- Page 1 B80 Mothership Quick Start Guide BMB1 ROM Rev D HD I/O 16X16 FOR PRO TOOLS 8.1 AND LATER 1• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120613 831.425.7501 page...
-
Page 2: Install Cards
Congratulations on your purchase of the B80 Mothership. There are a few simple things you must do before you can ROCK! *YOU MUST REGISTER YOUR B80 AT BURLAUDIO.COM/SUPPORT FOR YOUR WARRANTY TO BE VALID. WE NEED TO KEEP YOU UP TO DATE WITH THE LATEST FIRMWARE*... - Page 3 (See figures 4a-4d next page) -Always make sure the orange 2 pin connector is attached properly. Verify orientation. 3• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120613 831.425.7501 page...
- Page 4 Figure 7c Figure 7d *Rev A faceplate: Make sure *Rev B faceplates have a ribbon cable is connected to shrouded header to ensure all pins. proper connection. 4• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120614 831.425.7501 page...
- Page 5 When using B80 internal clock, set the CLOCK CONTROL to DAW, which allows Pro Tools to change sample rate. If using external clock, set to EXT. Figure 10 5• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120613 831.425.7501 page...
-
Page 6: Input Assignment
B80 Slot 8 Channel 31 -> HD I/O #2 Analog In Channel 15 B80 Slot 8 Channel 32 -> HD I/O #2 Analog In Channel 16 *BMB REV D COMPATABLE WITH PRO TOOLS 8.1 AND LATER* 6• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120614 831.425.7501... -
Page 7: Output Assignment
B80 Slot 4 Channel 63 -> HD I/O#2 Analog Out Channel 15 B80 Slot 10 Channel 32 -> HD I/O#2 Analog Out Channel 16 B80 Slot 4 Channel 64 -> HD I/O#2 Analog Out Channel 16 7• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120613 831.425.7501... - Page 8 This way we can keep you rocking. If you have support questions, please write an email to will@burlaudio.com or call 831.425.7501 Rock! 8• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120614 831.425.7501 page...
- Page 9 Higher fan speeds will ensure longer lasting electronics. Figure 13a Figure 13b If you have any questions, please call Will Kahn: 831-425-7501 or will@burlaudio.com Burl Audio, LLC Santa Cruz CA www.burlaudio.com 9• ©BURL AUDI0 2012 B80 Quick Start Guide BMB1 Rev D 120613 831.425.7501...
