Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Design
• Color
:
Usability
• Tube type
: Metal 2-piece telescopic tube
• Handgrip
: Ergonomic grip with air slider
• Tube coupling
: Conical
• Action radius
: 9.0 m
• Cord length
: 6.0 m
• Carrying handle
: Top and front
• Dust bag full indicator
• Park or storage assist : Vertical and horizontal
• Power control
: Electronic on appliance
• Wheel type
: Rubber
Filtration
• Dust bag type
: S-bag Ultra Long Performance
• Dust capacity
: 5 l
• Exhaust filter
: Super Clean Air HEPA 12 filter
• Motor filter
: Triple layer
Safety
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Consumer Lifestyle
13/07
Star blue
Printed in the Netherlands
Vacuum cleaner
TECHNICAL INFORMATION
Performance
• Noise level (Lc IEC)
• Airflow (max)
• Input power (IEC)
• Input power (max)
• Suction power (max)
• Vacuum (max)
Weight and dimensions
• Dimensions of product
(L x W x H)
• Weight of product
ACCESSORIES
• Standard nozzle
: Tri-Active nozzle
• Accessories
: Crevice tool, Small nozzle
• Accessory storage : On tubeclip
OPTIONAL (accessories)
• Starter kit FC8060 (Filters and dustbags)
© Copyright reserved
FC9184/01
FC9184/11
: 79 dB
: 49 l/s
: 1800 W
: 2100 W
: 475 W
: 35 kPa
: 500 x 310 x 300 mm
: 5.4 kg
Subject to modification
Advertisement
Table of Contents
Related Manuals for Philips FC9184/01
Summary of Contents for Philips FC9184/01
-
Page 1: Vacuum Cleaner
• After the product has been repaired, it should function properly and has to meet the safety requirements as officially laid down at this moment. Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification... - Page 2 FC9184/01 / FC9184/11 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • To open the appliance, first remove outlet grill (28) and • Then with a small screwdriver lift the Handle cover over exhaust filter (7). the nock on the Top housing (see picture).
- Page 3 FC9184/01 / FC9184/11 DISASSEMBLY- AND RE-ASSEMBLY ADVISE • When the Motor and/or Cordwinder have to be • When replacing the Cordwinder (21) the Lower housing replaced the Upper housing (17) must be removed. insert (19) needs to be removed. Move the Lower housing insert upwards so the cordwinder can easily be •...
-
Page 4: Wiring Diagram
FC9184/01 / FC9184/11 DISASSEMBLY- AND RE-ASSEMBLY ADVISE WIRING DIAGRAM • To replace Caster assy (4) turn the appliance upside down, push the Caster assy with a screwdriver up and pull it out (see picture). Black Black/White CORD WINDER Brown Blue... -
Page 5: Parts List
FC9184/01 / FC9184/11 PARTS LIST Service code Description Remark 4322 009 00631 Dust cover Silent Star blue unprinted 4322 003 46801 Dustbag holder Deep black 80231 4322 005 33431 Caster assy 4322 003 46671 On/Off pedal Deep black 80231 4322 003 46681... -
Page 6: Exploded View
FC9184/01 / FC9184/11 EXPLODED VIEW... - Page 7 FC9184/01 / FC9184/11 EXPLODED VIEW...
- Page 8 FC9184/01 / FC9184/11 EXPLODED VIEW...
- Page 9 FC9184/01 / FC9184/11 EXPLODED VIEW...
