Page 1: User Manual
Network Video Recorder User Manual Model: FN3004H Model: FN3004H Color: Black Color: White Model: FN3104H/FN3109H Version:V1.3...
Page 2: Table Of Contents
2.1.1 Package Contents........................ 11 2.1.2 Installing the HDD.........................11 2.1.3 Device Structure........................13 2.1.4 IR Remote Control Description(Only FN3104H)............. 15 2.1.5 Device Connection....................... 16 2.2 FN3004H............................17 2.2.1 Package Contents........................ 17 2.2.2 Device Structure........................18 2.2.3 Device Connection....................... 19 2.3 USB Mouse Operation........................20 3 GUI.................................
Page 3 5 Appendix............................... 96 5.1 HDD Capacity Calculation......................96 5.2 Common operations........................97 5.3 Specifications..........................102 5.4 List of Third-party list........................107 5.5 FAQ..............................108 5.6 Glossary............................110 5.7 CE & FCC............................111 5.8 WARRANTY............................ 112 5.9 Obtaining Technical Support......................115 www.foscam.com...
Page 4: Security Warning
NVR User Manual Security Warning Foscam cameras and NVRs require good security practices to safeguard your privacy. You should regularly change your camera or NVR password which is 8-10 numbers, letters, symbols combination. You should update your camera or NVR regularly.Make sure your camera or NVR has the latest firmware installed for your specific model and better experience.
Page 5: Preface
 Because the actual environment may be discrepant, the actual values of some data may be different from the values provided in the manual. If there are any question or dispute, the final interpretation of FOSCAM prevails.  If you do not follow the manual during operation, you will bear any loss caused thereof.
Page 6: Important Safety Instructions
 Please press power button to shut down the NVR instead cutting off the power directly to avoid to damaged the storage device.  Do not take the device apart when it is operating(or connecting to power).  Ensure power cable corresponds to the model of the NVR which produced by Foscam. www.foscam.com...
Page 7: Overview
You can select the scheduled time segment to enable or disable recording.  Manual Recording You can manual enable recording in the corresponding channel.  Alarm Recording Alarm recording is classified into I/O alarm recording and motion detection recording. - I/O Alarm Recording(FN3004H does not supports this function) www.foscam.com...
Page 8: Ipc Management
When an object moves in the detection time segment and detection area, an alarm is triggered, the NVR system enables motion detection recording, and the alarm output device outputs the alarm(Except FN3004H), sends pictures to your mailbox, and uploads pictures to your FTP server.
Page 9: Relevant Version
You are recommended to equip a 7200 rpm or higher HDD. You are recommended to equip a 16:9 monitor with the resolution Monitor higher than 1280*720. You are recommended to equip Foscam IPC or IPC supporting ONVIF protocol. Network 10/100M Ethernet or above.
Page 10: Icons Description
Exit current menu to upper level menu. Common Operations Starting Up the NVR Turn on the power switch on the rear panel(Except FN3004H). The Power indicator LED should turn green indicating that the device begins to start up. Note If the power LED indicator on the front panel is off, please check if the power supply is plugged into an electrical outlet and the power switch is turned on;...
Page 11 NVR.  Local GUI: Choose “Menu > System” in the Menu interface, then click Factory Reset in the System interface.  Web GUI: Choose “ (Parameter Configuration) > System Management > Factory Reset”. The Factory Reset page is displayed. www.foscam.com...
Page 12: Device
7200 RPM. But Do not buy a HDD with automatic sleep function, so as to maintain reliable and stable running of the disks. It is highly recommended to use FOSCAM IPC, or the other IPC which supports ONVIF ...
Page 13 Connect one end of the data cable and power cable to the motherboard of NVR and the other end to the HDD. Place the HDD on the bottom of the device using the provided screws and then fasten the screws on the bottom to fix the HDD. Re-install the cover of the NVR and fasten screws. www.foscam.com...
Page 14: Device Structure
The red LED is on: The HDD is not installed or cannot be detected. Blinks green: The HDD is writing, the NVR is recording. The green LED is on: The HDD is in the normal status and the NVR does not record. www.foscam.com...
Page 15: Rear Panel
1 matches channel 1. When an external power supply is used to power the alarm input device, the alarm input device needs to share the ground with the NVR. Ground terminal for alarm input. www.foscam.com...
