- Page 1 IP PHONE SYSTEM CooVox Series-U50 For Small and Medium Business Quick Installation Guide Quick Installation Guide PW R SY S W AN LA N SL O T2 SL O T1 C o o V o IP P ho ne S ys te m n.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)12...
-
Page 2: Table Of Contents
Table of Contents 1 Package Contents 2 Hardware Installation 2.1 Safety Precautions 2.2 Product Installation 2.3 Physical Connection 2.4 Led Definitions 3 Basic System Configuration 3.1 Web Login 3.2 Network Configuration 3.3 Choose the Module 3.4 Reset to factory 4 Further Configuration n.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)12... -
Page 3: Package Contents
1 Package Contents Thank you for purchasing ZYCOO IP phone system. These are the items Included with your IP phone system purchase: Power Adaptor IP PBX Antenna(only for Quick Installation GSM Module) Guide Two mounting brackets Warranty Card and fittings... -
Page 4: Safety Precautions
2.1 Safety Precautions Notes: To avoid any device damage and bodily injury caused by improper use, please observe the following rules. Keep the power off during the installation. Use only the power adapter provided with IP PBX. Make sure that the supply voltage matches the specifications indicated on the rear panel of IP PBX. - Page 5 Environment Temperature Humidity Operating 0 C~40 C 10%~90%RH Non-condensing Storage -40 C~70 C 5%~90%RH Non-condensing Clearness PWR SYS SLOT1 SLOT2 CooVox IP Phone System The dust accumulated on IP PBX can be absorbed by static electricity and result in poor contact of metal contact points. Some measures have been taken for the device to prevent static electricity, but too strong static electricity can cause deadly damage to the electronic elements on the internal circuit board.
-
Page 6: Product Installation
1.Check if the module is clean and intact. 2.Please ensure power of IP PBX is cut off. 3.Please ensure the direction of the module is correct (ZYCOO-logo side up). 4.Push the module into the module slot through the guide rail. -
Page 7: Physical Connection
Caution: Do not touch any device on the module, just to prevent the module from being damaged by static electricity. This operation must be done with power cut off. The module does not support hot- plugging. Desktop Installation Please place the IP PBX on a steady platform Caution: Please set 5~10cm gaps around the device for air circulation Please avoid any heavy thing placed on the device. -
Page 8: Led Definitions
2.4 LED Definitions Indication Function Status Explaination Power Status Blink System Status Blink Data Status Data Status 1-4(SLOT1) SLOT1 Status E1/T1 1-4(SLOT2) SLOT2 Status n.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)12... -
Page 9: Basic System Configuration
3 Basic System Configuration 3.1 Web Login Step 1. Connect a computer and the CooVox device in the same network. IP address is usually in the 192.168.1.X range. Step 2. Start a web browser. To use the user interface, you need a PC with Internet Explorer (version 7.0 or higher), Firefox, Chrome. -
Page 10: Network Configuration
3.2 Network Configuration Step 1. Go to Network Settings Network Step 2. Configure the network information There are three types of network connection. They are Static, DHCP, PPPoE(Point-to-Point Protocol over Ethernet). You can find detailed settings in the user manual. n.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)12... -
Page 11: Choose The Module
3.3 Choose the Module Go to System Module Settings When using the module except FXO/FXS/GSM, you need to set the module parameters with the below page. Module Type: Select the module type of the device slot. FXS/FXO/GSM module Default type. You don’t need set anything for these modules. -
Page 12: Reset To Factory
ISDN BRI module 3.4 Reset to factory To reset the IP address to the default IP Address “192.168.1.100” (ETH) or reset the login password to default value, press the hardware reset button at the front panel more than 5 seconds. After the device is rebooted, you can login the management WEB interface within the same subnet of 192.168.1.x. -
Page 13: Further Configuration
