Wall mounted type residential air-conditioners
Hide thumbs
Table of Contents

Advertisement

Quick Links

Manual No.'15•SRK-T-172
RESIDENTIAL AIR-CONDITIONING
TECHNICAL MANUAL & PARTS LIST
WALL MOUNTED TYPE
RESIDENTIAL AIR-CONDITIONERS
(Split system, air cooled cooling only type)
SRK10CRV-S, S1
SRK13CRV-S, S1
SRK10CRS-S, S1, S2, S3, S4, S5, S6
SRK13CRS-S, S1, S2, S3, S4, S5, S6
