Summary of Contents for Amica 507GG5.33HZpFG
- Page 1 507GG5.33HZpFG(W) INSTRUCTION MANUAL GAS COOKER IOAK-2423 / 8054083 (09.2014./1)
- Page 2 DEAR CUSTOMER, The cooker is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the cooker was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.
-
Page 3: Table Of Contents
TAbLE Of CONTENTS Safety instructions ......................4 Description of the appliance ....................11 Installation ......................... 12 Operation ........................... 18 Cleaning and maintenance ....................22 baking in the oven – practical hints ................27 Technical data ........................29... -
Page 4: Safety Instructions
SAfETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or... - Page 5 SAfETY INSTRUCTIONS During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. Accessible parts may become hot during use. Young children should be kept away. Warning: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
- Page 6 SAfETY INSTRUCTIONS Please pay attention to children whilst the cooker is in operation, as children do not know the rules of cooker use. In particular, hot surface burners, the oven chamber, grates, the door pane, and pans containing hot liquids standing on the hob may cause burns to children.
- Page 7 SAfETY INSTRUCTIONS Do not make your own alterations to the cooker in order to adapt it to a different type of gas, move the cooker to another place or make changes to the power supply. These operations may only be carried out by an authorised electrician or fitter. ...
- Page 8 SAfETY INSTRUCTIONS GAS & ELECTRICAL CONNECTION MOVING ThE COOKER Please refer to installation instructions for the Do not attempt to move the cooker by pulling Gas & Electrical Safety Regulations and the on the doors or handles. Open the door and Ventilation Requirements.
- Page 9 hOW TO SAVE ENERGY Using energy in a respon- Make sure the oven door is properly sible way not only saves closed. money but also helps the Heat can leak through spillages on the door environment. So let’s save seals. Clean up any spillages immediately. energy! And this is how you Do not install the cooker in the direct can do it:...
- Page 10 DISPOSAL Of ThE APPLIANCE UNPACKING Old appliances should not sim- During transportation, protec- ply be disposed of with normal tive packaging was used to household waste, but should protect the appliance against be delivered to a collection and any damage. After unpacking, recycling centre for electric and please dispose of all elements electronic equipment.
-
Page 11: Description Of The Appliance
DESCRIPTION Of ThE APPLIANCE 3, 4 1 Temperature control knob 2 Push-button oven light 3, 4, 5, 6 Gas burner control knobs 7 Grill signal light 8 Oven door handle 9 Drawer 10 Large burner 11 Medium burner Burner safety valve Spark ignitor 12 Medium burner 13 Auxiliary burner... -
Page 12: Installation
INSTALLATION Ventilation Requirements Before you start: Please read the instructions. Planning your installation will save you time The room containing the appliance should and effort. have an air suppły in accordance with Prior to installation, ensure that the local BS5440: Part2: 1989: distribution conditions (nature of the gas ... - Page 13 INSTALLATION Clearances Levelling No shelf or oyerhang or cooker hood should Before you start using the cooker it should be be closer than a minimum of 650mm, but leveled, which is particularly important for fat check with cooker hood manufacturer’s rec- distribution in a frying pan.
- Page 14 INSTALLATION Connect to the gas suppły Connect to the electricity supply Warmng: This appliance must be earthed. The iniet to the cooker is 1/2” BSP internal situated at the rear corner. The cooker is manufactured to work with Fit the bayonet connection. This should be a one-phase alternating current (220- located so as to ensure that the flexible con- 240V~50 Hz) and is equipped with a 3...
- Page 15 INSTALLATION Somipress burner auxiliary medium large oven Type of gas gas injector gas injector diameter gas injector diameter gas injector diameter [mm] [mm] diameter [mm] [mm] nominal thermal nominal nominal nominal nominal nominal thermal power thermal thermal thermal thermal power 1,00 kW power power...
- Page 16 INSTALLATION Surface burners applied do not require adjust- ment of primary air. A correct flame has dis- tinct internal cones of blue and green colour. A short, humming flame or long, yellow and smoking one, without clearly outlined cones, shows improper quality of gas in the house- hold piping or a damaged or soiled burner.
- Page 17 OPERATION Before first use remove packaging elements, gently (slowly) remove labels from the oven door, trying not to break the glue tape. empty the drawer, clean off factory pre- servatives from the oven chamber, take out and wash the oven fittings with warm water and a little washing-up liq- uid, ...
-
Page 18: Operation
OPERATION Ignition without an ignitor how to use surface burners light a match, Choice of cookware press in the knob to the end and turn it left to the “large flame” position Mind that the diameter of a pan base is always ... - Page 19 OPERATION Caution! Operation of the burner protection valve In cooker models equipped with a surface burner safety valve, hold the Some models are equipped with an automatic knob pressed down to the end when system that cuts off gas supply to a burner igniting for 10 seconds at the “large when the flame has disappeared.
- Page 20 OPERATION Oven functions and operation. To ignite the oven: strike a match, The oven can be heated by oven gas burner press down the knob to the stop and turn or by electric grill*. The oven function is left to the position corresponding to the tem- controlled by one knob, which contains a perature chosen, digital scale corresponding to thermoregula-...
- Page 21 OPERATION Use of the grill Caution! The grill should be used with the oven The grilling process operates through infrared door shut. rays emitted onto the dish by the incandes- When the grill is in use, accessible cent grill heater. parts can become hot.
-
Page 22: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- Important: nance of your cooker you can have a sig- The burner caps and leads must be reposi- nificant influence on the continuing fault-free tioned correctly so that they sit squarely onto operation of your appliance. - Page 23 CLEANING AND MAINTENANCE Replacement of the oven light Oven bulb The oven should be cleaned after every In order to avoid the possibility of an use. When cleaning the oven the lighting electric shock ensure that the appliance is should be switched on to enable you to switched off before replacing the bulb.
- Page 24 CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Using a flat screwdriver unhook the up- per door slat, prying it gently on the sides In order to obtain easier access to the oven (fig. B). chamber for cleaning, it is possible to remove 2.
- Page 25 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat (in the lower section of the door). Re- move the inner panel (fig. D, D1). 4. Clean the panel with warm water with some cleaning agent added. Carry out the same in reverse order to reassemble the inner glass panel.
- Page 26 OPERATION IN CASE Of EMERGENCY In the event of an emergency, you should: switch off all working units of the cooker disconnect the mains plug call the service centre some minor faults can be fixed by referring to the instructions given in the table below.
-
Page 27: Baking In The Oven - Practical Hints
bAKING IN ThE OVEN – PRACTICAL hINTS baking we recommend using the baking trays which were provided with your cooker which should be put on the drying rack; before the cake is taken out of the oven, check if it is ready using a wooden stick (if the cake is ready the stick should come out dry and clean after being inserted into the cake);... - Page 28 bAKING IN ThE OVEN – PRACTICAL hINTS Roasting meat cook meat weighing over 1 kg in the oven, but smaller pieces should be cooked on the gas burners. use heatproof ovenware for roasting, with handles that are also resistant to high temperatures;...
-
Page 29: Technical Data
TEChNICAL DATA Electrical supply 220-240V ~50Hz Warmng: This cooker must be earthed. Appliance category GB II2H3+ Oven: oven burner 2,8 kW electric grill 2,0 kW Usable capacity of the oven 58 litres Cooker dimensions H/W/D 90 / 50 / 60 cm Weight approx. - Page 32 Service Help Line 0844 815 8880 For the UK: please call 0818 46 46 46 For Ireland: please call...