Page 16: Ir Remote Control Description(Only Fn3104H)
Enter the shortcut menu of setting interface. It is used with direction keys. Enable or Disable channel touring according to the touring settings; Press the ESC button to stop. Manageme Enter the IPC Management interface, it is used with direction keys. www.foscam.com...
Page 17: Device Connection
Play/Pause key. Next key Play the next video file. Fast Multiple fast forward speeds and normal forward key playback. Play/Pause During pause, press the key to play. During play, press the key to pause. 2.1.5 Device Connection www.foscam.com...
Page 18: Fn3004H
Plug USB mouse into one of the USB interfaces of the NVR. Connect to the Storage device Plug USB Storage device into one of the USB interfaces of the NVR. FN3004H 2.2.1 Package Contents When you receive the NVR, please open the box and check whether there is any visible...
Page 19: Device Structure
● DC Power Adapter ● Quick Installation Guide ● Warranty Card The package contents list does not contain a mobile hard disk, IPC and mouse for FN3004H.  It is highly recommended that the Mobile Hard Disk should be used with Seagate and Westeam Digital and over 5400 RPM for FN3004H.
Page 20: Device Connection
Universal Serial Bus (USB) ports for additional devices such as USB mouse and USB Storage device. POWER Status The Power LED on the front panel will light in green Indicators after complete the wiring. Power Supply 5VDC power supply. 2.2.3 Device Connection www.foscam.com...
Page 21: Usb Mouse Operation
Plug USB mouse into one of the USB interfaces on the rear panel of the NVR. The mouse should automatically be detected. The operation of the mouse: Name Action Description Left-Click Single-Click Menu or window: select and enter. Double-Click Preview mode or Playback mode: Switch between single-screen and multi-screen. www.foscam.com...
Page 22 Time or Area box: Select the time or zone range. Drag Time bar: Drag time bar. Right-Click Single-Click Live view: Show menu. Menu: Exit current menu to upper level menu. Note The Single-Click mentioned in this article is refer to the left mouse click. www.foscam.com...
Page 23: Gui
The Setup Wizard can walk you through some important settings of the NVR. If you don’t want to use the Setup Wizard at that moment, right click the mouse to quit. For the operation, please refer to the Quick Installation Guide. Shortcut Menu After login, right-click the mouse, you will enter the shortcut menu. www.foscam.com...
Page 24: Color Settings
Color Settings Click Color Settings to choose a channel to alter the color, then adjust the parameters of hue, brightness, contrast, saturation and sharpness. Playback You can display the video of every a channel for playback. For details, see "3.4.2 www.foscam.com...
Page 25: Manual Record
Manual Record Click Manual Record to set manual record for single channel or all channels. Note:Only FN3109H supports 9 channels, but FN3104H and FN3004H support 4 channels. 【Enable Manual Record】 Check the Channel checkbox, Click OK button to take effect.
Page 26: Menu
: Start cruise. : Stop cruise. Shutdown Click Shutdown to enter the Shutdown page. You can log out, reboot or shut down the NVR system. Menu Right-click in live view mode and select Menu from the Shortcut Menu, the Menu www.foscam.com...
Page 27: Adding Devices
IP Camera List, and you can configure the basic setting of the IP cameras. Note Before adding the IP Camera, make sure that the IP Camera supports FOSCMA or ONIVF protocol. And you have the username, password and port number of the IP camera. www.foscam.com...
Page 28 If you did not find the online IP Camera which you want to connect, please click Refresh button to find the online IP Camera. Adding IP Camera 1． Select the IP Camera in the IPC Manager list. 1.Select the IPC 2.Click Add button www.foscam.com...
Page 29 NVR's. Select the protocol for the different IPC.  FOSCAM protocol: The High Denition(HD) IP Camera of foscam brand.  MJ protocol: The Standard Denition(SD) IP Camera of foscam brand.
Page 30 You can select the Channel and Protocol. Input the IP Address, Username, Password, HTTP Port and Media Port. Then click OK button to finish adding. And the camera and its information will be added in the list of cameras. Click OK button to www.foscam.com...
Page 31: Playback
9 channels, but you can select up to four channels for playback at the same time.) 3: Click Search button to search the matched recorded files. If there are search results, then they will be shown in the time bar area. Click the icon to play the recording video. www.foscam.com...
Page 32 For example, “<< X4” indicates the current fast backward speed is four times of the normal speed. Frame forward. View the image of each frame. 5:Playback time and maximized video playback Button Description Zoom-in time axis. Left moving time axis. www.foscam.com...
