CHECK WIRING Turn the power off, then check to be sure the “READ ERROR”...
TROUBLESHOOTING Symptom Remedy Symptom Remedy • Make sure KENWOOD MUSIC PLAY APP is installed on the • Search from the Bluetooth device again. Cannot playback at No Bluetooth device is • Reset the unit. ( 3) [BROWSE MODE]. Android device. ( 8) detected.
“ERROR” Try the operation again. If “ERROR” appears again, check if the device supports the function you have tried. Visit also the following website <www.kenwood.com/cs/ce/> for: – Latest firmware updates and latest compatible item list “NO INFO” / “NO DATA”...
Source name Display information - iPhone 3G, 3GS, 4, 4S, 5, 5S, 5C, 6, 6 Plus • You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod. STANDBY Source name (Date/Clock)* • Depending on the version of the operating system of the iPod/iPhone, some functions may...
INSTALLATION / CONNECTION Warning Installing the unit (in-dash mounting) • The unit can only be used with a 12 V DC power supply, negative ground. • Disconnect the battery’s negative terminal before wiring and mounting. • Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire (black) to prevent a short circuit.
If no connections are made, do not let the wire come out from the tab. Gray To front speaker (right) / For 3-way Gray/Black crossover: Mid range speaker (right) Brown To connect the Kenwood navigation Green (D) Wiring harness (Mute control wire) system, refer your navigation To rear speaker (left)
SPECIFICATIONS FM Frequency Range 87.5 MHz — 108.0 MHz (50 kHz space) USB Standard USB 1.1, USB 2.0 Full Speed Channel Space Selection 50 kHz File System FAT12/ 16/ 32 Usable Sensitivity 8.2 dBf (0.71 μV/75 Ω) Maximum Supply Current DC 5 V 1.5 A (S/N = 26 dB) Frequency Response (±1 dB) 20 Hz — 20 kHz Quieting Sensitivity 17.2 dBf (2.0 μV/75 Ω) Signal-to-Noise Ratio (1 kHz)
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Band 8: 1.6 kHz ±9 dB and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and Band 9: 2.5 kHz ±9 dB trade names are those of their respective owners.
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and 6.1 ﻛﻴﻠﻮ ﻫﺮﺗﺰ 9± ﺩﻳﺴﻴﺒﻞ :8 ﺍﻟﻤﻮﺟﺔ any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade 5.2 ﻛﻴﻠﻮ ﻫﺮﺗﺰ 9± ﺩﻳﺴﻴﺒﻞ :9 ﺍﻟﻤﻮﺟﺔ...
