Summary of Contents for BURL B2 Bomber ADC
- Page 1 User Guide B2 Bomber ADC B2 Bomber DAC Burl Audio January 2025 Revision M and later info@burlaudio.com www.burlaudio.com © 2025 Burl Audio. All rights reserved. MADE IN THE USA...
- Page 2 Burly is the heavy surf and fog that descends without warning over Santa Cruz, California. Burly is the dual rectified guitar and kick drum recorded through a BURL Audio B2 Bomber ADC and B1 Mic Pre. Burly is the toughness and heavy build quality of a BURL Audio unit. BURL is a creative...
- Page 3 B2 ADC FEATURES: • 44.1 kHz to 192 kHz, 24 bit, 2 channel ADC. • Proprietary, high definition, BURL Audio BX1 transformer input. • All Class-A, discrete transistors signal path with zero feedback and zero capacitors. • Audiophile quality 6 position attenuator with standard headroom settings.
- Page 4 B2 ADC FRONT PANEL CONTROLS 1. Input Level Attenuator: ***POST TRANSFORMER*** Allows quick selection between analog +4dBu =-12, -14, -16, -18, -20, or -2 2 dBfs digital headroom. 2. Dual Wire: Sends LEFT to AES1, RIGHT to AES2 at 176.4 and 192 kHz only. With Dual Wire set OFF, L and R are output to both AES1 and AES2.
- Page 5 B2 ADC REAR UNIT CONNECTIONS 1. AES 1: Digital Output for channels L & R with Dual Wire OFF; LEFT channel with Dual Wire ON at 176.4/192 kHz. 2. AES 2: Digital Output for channels L & R with Dual Wire OFF; RIGHT channel with Dual Wire ON at 176.4/192 kHz.
- Page 6 5. Set Sample Rate on front panel when Clock Source is set to INT. 6. Set Dual Wire switch to ON. if using dual AES cable protocol. 7. Set Input Level. BURL recommends starting at -18 dBfs. B2 BOMBER DAC Getting Started 1.