Page 33: Backup
Set the log search conditions to refine your search, including the Type, Channel, Date and time of the recording. Then click Search button to search the matched recorded files. If there are search results, then they will be shown in list. 【 Backup Record】 www.foscam.com...
Page 34: Device Information
2014-3-20 17:09:34 and 17:11:21. When searching for the recording information, you can also select "backup page" or "backup all" to achieve bulk backup. 3.4.4 Device Information Choose ”Menu > Device Information” in the Menu interface. The Device Information interface is displayed. www.foscam.com...
Page 35: Firmware Version
Choose ”Menu > About > Firmware Version” in the Menu interface. The Firmware Version interface is displayed. You can view the Device Type, Device Name, Firmware Version and Application Version. HDD Info Choose ”Menu > About > HDD Info” in the Menu interface. The HDD Info interface is www.foscam.com...
Page 36: System Log
Choose ”Menu > About > System Log” in the Menu interface. The System Log interface is displayed. The operation, alarm, exception and information of the NVR can be stored in log files, which can be viewed and exported at any time. www.foscam.com...
Page 37: Settings
20140320-134022_01.log indicates that a log is generated at 2014-3-20 13:40:22. When searching for the log information, you can also select "backup page" or "backup all" to achieve bulk backup. 3.4.5 Settings Choose ”Menu > Settings” in the Menu interface. The Settings interface is displayed. You www.foscam.com...
Page 38 Choose ”Menu > Settings > General” in the Menu interface. The General interface is displayed. You can configure the basic information of the NVR. NOTE Please do not modify the NVR system time when recording. Parameter Description Device Name You can modify your device name to help you identify it. www.foscam.com...
Page 39 Click Save button to take effect. Stream Choose ”Menu > Settings > Stream” in the Menu interface. The Stream interface is displayed. You can configure the encoding scheme parameters of the IP Camera, the NVR system will synchronize your IP camera with encoding scheme. www.foscam.com...
Page 40 Normally, when the frame rate above 15, you can achieve fluently video. The time between last key frame and next key frame. The shorter Key Frame the duration, the more likely you will get a better video quality, but Interval at the cost of higher network bandwidth consumption. www.foscam.com...
Page 41 4． Click and drag the mouse in the relative positions. The selected area is red. 5． Click Save button to take effect for one certain channel. The icon indicate starts schedule recording at the right bottom of the screen for certain channel. 【 Disable Schedule Recording】 1． Select channel from drop-down box list. www.foscam.com...
Page 42 If select the DHCP, NVR system will automatically obtain an IP address and Type other network settings from that server. If select the Static IP, you can configure an IP address and other network settings. HTTP Port The default value is 88. HTTPS Port The default value is 443. www.foscam.com...
Page 43 Check the DDNS checkbox, you can configure the DDNS information of the NVR. The FOSCAM NVR has embedded a unique DDNS domain name when producing, and you can directly use the domain name, you can also use the third party domain name.
Page 44 The system can be configured to send an email to the designated users if an alarm or motion event is detected etc.. Before configuring the Email settings, the NVR must be connected to a local area network (LAN) that maintains an SMTP mail server. www.foscam.com...
Page 45 The user account of sender ’s Email for SMTP server authentication. SMTP Password The password of sender ’s Email for SMTP server authentication. Sender The Email address of sender. Receiver The Email address of user to be notified. you can set 4 receivers www.foscam.com...
Page 46 Default port is 21.You can also change this port manually FTP Port through FTP server. FTP Mode Here supports two modes: PORT and PASV. FTP Username The user account of FTP server. FTP Password The user password of FTP server. Click Save button to take effect. www.foscam.com...
Page 47: Alarm Settings
Configure the sensitivity of the mouse. Alarm Settings 【 External Alarm】 Note:FN3004H do not support the External Alarm function. Choose ”Menu > Settings > Alarm Settings > External Alarm” in the Menu interface. The External Alarm interface is displayed. www.foscam.com...
Page 48 You can choose a week, one day of a week, the certain time period for the motion detection alarm. 2． Check Select checkbox to select the area. 3． Drag and draw the area for motion detection by left mouse. Note:Check Clear checkbox and If you clear the area, then drag and draw the area by www.foscam.com...
Page 49 Note: Make sure you have set Email. When the IO Alarm is triggered, you can choose whether to upload detection picture to FTP server. Note: Make sure you have set FTP. Check the checkbox to start recording for the certain channel. Linkage Record www.foscam.com...
