Page 1: Quick Start Guide
B16-BMB2 MOTHERSHIP BMB2 Rev C Rom 3 Quick Start Guide Section 1: Getting Started Section 2: MADI Quick Start Revision 1.8 January 16, 2020... -
Page 2: Getting Started
1. GETTING STARTED 1.1 Register Please register all serial numbers for your B16 MOTHERSHIP chassis and all Daughter Cards. You must register to activate your warranty! Please visit: www.burlaudio.com/register. 1.2 Install Daughter Cards (If Necessary) If the Daughter Cards have been pre-installed, skip to page 3, step 1.8. 1.3 Remove Lid Remove 9 screws on top and 2 on each side (Image 1). - Page 3 Section 1 1.5 Install Daughter Cards Make sure the card is inserted into the card guides, and the card is properly connected to the backplane. (Image 4) Pull cables through to the front for connection to faceplate. (Image 5) Refer to Daughter Card Quick Start Guide for further installation instructions.
- Page 4 SECTION 1 / SECTION 2 Important Installation Notes: Install the 1U vent above the B16 chassis. The MOTHERSHIP MUST run with proper ventilation. Failure to properly vent the MOTHERSHIP chassis above may cause failure, and will void the warranty. 2. MADI QUICK START 2.1 Connect MADI 1 Port on BMB2 to RME MADI Card Note: As of this Quick Start guide, the RME HDSPe, RME HDSPe FX, and RME MADIFACE card are supported.
