Instructions for Installation and Use
7kg Condenser Dryer
Ultima
CTD90
CTD95
To the Installer:
Before installation, fill in the product details on the back cover of this
book. The information can be found on the rating plate.
To the User:
You must read these instructions prior to installing and using the
appliance and then retain them for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint CTD90
Summary of Contents for Hotpoint CTD90
- Page 1 Instructions for Installation and Use 7kg Condenser Dryer Ultima CTD90 CTD95 To the Installer: Before installation, fill in the product details on the back cover of this book. The information can be found on the rating plate. To the User: You must read these instructions prior to installing and using the appliance and then retain them for future reference.
-
Page 2: Important Information
Important Information For your Condenser dryer to operate efficiently, you must follow the regular maintenance schedule shown below: Fluff filter... ! You MUST clean the fluff filter after EVERY drying cycle. STEP 1. STEP 2. STEP 3. STEP 4. Open the door of your Pull out the filter (using Clean any fluff deposits Refit the filter - NEVER... - Page 3 Important Information Condenser Unit... ! You MUST clean the fluff from the condenser EVERY month. STEP 3. STEP 4. STEP 1. STEP 2. Flush the condenser, from Refit the condenser unit Open the condenser cover Remove the condenser by - hold the handle and rotating the 3 clips then the rear with water, to - ensure that the unit is...
-
Page 4: Table Of Contents
Dryer description, 6 To open the door The features Control panel Start and programmes, 7-9 Choosing a programme Table of programmes The controls CTD90 Option buttons / icons CTD95 Display Door Opening Laundry, 10-11 Sorting your laundry Wash care labels... -
Page 5: Installation
Installation Where to put your dryer Electrical connections Make sure of the following before you insert the plug Place your dryer at a distance from gas ranges, into the the electrical socket: stoves, heaters, or cook tops because flames can The socket must be grounded. -
Page 6: Dryer Description
Dryer Description To open the door The features Rating plate Press and release the front Water container panel in position shown Model & Serial numbers Air intake Condenser Unit grille Condenser cover (cover open) Filter Condenser cover handle (Pull to open) Control panel START/CANCEL On/Off... -
Page 7: Start And Programmes
Start and Programmes 10. Press the START button to begin. The display will Choosing a programme show the estimated time to end. Plug the dryer into the electrical socket. During the drying programme, you can check on 2. Sort your laundry according to fabric type (see your laundry and take out items that are dry Laundry). -
Page 8: Display
Start and Programmes Programmes ! If the On/Off light is not lit; Press the ON/OFF button and then select programme. Programme What it does... How to set it... Note: 1. Press the Cottons - High Heat button. Options available: Cottons Dries your Cotton 2. -
Page 9: The Controls
Start and Programmes The Controls The time to end is displayed in hours ! Warning, after pressing the start button, the and minutes and counts down each programme cannot be changed. minute, this time includes the cool tumble phase, the ! ON/OFF button : press this button and you pause heat setting HIGH or LOW is also shown. -
Page 10: Laundry
Laundry Sorting your laundry Wash Care Labels Check symbols on clothing labels to make sure Look at the labels on your garments, especially when that the articles can be tumble dried. tumble drying for the first time. The following symbols Sort laundry by fabric type. -
Page 11: Special Clothing Items
Laundry Dryness: If you are going to iron some of your Special clothing items clothes, they can be taken out while still a bit damp. Others can be left longer if you need them Blankets and Bedspreads: acrylic items (Acilan, to be completely dry. -
Page 12: Warnings And Suggestions
Warnings and Suggestions Do not tumble dry large, very bulky items. ! The appliance has been designed and built according Do not tumble dry acrylic fibres at high temperatures. to international safety standards. Complete each programme with its Cool Tumble Phase. These warnings are given for safety reasons and must Do not turn off the dryer when there are still warm be followed carefully. -
Page 13: Maintenance And Care
Maintenance and Care Switching off the electricity Empty the water container after each cycle ! Unplug your dryer when not using it, when cleaning it and during all maintenance operations. Pull the container out of the dryer and empty it into a sink or other suitable drain. -
Page 14: Troubleshooting
Troubleshooting One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the following troubleshooting suggestions: Problem: Possible causes / Solution: The tumble dryer won’t start. The plug is not plugged into the socket, or not making contact. There has been a power failure. -
Page 15: Service
Service Before calling the Service Centre: Spare Parts Use the troubleshooting guide to see if you can This dryer is a complex machine. Repairing it yourself solve the problem yourself (see Troubleshooting). or having a non-authorised person try to repair it could If not, turn off the dryer and call the Service cause harm to one or more persons, could damage Centre closest to you. -
Page 16: After Sales Service
Republic of Ireland: 0123 002 333 Genuine Parts and Accessories UK: 08709 077 077 Monday to Friday, 8.30am to 5pm Saturday, 8.30am to 12noon www.hotpointservice.co.uk Republic of Ireland: 0818 313 413 www.hotpoint.co.uk Indesit Company UK Limited, Morley Way, Peterborough, PE2 9JB...