Page 50: Motion Detection
In this chapter, you can follow the steps to schedule a record which triggered by the detected motion. Choose ”Menu > Settings > Alarm Settings > Motion Detection” in the Menu interface. The Motion Detection interface is displayed. Step1 Select channel from drop-down box list. www.foscam.com...
Page 51 Alarm Output Note: Make sure you have installed the alarm output device. FN3004H do not support Alarm Output function. When the Motion detection is triggered, you can choose whether to send e-mail. Send E-Mail Note: Make sure you have set Email.
Page 52 Note: You must set the detection area and detection schedule, or else there is no alarm anywhere and anytime. -------End 【 Other Alarm】 Choose ”Menu > Settings > Alarm Settings > Other Alarm” in the Menu interface. The Other Alarm interface is displayed. You can configure the HDD(Hard Disk Drive) information. www.foscam.com...
Page 53 Check the Buzzer checkbox if you want to enable buzzing Buzzer sound of the NVR device. Click Save button to take effect. Choose ”Menu > Settings > OSD” in the Menu interface. The OSD interface is displayed. You can configure the OSD(On Screen Display) information. www.foscam.com...
Page 54 Check the Enable Mask checkbox to enable OSD function. 【Set Shelter Area】 If the IPC device type is MJ or IPC protocol type is ONVIF, the feature is invalid. 1． Click Select Shelter Area button and it pop up a window. www.foscam.com...
Page 55: System
Click Save button to take effect. 3.4.6 System Choose ”Menu > System” in the Menu interface. The System interface is displayed. You can manage the NVR device about User Account, Upgrade, Factory Reset, Para export, Auto Restore, Log Out, Reboot, Shutdown. www.foscam.com...
Page 56: User Account
The administrator has the permission to add and delete all users and configure user parameters. You can add, modify, delete username/password or distribute authority for users. The valid value range of Username and Password is 1 ~ 20 characters, it contains the English letter, numeric and symbol. www.foscam.com...
Page 57 Don’t shut down the power during upgrade. After upgrading, you can see the upgrade result. Factory Reset Choose ”Menu > System” in the Menu interface, then click Factory Reset in the System interface. Click OK button in the pop-up message box and all parameters will return to factory www.foscam.com...
Page 58: Log Out
Choose ”Menu > System” in the Menu interface, then click Log Out in the System interface. Click OK button in the pop-up message box, the NVR system will log out. www.foscam.com...
Page 59 Click OK button in the pop-up message box, the NVR system will shut down. It is recommended that cut off the power after shut down. You can start up/shut down the NVR by the IR Remote Control(Only FN3104H). www.foscam.com...
Page 60: Web
Log in to the Web client of the NVR. You can directly enter the IP address and port in the browser or search out the NVR by using the FOSCAM search tool. Here we take FOSCAM search tool as an example.
Page 61 It will pop up the message below the page, as shown in the following figure. Click Install button to install the add-on. Please follow the installation instructions. (Please close the browser during installation.） Step5 After installing the add-on, refresh the browser and enter the login interface. www.foscam.com...
Page 62 When you log in for the first time, it will come to the operating of modify the username and password automatically.Enter the New Username, New password and Confirm the password. Step8 Click Modify button, you will see the Live View interface of the NVR client. -------End www.foscam.com...
Page 63: Live Video
Configuration, User Management, System Management in the Parameter Configuration interface. Playback Play back the recorded video files of a specific channel in the live view mode. Logout Disconnect the link between the client page of the current browser and the NVR server. www.foscam.com...
Page 64 In channels of the NVR, you can add IPC devices. The FN3109H supports 9 channels, the FN3104H and FN3004H support 4channels. Note: If you need to display nine channels IPC device on the live view window, the sub stream of each IPC must be less than 720P.
Page 65 Horizontal: The IP camera will rotate from left to right. : Start cruise. : Stop cruise. If you want to define or change the cruise trace, please go to “Parameter Configuration > Service configuration > Preset Settings”. 【 How to do cruise?】 www.foscam.com...
Page 66: Parameter Configuration
If you want to see one preset position you have set, only select the preset position name from the preset drop-down list, and click button, the IP camera will go to the preset position. Parameter Configuration Choose ” (Parameter Configuration)”, you can configure the Local Settings, Settings, Service Configuration, User Management, System Management and so on. www.foscam.com...
