Wap Browser Display - Nokia 9110i Developer's Manual

The size of the application area depends on the width of the longest command button text. The
minimum width of the command button area is 430 pixels, the maximum being 480 pixels.
Indicator
area
Search
field
Figure 2
3.2.2 Display components
The display is able to show 16 grey tones. All of these will be used when images are shown. Only 4
tones are to be used in the system UI (i.e. components, icons, the indicator area etc.)
The fonts use two different tones (Black, grey 2N), grey. Normally all texts are black. When command
buttons or texts in the active window are dimmed (meaning that the user can't select them) grey 2N is
used.

3.3 WAP Browser Display

WAP services main view is shown below:
Figure 3. Main view
Application area
Selection
frame
Different parts of the display
Command
button area
area
Scroll
bar
10 (26)
