- Page 1 VX820 P r o f e s s i o n a l A u d i o C a r d U s e r ’ s m a n u a l...
- Page 2 No portion of this manual may be reproduced without prior written consent from Digigram. The copyright protection claimed here includes photocopying, translation and/or reformatting of the information contained in this manual. Digigram is not responsible for errors and odmissions and reserves the right to make improvements or changes without prior notice.
- Page 3 VX820 User’s Manual OVERVIEW Features · Audio card for PCI bus. · 2 analog mono inputs. · 1 digital stereo input. · 8 analog mono outputs. Software requirements Hardware requirements · WAVE VX driver V2.20 or · One card slot, PCI 2.1 compliant.
- Page 4 SCHEMATIC DIAGRAM...
- Page 5 VX820 User’s Manual LAYOUT AND CONNECTIONS VX820 VX820 Switches position Up = OFF Down = ON CONNECTORS J1 - Analog Audio connector. (High density SubD 62, female) - optional breakout cable available on request. SJ2 and J3 - Reserved - Do not use...
-
Page 6: Audio Inputs
SWITCHES SW1 - Input impedance SW2 - Reserved - All switches must be "ON" DETAILLED FEATURES Audio inputs Analog line inputs · 2 balanced analog line inputs (can be used with unbalanced signals). · Maximum input level available +22dBu · switch selectable input impedance : 600O or >10 kO ·... - Page 7 VX820 User’s Manual ANALOG PERFORMANCES Sampling frequencies · 8, 11.025, 16, 22.05, 24, 32, 44.1, 48 kHz available Characteristics measured at 48 kHz sampling frequency, record + playback in linear. · Signal / Noise ratio (un-weighted) : better than 88 dB.
- Page 8 Digigram S.A France E-mail : info@digigram.com Digigram Inc. USA E-mail : input@digigram.com Digigram Asia Pte Ltd E-mail : info_asia@digigram.com www.digigram.com DU 145100101 IS=B...
