LUNAR Introduction and Contents Thank you for buying this Bush product, which is designed to give you many years of trouble-free service. You may already be familiar with using a similar unit, but please take time to read these instructions, as they are designed to familiarise you with the unit’s many features and to ensure you get the very best from your purchase.
LUNAR Safety Instructions General Safety Considerations 1) The nameplate artwork is located at the bottom or rear of the apparatus. 2) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.
LUNAR What is DAB+ DAB+ was developed in Europe by a consortium of broadcasters and manufacturers. DAB+ uses digital compression techniques to transform the source material, i.e. music and speech, into better quality audio. Interference free reception Analogue systems suffer from an effect called “multipath distortion”. This is caused because waves do not behave in an orderly fashion, but bounce and reflect off buildings etc.
LUNAR Connecting AC Power Connect the small end of adapter to main unit DC IN and insert the main plug of adapter into standard AC wall socket. Press the STANDBY button to power on the unit. Warning! 1) The DAB+ Bluetooth Speaker is designed to operate from a mains supply of AC 240V~50Hz.If the plug of adapter not fit properly, turn it over and again.
LUNAR Connecting AC Power Before installing batteries (not included), ensure that the unit is disconnected from the mains supply. Remove the battery compartment cover on the back of the DAB+ Receiver by carefully pushing the two lugs down.The battery cover can then be lifted away. Select the battery switch (Alkaline or NI-MH) in the batteries compartment.
Page 8
LUNAR Using Rechargeable Batteries NIMH Warning! There is danger of explosion if use non-rechargeable batteries with the NIMH switch set. Overtime batteries will loose the charge, please always remember to check the Batteries. Please be aware alarm will not work in battery mode.
LUNAR Main Operation Power On / Off Follow the previous page “Connecting AC Power” & “Battery Operation”. Press the STANDBY button to power on / off the DAB+ Bluetooth Speaker. Switching On for the first time Insert the AC power or batteries. The DISPLAY will illuminate and “WELCOME” will be displayed.
Page 10
LUNAR Operate DAB+ Radio Using DAB+ Stations 1. Power on your DAB+ Bluetooth Speaker, the DAB+ mode should be selected automatically. Warning! If the DAB+ Bluetooth Speaker, does not turn onto DAB+ mode, press the MODE button to select DAB+ mode.
Page 11
LUNAR DAB+ Station Text Information Using the DAB+ Station Information It is possible to change the information that is displayed on the second line of the DISPLAY when listening to a DAB+ station. There are more types of information available as listed below with examples to the right. To change the information displayed press the INFO button repeatedly.
Page 12
LUNAR DAB+ Menu Order Using the MENU Control (DAB+ mode) The MENU control allows you to change some of the system options on your DAB+ Receiver. These options are arranged in a menu structure as shown below. - 12 -...
LUNAR DAB+ Menu Order Continued The MENU Comment (DAB+ mode) Pressing the MENU button will enter the menu control. Press the < / > buttons to scroll through the options is described below. Full Scan 1. Press the MENU button to access the menu control 2.
Page 14
LUNAR DAB+ Menu Order Continued System - Date / Time ( See Date / Actual Time Setting) 1. In MENU order, use the < / > buttons until “System” displayed. Press SELECT button. 2. Press the < / > buttons until “Date / Time” displayed , use < / > buttons and SELECT button to adjust correct digit.
LUNAR Operate FM Radio Using the FM Radio In Power on mode, press the MODE button to select FM mode. You may hear background noise as no station has been tuned in. The DISPLAY will show the frequency of FM station.
Page 16
LUNAR FM Station Text Information Changing the FM Station Information It is possible to change the information that is displayed on the second line of the DISPLAY when listening to a FM station (RDS mode). There are more types of information available as listed below with examples to the right.
Page 17
LUNAR FM Menu Order Using the MENU Control (FM mode) The MENU control allows you to change some of the system options on your DAB+ Bluetooth Speaker. These options are arranged in a menu structure as shown below. - 17 -...
LUNAR FM Menu Order Continued The MENU Comment (FM mode) Pressing the MENU button will enter the menu control. Use the < / > buttons to scroll the options described below. Scan setting 1. Press the MENU button to access the menu control 2.
LUNAR Date / Actual Time Setting When receiving DAB+/ FM stations the broadcast stations provide the correct time. The broadcast stations set your actual clock time, so it will always be accurate. Auto Update the Clock Time 1. Turn on the unit and press the MODE button to select DAB+ / FM.
LUNAR Alarm Time Setting You can select two-alarm time settings and wake to BEEP / iPod / FM / DAB / sound. 1. Turn on the unit to DAB+ / FM mode. Press the MENU button to enter. 2. Use the < / > buttons to select SYSTEM mode and press SELECT button to enter.
LUNAR Checking the Alarm Time You can check the alarm time In standby mode and press ALARMS button frequency to select alarm 1 / alarm 2 for checking time. Display Back Light You can set the display backlight time out below: 1.
Page 22
Using the apps function First, go to Apple Store on your iPhone / iPad. Search for “Lunar”. Download the apps. The BUSH LUNAR app enhances the DAB+ Bluetooth Speaker with dock for iPhone/ iPad. It provides the ability to control DAB radio stations on your LUNAR Dock when the iPhone or iPad is docked in the device.
‘discover’ or ‘add’ a Bluetooth device. Using your phone to connect the DAB+ Bluetooth Speaker.- 1. Your phone will find the DAB+ Bluetooth Speaker under name “LUNAR”. 2. Your phone then asks if you want to pair with the DAB+ Bluetooth Speaker.
