Installation and Operating Instructions
For Single Burner Outdoor BBQ Models Alpha & Bravo.
IMPORTANT: READ THIS DOCUMENT THOROUGHLY BEFORE USING YOUR
SOVEREIGN BBQ.
IMPORTANT: REMOVE ALL PACKING MATERIAL AND LITERATURE FROM
YOUR BBQ BEFORE ASSEMBLY, CONNECTION TO GAS AND USE.
Thank you and congratulations for choosing a quality Sovereign BBQ for all your cooking and
entertainment needs.
By following these instructions for safe and easy operation, you will enjoy many years of
satisfying, trouble free outdoor cooking.
INSTALLATION
Choosing a Location
This BBQ is for outdoor use only and should be placed in a well ventilated area. Take care to
ensure that it is not placed UNDER or ABOVE any combustible surfaces. The sides of the BBQ
should NEVER be closer than the following: minimum recommended distances from combustible
materials - 100mm sides, 200mm front & rear, 50mm bottom, 1200mm above. Keep this BBQ
away from flammable materials. Installation of appliance and cylinder must be in accordance with
AS5601 - 2002 / AG601 2002 requirements.
Should you intend to install your BBQ on a boat, Sovereign BBQ's recommend (for optimum
performance) that the BBQ be installed either across the transom or to the port side of your vessel.
This ensures the air intake on the BBQ is not installed to windward (as it would be if mounted to
Starboard), and will make for more enjoyable use of your appliance in heavy weather conditions.
Other Precautions
Do not obstruct any of the ventilation openings in your Sovereign BBQ body. Also, position the
gas supply bottle on level ground next to the BBQ and safely away from any source of heat.
Should you need to change the gas bottle, confirm that the BBQ is turned off, and that there are
no sources of ignition (cigarettes, open flame, sparks etc.) nearby before proceeding. Be sure to
inspect the gas hose and ensure it is free of any twisting or tension. The hose should hang freely
with no bends, folds, or kinks, which could obstruct free flow of gas. Apart from the connection
point, no part of the hose should touch any hot BBQ parts. Inspect the hose before use.
www.sovereignbbqs.com
ABN: 12 972 212 300
Phone (Intl +61 7) 3382 0230 • Fax (Intl +61 7) 3382 0087
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sovereign Alpha
Summary of Contents for Sovereign Alpha
- Page 1 Starboard), and will make for more enjoyable use of your appliance in heavy weather conditions. Other Precautions Do not obstruct any of the ventilation openings in your Sovereign BBQ body. Also, position the gas supply bottle on level ground next to the BBQ and safely away from any source of heat.
- Page 2 Please note your Sovereign BBQ is intended for use with propane gas only. Only gas bottle sizes up to 9kg are recommended for use with your Sovereign BBQ. Approved propane regulators for use with your Sovereign BBQ must have an outlet pressure of 2.75 kpa.
- Page 3 Model, and 140mm in depth for the Alpha Model). For installation purposes, the front mounting centres for the Bravo Model are 394mm, whilst the Alpha Model is 523mm. As for the standard centre and rear mounting options, they attach to your chosen Sovereign BBQ via standard reinforced M10 (metric 10mm) threads located at the rear (two each side, installed vertically, making four threads in total across the back of your BBQ) and middle sides (one each side).
- Page 4 Gas Connection Your Sovereign BBQ is intended for use with propane gas. It is recommended that the gas bottle be secured in an upright position to prevent it from being knocked or falling over. A popular securing option is to run a light chain from the gas bottle to your BBQ, and secure the chain to the BBQ by bolting it to one of the M10 side mounting threads.
- Page 5 (upon final completion of the re-assembly) where the thermocouple screws onto the control valve to ensure no leaks are present. The below diagrams will assist with testing your Sovereign BBQ for any leaks. Phone (Intl +61 7) 3382 0230 • Fax (Intl +61 7) 3382 0087...
- Page 6 Grill Kit If you have purchased a Sovereign BBQ Flat/Grill model, your BBQ will have been supplied complete with a flame disperser. The flame disperser is designed to sit over the burner on the grill half of the plate, and below the BBQ plate itself (see below diagram). When the flame contacts the flame disperser, the flame disperser distributes the flame and heat evenly over the grilling surface.
- Page 7 (5) If ignition does not occur, turn the control knob to the OFF position and wait minimum 60 seconds before trying again. The below diagrams will assist you in lighting your selected Sovereign BBQ. Optimum Cooking Temperatures WARNING: always use the low temperature setting when cooking with the lid closed. The BBQ will reach much greater temperatures with the lid closed.
-
Page 8: Cleaning And Maintenance
To Turn Off (1) Turn the control knob to the OFF position. (2) Always turn the gas supply off at the gas bottle as well. CLEANING & MAINTENANCE BBQ Plate Do not clean your BBQ while hot. Your BBQ plate can be easily removed using the handles on each side (as per the below diagram). - Page 9 (3) Lift the left side of the burner and slide to the left. The below diagrams will assist you in removing the burner from your selected Sovereign BBQ. Phone (Intl +61 7) 3382 0230 • Fax (Intl +61 7) 3382 0087...
- Page 10 (2) Read the “Installation and Operating Instructions” carefully before using the appliance. DISCLAIMER The “Installation and Operating Instructions” are provided on the understanding that: Sovereign BBQ’s are not responsible for the results of any actions taken relying on the information in these instructions, or for any error in or omission from these instructions.
