Glossary; Features; Assembly - Craftsman 315.FS2000 Operator's Manual

Activate (operating controls)
To move an operating control so that it is in a position
that allows the tool to be actuated or that satisifes one
requirement for the tool to be actuated.
Actuate (tool)
To cause movement of the tool component(s) intended to
drive a fastener.
Actuation system
The use of a trigger, workpiece contact, and/or other
operating control, separately or in some combination or
sequence, to actuate the tool.
• Single sequential actuation
An actuation system in which there is more than one
operating control and the operating controls must
be activated in a specific sequence to actuate the
tool. Additional actuation can occur when a specific
operating control, other than a workpiece contact, is
released and re-activated.
• contact actuation
An actuation system in which there is more than one
operating control and the operating controls can
be activated in any sequence to actuate the tool.
Additional actuation can occur when any operating
control is released and re-activated.
pRoDuct SpEcIFIcAtIoNS
Motor ...............................................................19.2 Volt DC
Magazine Capacity ...............................................105 Nails
WARNING:
Do not use this product if it is not com-
pletely assembled or if any parts appear to be miss-
ing or damaged. Use of a product that is not prop-
erly and completely assembled or with damaged or
missing parts could result in serious personal injury.
If any parts are damaged or missing, please call 1-800-932-3188 for assistance.

GloSSARY

Fastener
A staple, pin, brad, nail, or other fastening device which is
designed and manufactured for use in the tools within the
scope of this standard.
Jam
An obstruction in the feed or drive areas of the tool.
operating control
A control that separately, or as part of an actuation
system, can cause the actuation of a tool.
trigger
A tool operating control activated by a tool operator's
fingers.
Workpiece
The intended object into which a fastener is to be driven
by a tool.
Workpiece contact
An operating control element or assembly on the tool
intended to be activated by the material to be fastened.

FEAtuRES

Nailer Speed .........................................up to 60 shots/min.
Nail Type ...............................................................18 gauge
Brad Nail Length.................................................. 5/8 - 2 in.

ASSEMBlY

WARNING:
or create accessories or attachments not recom-
mended for use with this product. Any such altera-
tion or modification is misuse and could result in
a hazardous condition leading to possible serious
personal injury.
8 – English
Do not attempt to modify this product