Page 67: Local Settings
Click Save button to take effect. System Time You can configure the date and time of the NVR. Step1 Choose ” (Parameter Configuration) > Local settings > System Time”. The System Time page is displayed. Step2 Configure the system time of the NVR. www.foscam.com...
Page 68 NVR system with your computer. Date Format Select the date format from the drop-down list. Time Format Select the time format from the drop-down list. Step6 Click Save button to take effect. -------End Network You can configure the network information of the NVR. www.foscam.com...
Page 69 LAN. Subnet Mask The subnet mask of the NVR system. Gateway The gateway of the NVR system. Primary DNS The primary DNS server of the NVR system. Server Alternative The secondary DNS server of the NVR system. www.foscam.com...
Page 70 (LAN) that maintains an SMTP mail server. The network must also be connected to either an intranet or the Internet depending on the location of the e-mail accounts to which you want to send notification. Step1 Choose ” (Parameter Configuration) > Local settings > Email”. The Email page is displayed. www.foscam.com...
Page 71 NVR User Manual Step2 Configure the Email parameter. www.foscam.com...
Page 72: Ftp Settings
The system can be configured to send an picture to the FTP server if an alarm or motion event is detected etc.. Step1 Choose ” (Parameter Configuration) > Local settings > FTP Settings”. The FTP Settings page is displayed. www.foscam.com...
Page 73 If the test success, you can see the success information. -------End DDNS The FOSCAM NVR has embedded a unique DDNS domain name when producing, and you can directly use the domain name, you can also use the third party domain name. Choose ”...
Page 74 Video Encode Choose ” (Parameter Configuration) > Local settings > Video Encode”. The Video Encode page is displayed. You can configure the encoding scheme parameters of the IP Camera, the NVR system will synchronize your IP camera with encoding scheme. www.foscam.com...
Page 75 The time between last key frame and next key frame. The shorter the Key Frame duration, the more likely you will get a better video quality, but at the Interval cost of higher network bandwidth consumption. Click save button to take effect. www.foscam.com...
Page 76: Device Management
LAN with NVR, you may add it in one button with IP Camera’s user name, password and port number. 【Auto Adding IPC】 Choose ” (Parameter Configuration) > Device Management > IP Camera Setup”. The www.foscam.com...
Page 77: Hard Disk Information
Choose the IP Camera in the list of ‘The Current LAN IPC List’ . Choose the Protocol from the drop list. Input the Username and Password of the IPC. Select the FOSCAM protocol for Foscam brand IPC, and select the ONVIF protocol for other brands IPC.
Page 78 (Parameter Configuration) > Device Management > Storage Location”. The Storage Location page is displayed. Snapshot Pictures To: Click the icon (Take Snapshot) in the Real time Preview page or Playback page, the snapshot picture will be saved to the Snap Picture Path in the local computer. www.foscam.com...
Page 79: Service Configuration
 The Icon indicate the IPC is recording. You can follow the steps to schedule a record which triggered by the detected motion. Choose ” (Parameter Configuration) > Service Configuration > Motion Detection”. The Motion Detection page is displayed. www.foscam.com...
Page 80 The higher the sensitivity, the NVR will be more easily alarmed. The Detection Interval time between two motion detection. Step4 Check the checkbox to select the linkage method. You may refer to follow table for details of linkage methods. www.foscam.com...
Page 81 When the IO Alarm is triggered, you can choose whether to alarm via the alarm output device. Notes: Alarm output FN3004H do not support Alarm output function. Make sure you have installed the alarm output device. When the Motion detection is triggered, you can choose whether to send e-mail.
Page 82 You can choose a week, one day of a week, the certain time period for the motion detection alarm.  Choose all Time Period Click the black button up the MON, you will see all time range turn red. When something moving in the detection area at anytime, the NVR will alarm. Click here www.foscam.com...
Page 83 NVR will alarm and adopt the corresponding alarm linkage. Note: You must set the detection area and detection schedule, or else there is no alarm anywhere and anytime. -------End Schedule You can enable or disable schedule record for the every channel. www.foscam.com...
Page 84 Click Save button to take effect. -------End External Alarm Note:FN3004H do not support the External Alarm function. External alarm input devices (such as door status sensor, infrared sensor, and smoke sensor) are connected through the alarm input interface and external alarm output devices (such has local audible alarm and visual alarm) are connected through the alarm output interface.
