Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Design
• Color
: Deep black
Usability
• Tube type
: Metal 2-piece telescopic tube
• Handgrip
: Ergonomic grip with air slider
• Tube coupling
: SmartLock
• Action radius
: 9.0 m
• Cord length
: 6.0 m
• Carrying handle
: Top and front
• Dust bag full indicator
• Park or storage assist : Vertical and horizontal
• Power control
: Electronic on appliance
• Wheel type
: Rubber
Filtration
• Dust bag type
: S-bag Ultra Long Performance
• Dust capacity
: 5 l
• Exhaust filter
: Micro filter
• Motor filter
: Triple layer
Safety
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Consumer Lifestyle
13/07
TECHNICAL INFORMATION
Performance
• Noise level (Lc IEC)
• Airflow (max)
• Input power (IEC)
• Input power (max)
• Suction power (max)
• Vacuum (max)
Weight and dimensions
• Dimensions of product
(L x W x H)
• Weight of product
ACCESSORIES
• Standard nozzle
• Additional nozzle
• Accessories
• Accessory storage : On tubeclip
OPTIONAL (accessories)
• Starter kit FC8060 (Filters and dustbags)
Printed in the Netherlands
Vacuum cleaner
FC9185/01
: 79 dB
: 47 l/s
: 1800 W
: 2000 W
: 450 W
: 34 kPa
: 500 x 310 x 300 mm
: 5.4 kg
: Tri-Active nozzle
: Hard floor nozzle
: Crevice tool, Small nozzle
© Copyright reserved
Subject to modification
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Philips FC9185/01
Summary of Contents for Philips FC9185/01
-
Page 1: Vacuum Cleaner
• After the product has been repaired, it should function properly and has to meet the safety requirements as officially laid down at this moment. Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification... - Page 2 FC9185/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • To open the appliance, first remove outlet grill (28) and • Then with a small screwdriver lift the Handle cover over exhaust filter (7). the nock on the Top housing (see picture). • Remove Dustcover (1) using a screwdriver (see picture).
- Page 3 FC9185/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • When the Motor and/or Cordwinder have to be • When replacing the Cordwinder (21) the Lower housing replaced the Upper housing (17) must be removed. insert (19) needs to be removed. Move the Lower housing insert upwards so the cordwinder can easily be •...
-
Page 4: Wiring Diagram
FC9185/01 DISASSEMBLY- AND RE-ASSEMBLY ADVISE WIRING DIAGRAM • To replace Caster assy (4) turn the appliance upside down, push the Caster assy with a screwdriver up and pull it out (see picture). Black Black/White CORD WINDER Brown Blue MOTOR POWER... -
Page 5: Parts List
FC9185/01 PARTS LIST Service code Description Remark 4322 009 00651 Dust cover Deep black unprinted 4322 003 46801 Dustbag holder Deep black 80231 4322 005 33431 Caster assy 4322 003 46671 On/Off pedal Deep black 80231 4322 003 46681 Cordwinder pedal... -
Page 6: Exploded View
FC9185/01 EXPLODED VIEW... - Page 7 FC9185/01 EXPLODED VIEW...
- Page 8 FC9185/01 EXPLODED VIEW...
- Page 9 FC9185/01 EXPLODED VIEW...
