- Page 1 WLA-12 OPERATING MANUAL AND USER GUIDE www.wharfedalepro.com...
-
Page 2: Important Warnings And Safety Instructions
Inspect all mounting hardware before your line array is flown. If there is any damage or distortion to any mounting hardware do not fly the array until any damaged hardware is repaired or replaced. Only use Wharfedale Pro supplied Quick Release Pins, contact your Wharfedale Pro Distributor if any... -
Page 3: Table Of Contents
Bi-Amp Mode .......................9 Parallel Wiring ....................10 WLA-12 Fly Frame ..................... 11 WLA-12 Dolly .....................13 Installation ......................14 Dimensional Drawings - WLA-12 ..............18 Dimensional Drawings - WLA-12 Fly Frame ...........19 Dimensional Drawings - WLA-12 Dolly ............20 Example Arrays ....................21 Specification ......................22 Warranty......................22... -
Page 4: Introduction
OPERATING MANUAL AND USER GUIDE Introduction The Wharfedale Pro WLA- is a mid format line array system with exceptional output, frequency response, directivity and throw capability. High tech transducers and enclosure design techniques give the WLA- a perfect power to size ratio. The WLA- achieves ultra high sensitivity with its fully horn-loaded architecture. A horn-loaded 12” LF is combined with three horn-loaded titanium compression drivers for the HF, generating huge SPL with maximum efficiency. The ultra high sensitivity of the WLA Series creates punishing level from even the most modest of power amplifiers, ensuring that your system can generate a huge SPL. -
Page 5: Features
WLA Series Features High Sensitivity, Full Horn Loaded Design 400W/800W/1600W Power Handling 12” Horn Loaded LF Driver 3” LF Voice Coil 3x 1” Exit HF Compression Drivers 1.8” Pure Titanium HF Diaphragms With Rare Earth Magnets Physically Aligned Transducers Internal Passive Crossover Network External Crossover Bypass Switching Front Hinged Rigging System Captive Rigging Hardware with Tethered Quick Release Pins... -
Page 6: Splay Angles
OPERATING MANUAL AND USER GUIDE Splay Angles The WLA can be configured with several different splay angles. The splay angles determine the amount of overlap between individual units. This is used to determine the amount of summation, or “throw”, for separate sections of the array. As the splay angle between boxes increases the summation decreases but spectral variance due to interactions between elements is also decreased. -
Page 7: Air Absorption
WLA Series Air Absorption The high frequency performance of the medium and long throw sections of the line array will be limited by air absorption. As the distance from the source increases, the mid and high frequencies will be reduced. The amount of absorption at a given frequency is a function of pressure, temperature, and relative humidity. - Page 8 OPERATING MANUAL AND USER GUIDE Air Absorption Humidity (%)
-
Page 9: Full Range Mode
WLA Series Full Range Mode... -
Page 10: Bi-Amp Mode
OPERATING MANUAL AND USER GUIDE Bi-Amp Mode... -
Page 11: Parallel Wiring
WLA Series Parallel Wiring... -
Page 12: Wla-12 Fly Frame
OPERATING MANUAL AND USER GUIDE WLA-12 Fly Frame THE WLA-12 AND FLY FRAME IS CERTIFIED TO HOLD A TOTAL WEIGHT (INCLUDING THIRD PARTY HARDWARE) OF 750KG. 12 ELEMENTS CAN BE FLOWN WITH A SAFETY FACTOR OF 5.7. Only use the Wharfedale Pro WLA- with the WLA Flyframe. Ensure that only rated, certified hardware such as turnbuckles, shackles and chains are used. - Page 13 WLA Series...
-
Page 14: Wla-12 Dolly
OPERATING MANUAL AND USER GUIDE WLA-12 Dolly The WLA-12 Dolly should always be used when flying a WLA-12 line array system. Each WLA- Dolly will hold a single WLA- element. The WLA- Dolly helps to protect the WLA- element and aid the connection and flying process. -
Page 15: Installation
WLA Series Installation One Point Hang Procedure - Method 1 Attach a suitably rated shackle to the center spine of the fly frame. Use washers to ensure the shackle pin is centered on the spine. The connection point will depend on the splay angles used in your array and can be used to aim the array. - Page 16 OPERATING MANUAL AND USER GUIDE Method 1 & 2 Diagram THE WLA-12 AND FLY FRAME IS CERTIFIED TO HOLD A TOTAL WEIGHT (INCLUDING THIRD PARTY HARDWARE) OF 750KG. 12 ELEMENTS CAN BE FLOWN WITH A SAFETY FACTOR OF 5.7.
- Page 17 WLA Series Two Point Hang (Limited Space) Procedure - Method 3 Attach suitably rated shackles to the front and rear holes on the center spine of the fly frame. Use washers to ensure the shackle pins are centered on the spine.
- Page 18 OPERATING MANUAL AND USER GUIDE Method 3 Diagram THE WLA-12 AND FLY FRAME IS CERTIFIED TO HOLD A TOTAL WEIGHT (INCLUDING THIRD PARTY HARDWARE) OF 750KG. 12 ELEMENTS CAN BE FLOWN WITH A SAFETY FACTOR OF 5.7.
-
Page 19: Dimensional Drawings - Wla-12
WLA Series Dimensional Drawings - WLA-12... -
Page 20: Dimensional Drawings - Wla-12 Fly Frame
OPERATING MANUAL AND USER GUIDE Dimensional Drawings - WLA-12 Fly Frame THE WLA-12 AND FLY FRAME IS CERTIFIED TO HOLD A TOTAL WEIGHT (INCLUDING THIRD PARTY HARDWARE) OF 750KG. 12 ELEMENTS CAN BE FLOWN WITH A SAFETY FACTOR OF 5.7. -
Page 21: Dimensional Drawings - Wla-12 Dolly
WLA Series Dimensional Drawings - WLA-12 Dolly... -
Page 22: Example Arrays
OPERATING MANUAL AND USER GUIDE Example Arrays THE WLA-12 AND FLY FRAME IS CERTIFIED TO HOLD A TOTAL WEIGHT (INCLUDING THIRD PARTY HARDWARE) OF 750KG. 12 ELEMENTS CAN BE FLOWN WITH A SAFETY FACTOR OF 5.7. -
Page 23: Specification
580mm / 22.8" Weight Net Weight 61Kg / 134.2lbs Gross Weight 73Kg / 160.6lbs WHARFEDALE PRO LIMITED WARRANTY Wharfedale Pro products are warranted of manufacturing or material defects for a period of one year from the original date of purchase. In the event of malfunction, contact your authorized Wharfedale Pro dealer or distributor for information. *Be aware that warranty details may differ from country to country. Contact your dealers or distributor for information. These terms do not infringe your statutory rights. - Page 24 Wharfedale Professional IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, England www.wharfedalepro.com Wharfedale Professional reserves the right to alter or improve specifications without notice. All rights reserved © 2013 Wharfedale Pro. Wharfedale Pro is a member of the IAG Group.
