Maytag MBF2256KEW Important Safety Instructions Manual
Hide thumbs Also See for MBF2256KEW:

Advertisement

Important Safety Instructions

Installer: Please leave this guide with this appliance.
Consumer: Please read and keep this Use & Care
Guide for future reference. This guide provides
proper use and maintenance information.
Keep sales receipt and/or cancelled check as proof
of purchase.
Call: 1-800-688-9900 U.S.A.
1-800-688-2002 Canada
Have complete model and serial number
identification of your refrigerator. This is located on a
data plate inside the refrigerator compartment, on
the upper left side. Record these numbers below for
easy access.
Model Number _______________________________
Revision Number ______________________________
Serial Number ________________________________
Date of Purchase ______________________________
In our continuing effort to improve the quality and
performance of our appliances, it may be necessary
to make changes to the appliance without revising
this guide.
What You Need to Know About

Safety Instructions

Warning and Important Safety Instructions appearing in
this guide are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining or operating appliance.
Always contact the manufacturer about problems or
conditions you do not understand.
Recognize Safety Symbols, Words,
Labels
DANGER – Immediate hazards which WILL result
in severe personal injury or death.
WARNING – Hazards or unsafe practices which
COULD result in severe personal injury or death.
CAUTION – Hazards or unsafe practices which COULD
result in minor personal injury or property damage.
1
DANGER
WARNING
CAUTION
DANGER
To reduce risk of injury or death, follow basic
precautions, including the following:
IMPORTANT: Child entrapment and suffocation
are not problems of the past. Junked or abandoned
refrigerators are still dangerous – even if they sit out
for "just a few days. " If you are getting rid of your old
refrigerator, please follow the instructions below to
help prevent accidents.
Before you throw away your old
refrigerator or freezer:
• Take off the doors.
• Leave the shelves in place so
children may not easily climb
inside.
This appliance is equipped with a three-prong
grounding plug for your protection against possible
electrical shock hazards. It must be plugged into a
grounding receptacle. Where a standard two-prong
wall receptacle is encountered, it is the personal
responsibility and obligation of the customer to have it
replaced with a properly grounded three-prong wall
receptacle. Do not under any circumstances, cut or
remove the third (ground) prong from the power cord.
Do not use an adapter plug.
Power supply cord with
three-prong grounding plug
Grounding type
wall receptacle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MBF2256KEW and is the answer not in the manual?

Questions and answers

Summary of Contents for Maytag MBF2256KEW

  • Page 1: Important Safety Instructions

    Important Safety Instructions DANGER Installer: Please leave this guide with this appliance. To reduce risk of injury or death, follow basic Consumer: Please read and keep this Use & Care precautions, including the following: Guide for future reference. This guide provides proper use and maintenance information.
  • Page 2 Important Safety Instructions WARNING To reduce risk of fire, electric shock, serious injury or 13. Always disconnect refrigerator from electrical death when using your refrigerator, follow these basic supply before attempting any service. Disconnect precautions, including the following: power cord by grasping the plug, not the cord. 1.
  • Page 3: Measuring The Opening

    Installation Your refrigerator was packed carefully for shipment. Leveling Remove and discard shelf packaging and tape. Do not remove the serial plate. CAUTION To protect property and refrigerator from damage, Location observe the following: • Protect vinyl or other flooring with cardboard, rugs, •...
  • Page 4: Door And Drawer Removal

    Installation 3. Using hex head driver, turn the front adjustment Door and Drawer Removal screws (A) on each side to raise or lower the front Some installations require door/drawer removal to of the refrigerator. transport the refrigerator to its final location. WARNING To avoid electrical shock which can cause severe personal injury or death, observe the following:...
  • Page 5: Pullout Freezer Drawer

    Installation Pullout Freezer Drawer To Install: 1. Pull both rails out to full (select models) extension. DANGER To prevent accidental child entrapment or suffocation risk, do not remove the divider in the top freezer basket. 2. While supporting door front, hook supports into tabs WARNING located on inside of rail.
  • Page 6: Reinstallation Of The Doors

    Installation Reinstallation of the Doors CAUTION 1. Install hinge assemblies: To avoid possible injury and damage to property: • Install top hinge loosely with " hex head ⁄ • Place doors on a nonabrasive surface protected by screws. towels or rugs while working directly on doors. •...
  • Page 7 Installation 3. Locate handle trim in literature pack and Freezer Handles install over top and bottom of handle, as Partial-Width Handle illustrated. Materials Needed • Secure top handle trim with remaining • Phillips screwdriver screw removed in step 1. To Install: •...
  • Page 8 Installation 3. Push the left handle To Remove: base against the left 1. At the right end, flex the handle base away from door tab and slightly the surface of the freezer drawer. Simultaneously to the right, just slide the door handle removal card that came with enough to allow it to your refrigerator under the right side base of the hang unsupported.
  • Page 9: Connecting The Water Supply

    Installation Connecting the Water Supply Materials Needed • " outer diameter flexible copper tubing ⁄ (select models) • Shut-off valve (requires a " hole to be drilled into ⁄ WARNING water supply line before valve attachment) • Adjustable wrench To reduce the risk of injury or death, follow •...
