2SHUDWLQJ LQVWUXFWLRQV
IRU :LQWHUKDOWHU *DVWURQRP GLVKZDVKHU *6
&RQWHQWV
1
Intended Use .................................................................................................................... 1
2
Installation and commissioning ....................................................................................... 1
3
Safety Instructions ........................................................................................................... 2
4
Operating And Control Elements ...................................................................................... 3
5
Functioning Of The Dishwasher ......................................................................................... 3
6
Preparation For Washing ................................................................................................... 4
Detergent Dosage ............................................................................................................. 5
7
Washing ........................................................................................................................... 6
Wash Pause...................................................................................................................... 7
8
After Washing.................................................................................................................... 8
9
Maintenance And Care ..................................................................................................... 9
Descaling .......................................................................................................................... 10
13
Faults ................................................................................................................................ 11
14
Emission Values................................................................................................................ 11
Declaration of EU conformity
W
H K
ZLQ
U O
Page
W
H
U
89005828
07/00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winterhalter Gastronom GS 501
Summary of Contents for Winterhalter Gastronom GS 501
- Page 1 2SHUDWLQJ LQVWUXFWLRQV IRU :LQWHUKDOWHU *DVWURQRP GLVKZDVKHU *6 &RQWHQWV Page Intended use ........................1 Installation and commissioning ..................1 Safety instructions ......................2 Operating and control elements ..................3 Functioning of the dishwasher ..................3 Preparation for washing ....................4 Detergent dosage ......................
- Page 2 Any change in design or use of the dishwasher carried out with- out the written permission of Winterhalter Gastronom GmbH, leads to the guarantee and product li- ability becoming null and void. If damage is caused to the dishwasher due to failure to observe the instructions given in this manual, no claims under guarantee can be made to Winterhalter Gastronom GmbH.
- Page 3 Only use detergent and rinse additive which are suitable for industrial dish- washers. We recommend the products developed by Winterhalter Gastronom. These are specially suited to Winterhalter Gastronom dishwashers. All quanti- ties given refer to Winterhalter Gastronom products. Observe danger instruc- tions printed on packaging.
- Page 4 • 7KH GLVKZDVKHU LV VSODVKSURRI 'R QRW VSUD\ WKH RXWVLGH ZLWK D KLJK SUHVVXUH RU VWHDP MHW FOHDQHU • Check the FI-residual current operated device for functioning regularly accor- ding to the regulations by pressing the test button. • In addition to daily cleaning, we recommend that you have the dishwasher ser- viced at least twice a year by Winterhalter customer service.
- Page 5 3UHSDUDWLRQ IRU ZDVKLQJ 2SHQ stop valve of water supply 6ZLWFK on customer’s main switch &KHFN level in rinse additive container and detergent container (only with auto- matic detergent dosage) 5HSODFH or ILOO up empty containers. Observe safety instructions on packaging. Screw standpipe into wash tank with slight turning movement.
- Page 6 With an external detergent dosage pump, please observe the operating instructions belonging to it. 0DQXDO GHWHUJHQW SUHGRVDJH Pour detergent powder into surface strainer with cup. Dosage: Approx. 120g We recommend Winterhalter Gastronom detergent powder. Observe the Winterhalter Gastronom recommended dosage. Observe safety instructions on the detergent packaging. &ORVH hood Wash programme is started.
- Page 7 Programme switch illuminated: wash programme in progress. Programme switch extinguished: wash programme completed. 0DQXDO DGGLWLRQ RI GHWHUJHQW Manual addition of detergent powder must be repeated after approx. every 5 wash cycles. Pour 60g of detergent powder onto the surface strainer. Then start the wash programme.
- Page 8 Programme switch illuminated: wash programme in progress. Programme switch extinguished: wash programme completed. 2SHQ hood. 5HPRYH rack When the hood is opened, the programme switch lights up again briefly and the wash programme switches to standby. As soon as the programme switch is extinguished again (after approx. 5 se- conds), a new programme can be started.
- Page 9 $IWHU ZDVKLQJ 2SHQ hood and remove wash rack. 5HPRYH and FOHDQ surface strainers. 5HPRYH standpipe, tank is drained. 1RWH If the dishwasher is fitted as an optional extra with a drain pump for pumping off the tank water, the white switch must be pressed after removing the standpipe.
- Page 10 Leave hood open. In this way the interior can dry out. • Clean the outer walls of the dishwasher with cleaning products for high grade stainless steel. We recommend Winterhalter Gastronom high-grade stainless steel cleaner and Winterhalter Gastronom high-grade stainless steel protection.
- Page 11 Re-insert parts removed. Clean the outer walls of the dishwasher with cleaning products for high-grade stainless steel. We recommend Winterhalter Gastronom high-grade stainless steel cleaner and Winterhalter Gastronom high-grade steel protector. 'HVFDOLQJ 'UDLQ machine. ,QWHUUXSW detergent supply: 5HPRYH suction pipe from the detergent canister.
- Page 12 )DXOWV )DXOW &DXVH(IIHFW 5HPHG\ Appliance does Customer’s main switch is Switch on customer’s main not start up not switched on switch Dishwasher does Stop valve closed Open stop valve not fill up For machines with drain Press switch. Indicator lamp pump, white switch is must go out.
