Page 1: Quick Start Guide
B80-BMB1 MOTHERSHIP BMB1 Rev C Rom 2 Quick Start Guide Revision 1.6 April 30, 2018... -
Page 2: Getting Started
You must register to activate your warranty! Please visit: www.burlaudio.com/register. 1.2 Check Jumper Settings On BMB1 The B80 MOTHERSHIP is fully modular, accommodating a wide variety of I/O needs. Jumper settings on the BMB1 Motherboard allow for different I/O routing possibilities. - Page 3 B80-BMB1 EXAMPLE A: JUMPERS ON 1 AND 3 (FACTORY SETTING) BMB1 jumper settings for a 40 in x 40 out system using BAD8 and BDA8 Daughter Cards Image 3: Jumpers on 1 and 3 for BMB1 Rev C Rom 2 support BAD8 and BDA8.
- Page 4 B80-BMB1 EXAMPLE C: JUMPERS ON 2 AND 3 BMB1 jumper settings for a 32 in x 32 out system using BAD8, BDA8, BAES4 and BCLK Daughter Cards Image 7: Jumpers on 2 and 3 support BMB1 Rev C Rom 2 BAD4’s, BAD8’s BAES4, and Image 6: This is an example of a 32 in x 32 out BCLK Daughter Cards.
- Page 5 B80-BMB1 PTER 1 CHANNEL MAPPING FOR JUMPER SETTINGS JUMPERS 1 AND 2: INPUTS iii. CHANNEL MAPPING FOR JUMPER SETTINGS JUMPERS 3 AND 4: OUTPUTS iii. 1.3 Install Daughter Cards Image 10: Insert the Daughter Card into the card Image 11: Attach the ribbon cable guides.
- Page 6 B80-BMB1 1.4 Install Vents Image 12: B80 MOTHERSHIP with 1U vents above and below for proper airflow. Important Installation Notes: Install the 1U vents above and below the B80 chassis. The MOTHERSHIP MUST run with proper ventilation. The BP300 power supply should be installed underneath the MOTHERSHIP rather than above it.
-
Page 7: Input Assignments
B80-BMB1 1.7 Input Assignments Image 13: B80 input assignment in Pro Tools IO settings. B80 Ch. 1-16 are HDIO#1 Ch. 1-16 B80 Ch. 33-48 are HDIO#3 Ch. 1-16 B80 Ch. 17-32 are HDIO#2 Ch. 1-16 B80 Ch. 49-64 are HDIO#4 Ch. 1-16 1.8 Output Assignments Image 14: B80 output assignment in Pro Tools IO settings.