Page 85 Select the Alarm Input interface from Alarm Input drop-down box list. Step3 Check the Enable checkbox to enable IO Alarm function. Step4 Set the Duration from drop-down box list. Step6 Check the checkbox to select the linkage method. You may refer to follow table for details of linkage methods. www.foscam.com...
Page 86 Step1 Choose “ (Parameter Configuration) > Service Configuration > Other Alarm”,The Other Alarm page is displayed. Step2 Select Type form drop-down box list. Step3 Check the Buzzer checkbox if you want to enable buzzing sound of the NVR device. www.foscam.com...
Page 87 Step3 You can configure the privacy zone settings for the camera. Check the Enable Privacy checkbox and it pop up a window. If the IPC device type is MJ or IPC protocol type is ONVIF, www.foscam.com...
Page 88 (Parameter Configuration) > Service Configuration > Cruise Settings”. The Cruise Settings page is displayed. There are two default cruise tracks: Vertical and Horizontal. Vertical: The IP Camera will rotate from up to down   Horizontal: The IP Camera will rotate form left to right. www.foscam.com...
Page 89 Add button, you can see the preset point has been added to the cruise track on the cruise track page. You need to add two or more preset points to the cruise track. How to customize the preset, please refer to “4.3 Live Video > Preset settings”. www.foscam.com...
Page 90 1．Select channel from drop-down box list. 2．Select the track from the Cruise Tracks. 3．Click Delete button to delete the cruise track. You can see the cruise track which you want to query. Note:The default cruise track cann’t be deleted. www.foscam.com...
Page 91: User Management
4． Click Save button to save the settings and the added new user will be displayed on the list. 【 Changing Password of Admin】 1． In the Password text field, delete the old password, input the new password. 2．Click Save button to take effect. www.foscam.com...
Page 92: System Management
NVR device will reboot automatically. Note  Do not disturb the update process by turning off the power. All current settings will be overwritten when importing a configuration file. If a bad  configuration file is uploaded the NVR may not work. www.foscam.com...
Page 93 Patch Installation Choose ” (Parameter Configuration) > System Management > Patch Installation”. The Patch Installation page is displayed. You can install or install patch of the NVR. Click Browse to select the patch file in the local directory. www.foscam.com...
Page 94 Click Reboot button, then click OK button in the pop-up message box.The NVR system will reboot. Auto Restore Choose ” (Parameter Configuration) > System Management > Auto Restore”. The Auto Restore page is displayed. You can configure the Date and Time. The NVR system will be maintained at the setting time. www.foscam.com...
Page 95: Playback
32 times of the normal playing speed. Click this button. The multiple of normal playing speed is displayed in the upper right corner of the playback page. For example, “<< X4” indicates the current fast backward speed is four times of the normal speed. www.foscam.com...
Page 96 Full screen. Make the playing video maximized. After the video is maximized, press ESC to exit full screen. 4： Playback time You can move the mouse to a specific time axis and click to watch the playback. Icon Description Zoom-in time axis. Zoom-out time axis. www.foscam.com...
Page 97: Appendix
【 Example】 If you select 4M for the bit rate and select four channels for recording and one week of recording is needed, you can calculate the HDD capacity by using the following formula: Recording time（ hour） =7days*24 hours=168 hour www.foscam.com...
Page 98: Common Operations
User can also use third part DDNS, such as www.no-ip.com, www. 3322.com Here take www.no-ip.com for example: ① Step 1, Go to the website www.no-ip.com to create a free hostname Firstly: Login on www.no-ip.com and click No-IP Free to register. www.foscam.com...
Page 99 NVR User Manual Click here to register . Figure 4.27 Please register an account step by step according to instructions on www.no-ip.com. After registration, please login your email which used to register. You will receive an email from website, www.foscam.com...
Page 100 Secondly: Login the link with the registered username and password to create your domain name. Figure 4.28 Please create the domain name step by step according to instructions on www.no-ip.com Step 2, DO DDNS Service Settings within the NVR www.foscam.com...
Page 101 NOTE : If you have set Third Party DDNS successfully ,the Foscam Domain Name will be invalid. The Third Party DDNS and the Foscam Domain Name cannot work at the same time, the last time you configured will take effect.
Page 102 The IP address of the NVR must be in the range of the router address pool.  Log in to the router client through the browser and select “DHCP server > DHCP service”. On the DHCP page, you can view the start address and end address of the address pool. www.foscam.com...
