Matrox MXO2
Power button
External
power supply
IEC-C13
power cord
To AC
outlet
OR
²Caution When
Female 4-pin
XLR cable
MXO2
(side view)
disconnecting the power
supply from MXO2,
make sure that you slide
back the casing on the
connector to release the
locking mechanism.
Matrox battery
power cable
Battery on a
universal battery
adapter
Powering Matrox MXO2
