Sharp LC-26D4U Service Manual page 91

LC-26D4U
LC-32D4U
LC-37D4U
Ref. No. Part No.
DUNTKD352DE17/18/19 (LC-26/32/37D4U)
AV Unit (Continued)
R2542 VRS-CY1JF103JY
R2543 VRS-CY1JF102FY
R2544 VRS-CY1JF473JY
R2545 VRS-CY1JF102FY
R2546 VRS-CY1JF473JY
R2547 VRS-CY1JF223JY
R2548 VRS-CY1JF223JY
R2553 VRS-CY1JF103JY
R2554 VRS-CY1JF103JY
R2572 VRS-CY1JF102FY
R2573 VRS-CY1JF473JY
R2575 VRS-CY1JF332JY
R2580 VRS-CY1JF473JY
R2581 VRS-CY1JF101JY
R2582 VRS-CY1JF101JY
R2583 VRS-CY1JF101JY
R2584 VRS-CY1JF562JY
R2585 VRS-CY1JF473JY
R2586 VRS-CY1JF104JY
R2700 VRS-CY1JF220JY
R2701 VRS-CY1JF220JY
R2702 VRS-CY1JF220JY
R2703 VRS-CY1JF4R7JY
R2704 VRS-CJ1JF101JY
R2705 VRS-CJ1JF101JY
R2706 VRS-CJ1JF103JY
R2707 VRS-CY1JF105JY
R2708 VRS-CY1JF271JY
R2709 VRS-CY1JF101JY
R2710 VRS-CY1JF152JY
R2711 VRS-CY1JF472JY
R2712 VRS-CY1JF103JY
R2713 VRS-CY1JF220JY
R2715 VRS-CY1JF220JY
R2716 VRS-CY1JF220JY
R2728 VRS-CY1JF4R7JY
R2734 VRS-CY1JF183JY
R2735 VRS-CY1JF103JY
R2738 VRS-CY1JF101JY
R2739 VRS-CY1JF000JY
R2741 VRS-CJ1JF470JY
R2742 VRS-CJ1JF222JY
R2745 VRS-CY1JF5R1JY
R2746 VRS-CY1JF220JY
R2747 VRS-CY1JF101JY
R2748 VRS-CJ1JF101JY
R2750 VRS-CY1JF102JY
R2751 VRS-CY1JF472JY
R2752 VRS-CY1JF102JY
R2753 VRS-CY1JF473JY
R2756 VRS-CY1JF183JY
R2759 VRS-CY1JF273JY
R2760 VRS-CY1JF273JY
R2761 VRS-CY1JF221JY
R2762 VRS-CY1JF221JY
R2763 VRS-CY1JF472JY
R2764 VRS-CY1JF472JY
R2765 VRS-CY1JF472JY
R2766 VRS-CY1JF472JY
R2767 VRS-CY1JF472JY
R2769 VRS-CY1JF221JY
R2770 VRS-CY1JF183JY
R2771 VRS-CY1JF222JY
R2772 VRS-CY1JF221JY
R2773 VRS-CJ1JF223JY
R2775 VRS-CY1JF101JY
R2782 VRS-CY1JF220JY
R2783 VRS-CY1JF220JY
R2784 VRS-CY1JF220JY
R2785 VRS-CY1JF220JY
R2925 VRS-CY1JF561JY
R2926 VRS-CY1JF561JY
Description Code
J 10k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 3.3k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 5.6k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 100k 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 4.7 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 1M 1/16W Metal Oxide AA
J 270 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 1.5k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 4.7 1/16W Metal Oxide AA
J 18k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 47 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 5.1 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 18k 1/16W Metal Oxide AA
J 27k 1/16W Metal Oxide AA
J 27k 1/16W Metal Oxide AA
J 220 1/16W Metal Oxide AA
J 220 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 220 1/16W Metal Oxide AA
J 18k 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 220 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 560 1/16W Metal Oxide AA
J 560 1/16W Metal Oxide AA
Ref. No. Part No.
R2927 VRS-CY1JF561JY
R2938 VRS-CY1JF102JY
R2939 VRS-TV1JD750JY
R2940 VRS-TV1JD750JY
R2941 VRS-TV1JD750JY
R2949 VRS-CY1JF000JY
R2950 VRS-CY1JF000JY
R2951 VRS-CY1JF000JY
R3057 VRS-CY1JF472JY
R3059 VRS-CY1JF103JY
R3060 VRS-CY1JF103JY
R3062 VRS-CY1JF000JY
R3101 VRS-CY1JF473JY
R3102 VRS-CY1JF473JY
R3103 VRS-CY1JF473JY
R3104 VRS-CY1JF473JY
R3105 VRS-CY1JF473JY
R3127 VRS-CY1JF000JY
R3128 VRS-CY1JF000JY
R3130 VRS-CY1JF000JY
R3131 VRS-CY1JF000JY
R3133 VRS-TV1JD101JY
R3135 VRS-TV1JD101JY
R3801 VRS-CY1JF101JY
R3802 VRS-TV1JD750JY
R3804 VRS-TV1JD750JY
R3805 VRS-CY1JF103JY
R3806 VRS-CY1JF101JY
R3807 VRS-CY1JF101JY
R3808 VRS-CY1JF101JY
R3809 VRS-TV1JD750JY
R3810 VRS-CJ1JF101JY
R3812 VRS-CY1JF000JY
R3815 VRS-CY1JF101JY
R3820 VRS-CY1JF000JY
R3826 VRS-CY1JF000JY
R3827 VRS-CY1JF000JY
R3832 VRS-CJ1JF470JY
R3833 VRS-CY1JF101JY
R3835 VRS-CY1JF000JY
R3839 VRS-CY1JF333JY
R3840 VRS-CY1JF473JY
R3843 VRS-CY1JF101JY
R3847 VRS-CY1JF220JY
R3848 VRS-CY1JF220JY
R3849 VRS-CY1JF220JY
R3852 VRS-CY1JF101JY
R3853 VRS-CY1JF101JY
R3854 VRS-CY1JF473JY
R3855 VRS-CY1JF473JY
R3856 VRS-CY1JF000JY
R3857 VRS-CY1JF331JY
R3858 VRS-CY1JF820JY
R3859 VRS-CY1JF331JY
R3860 VRS-CY1JF820JY
R3861 VRS-CY1JF000JY
R3862 VRS-CY1JF820JY
R3863 VRS-CY1JF331JY
R3864 VRS-CY1JF000JY
R3865 VRS-CY1JF000JY
R3866 VRS-CY1JF000JY
R3868 VRS-CY1JF103JY
R3881 VRS-CY1JF220JY
R3882 VRS-CY1JF220JY
R3883 VRS-CY1JF220JY
R3919 VRS-CY1JF102JY
R3922 VRS-CY1JF223JY
R3924 VRS-CY1JF473JY
R3926 VRS-CY1JF222JY
R3930 VRS-CY1JF682JY
R3932 VRS-CY1JF103JY
R3933 VRS-CY1JF223JY
R3934 VRS-CY1JF101JY
R3935 VRS-CY1JF101JY
R3938 VRS-CY1JF103JY
R3939 VRS-CY1JF223JY
112
Description Code
J 560 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 4.7k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 75 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 47 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 33k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 330 1/16W Metal Oxide AA
J 82 1/16W Metal Oxide AA
J 330 1/16W Metal Oxide AA
J 82 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 82 1/16W Metal Oxide AA
J 330 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 6.8k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