Page 103: Specifications
4-ch 720P/960P HD IP Camera Capitable Camera Foscam HD IP Cameras and other brand ONVIF-embedded cameras supported Foscam MJPEG cameras to be added by firmware upgrade Video Output Decoding Resolution (1080P)1920 x 1080, (960P)1280 x 960, 720P(1280 x 720), VGA(640 x 480), VGA(640 x 360), QVGA(320 x 240),...
Page 104 89(L)*89(W)*31.5(H) mm Environment Operating Temperature -20° ~ 55°C (-4°F ~ 131°F) Operating Humidity 20% ~ 85% non-condensing Storage Temperature -20°C ~ 60° (-4°F ~ 140°F) Storage Humidity 0% ~ 90% non-condensing Certification CE, FCC, RoHS Warranty Limited 2-year warranty www.foscam.com...
Page 105 ITEMS FN3104H Video Input IP Video Input 4-ch 720P/960P HD IP Camera Capitable Camera Foscam HD IP Cameras and other brand ONVIF-embedded cameras supported Foscam MJPEG cameras to be added by firmware upgrade Video Output Decoding (1080P)1920 x 1080, (960P)1280 x 960, 720P(1280 x 720),...
Page 106 ITEMS FN3109H IP Video Input 9-ch HD IP camera input Video Input Foscam H.264 / MJPEG IP Cameras and other brand Capitable Camera ONVIF cameras supported 1080P(1920 x 720),960P(1280 x 960), 720P(1280 x Decoding Resolution 720), VGA(640 x 480), VGA(640 x 360), QVGA(320 x...
Page 107 220 × 209 × 40mm (L x W x H) Net Weight (g) 750g Physical and Operating Temperature -20°C ~ 55°C (-4°F ~ 131°F) Environmental Operating Humidity 20% ~ 85% non-condensing Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F) Storage Humidity 0% ~ 90% non-condensing www.foscam.com...
Page 108: List Of Third-Party List
1TB, Mobile Hard Disk 5400RPM 8MB Cache USB3.0 TOSHIBA HDTB105AK3AA 500GB, Mobile Hard Disk 5400RPM 8MB Cache USB3.0 Western Digital WDBUZG0010BBK-01 1TB, Mobile Hard Disk 5400RPM USB3.0 DS11-201312-0043 2TB, Mobile Hard Disk 5400RPM USB3.0 Seagate STBV4000300 New Seagate Expansion 4TB, Mobile Hard Disk 5400RPM USB3.0 www.foscam.com...
Page 109: Faq
Check whether the IPC also supports the protocol selected in the NVR.  6. The screen of the display is incomplete. Confirm the current resolution and check the resolution supported by the display. If the resolution is 1920*1080, the display needs to support the resolution 1920*1080. www.foscam.com...
Page 110 Please add the NVR as a trusted site to resolve this issue. Open IE browser, Choose “Tools > Internet Options > Security”, Select “Trusted sites”, then click “Sites”, it will pop up the page, as shown in the following figure. www.foscam.com...
Page 111: Glossary
It is a network protocol for encapsulating Point-to-Point Protocol over Protocol (PPP) frames inside Ethernet frames. It is used Ethernet mainly with ADSL services where individual users connect to the ADSL transceiver (modem) over Ethernet and in plain Metro Ethernet networks. www.foscam.com...
Page 112: Ce & Fcc
FCC Caution Any changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. CE Mark Warning www.foscam.com...
Page 113: Warranty
No warranty service is provided unless the product is returned to an authorized return center in the region where the product was first shipped by FOSCAM or to the point-of-purchase, which may have regional specific warranty implications.
Page 114 NVR User Manual  Please read FOSCAM warranty policy & policy of your reseller first before sending items back to point-of-purchase.  Customer must first contact point-of-purchase to obtain a Return Merchandise Authorization (RMA) number before returning the product. If the product you received is suspected to be defective and the product warranty has not expired, The RMA number will allow your reseller to track your return much easier and help them expedite processing your request.
Page 115: Limitation Of Liability
Repair Service Out Of Warranty  FOSCAM provide extra repair service for product that out of warranty, it is chargeable. The total fee contains device cost and service fee. Device cost (including accessories) is the standard uniform price provide by FOSCAM.
Page 116: Obtaining Technical Support
FOSCAM, shall be the repair or replacement of defective parts. If FOSCAM lists a product on its website specification in error or that is no longer available for any reason, FOSCAM reserves the right to explain it without incurring any liability.
