Dell Power Companion
PW7015MC
User's Guide
Regulatory model: PW7015M

Advertisement

Table of Contents
loading

  Related Manuals for Dell Power Companion PW7015MC

  Summary of Contents for Dell Power Companion PW7015MC

  • Page 1 Dell Power Companion PW7015MC User’s Guide Regulatory model: PW7015M...
  • Page 2 Copyright © 2015 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
  • Page 3: Table Of Contents

    Contents About your power companion ....5 Product features ......5 What’s in the box .
  • Page 4 Statutory information......15 Warranty ......15 Limited warranty and return policies .
  • Page 5: About Your Power Companion

    About your power companion Product features The features of the Dell Power Companion PW7015MC include: Portability You could use your power companion to charge your Dell laptop or mobile devices while on-the-go. Compatibility Supports Dell dedicated PSID (Power Supply Identifier) protocol and select Dell power adapters.
  • Page 6: What's In The Box

    What’s in the box Dell PW7015MC Power Companion Quick Start Guide Power companion Documents Power-in cable Power-out cable Ferrite cores (2) │ What’s in the box...
  • Page 7: Features

    Features Power companion Power-in port (from laptop Power button/Battery-status adapter) button Battery-status lights (5) USB-out ports (2) Power-out port (to laptop) Features │...
  • Page 8: Charging Your Power Companion

    NOTE: The power adapter is not shipped with the power companion. 1. Connect one end of the power adapter of your Dell computer to the power-in cable. Then connect the power-in cable to the power-in port on the power companion.
  • Page 9: Charging Your Device

    Charging your device Charging your laptop 1. Connect one end of the power-out cable to the power-out port on the power companion. 2. Connect the other end of the power-out cable to the power-adapter port on your laptop. 3. Press the power button to start charging your laptop. NOTE: The battery-status light blinks amber when the power companion battery is low.
  • Page 10: Charging Your Mobile Devices

    Charging your mobile devices Using the power companion, you can charge up to two portable devices simultaneously. 1. Connect one end of the USB cable to the USB port on the power companion. 2. Connect the other end of the USB cable to the charging port on your mobile device.
  • Page 11: Checking The Battery

    Checking the battery Checking battery charge status You can check the battery-charge status by pressing the power button. The battery-status lights turn on indicating the battery-charge status of the power companion. NOTE: The battery-status lights remain illuminated for 5 seconds after you release the power button.
  • Page 12: Checking Battery Health

    Checking battery health Battery health is a measurement reflecting the general condition of the battery. It indicates how much battery life remains before the power companion must be replaced. NOTE: The units of SOH (State Of Health) are percentage (%) points. A battery’s SOH is 100% at the time of manufacture and will deteriorate gradually with usage.
  • Page 13: Troubleshooting

    The battery-status light does • Check if the power companion is out not turn on. of battery power. Charge the power companion. • If the problem persists, contact Dell or your dealer for technical assistance. Troubleshooting │...
  • Page 14: Specifications

    Interfaces/Ports Input One 7.4 mm barrel connector (female) One 4.5 mm barrel connector (female) Output One Dell proprietary connector (female) Two USB ports (battery charging 1.2 compliant) Environmental Temperature Operating: 0°C to 40°C (32°F to 104°F) Storage:–20°C to 60°C (-4°F to 140°F) Humidity 90% maximum relative humidity;...
  • Page 15: Statutory Information

    Limited warranty and return policies Dell-branded products carry a 1-year limited hardware warranty. For U.S. customers: This purchase and your use of this product are subject to Dell’s end user agreement, which you can find at http://www.dell.com/terms. This document contains a binding arbitration clause.
