  • Page 1 Owner’s manual Mode d’emploi Manual de instrucciones DVH940 5.1CH SURROUND DECODER • DÉCODEUR SURROUND 5.1 CANAUX • DECSCODIFICADOR DE 5.1CH SURROUND • DVH940...

  • Page 2: Table Of Contents

    ∗ Check the contents of the enclosed warranty card and keep it carefully with this manual. ∗ The DVH940 can be operated by the CeNET-compatible Clarion Center Units. These operating instructions note functions which change as the result of connecting the DVH940 to one of the above components.

  • Page 3: Features

    0.1 channel are recorded discretely, so no crosstalk occurs between channels, and the sense of placement and depth of the sounds is reproduced faithfully. ∗ Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and double-D symbol are trademarks of Dolby Laboratories. DVH940...

  • Page 4: Specifications

    ×2 ×4 ×4 ×1 Power supply: DC 14.4 V (10.8 - 15.6 V) Ground: 1 DVH940 ............1 Negative ground 2 CeNET cable (5 m) ........1 Power consumption: 3 Owner’s manual .......... 1 480 mA 4 Warranty ............. 1 Dimensions: 5 Optical Digital Cable (5 m) ......

  • Page 5: Confirm Before Operation

    4. CONFIRM BEFORE OPERATION This component does not operate independently as an stand-alone unit and must be used in conjunction with an operational Clarion Source Unit (CeNET supported), or a 5.1 CH surround decoder control unit (DVC920). See section “8. SYSTEM EXPANSION” (P. 14) for details regarding other compatible components.
  • Page 6 Digital signals fs=48 kHz Dolby Digital (Not 2ch) × 2ch~5.1ch × fs=96 kHz Linear PCM × × Analog signals — — O: Adjustable ×: Adjustable without audio processing (Analog signals: when connected to CeNET connectors or analog input connectors) DVH940...

  • Page 7: Operations

    6 THEATER: Movie or drama theater. to Q20. 7 OFF: DSF off. ●GAIN: adjusts the output level. 3. Press the [ADF] button to return to the • Adjustments are made in the range -12 original mode. dB to +12 dB. DVH940...

  • Page 8: Setting Acoustic Features

    1. Press and hold the [ADJ] button for 1 second or longer to enter adjust mode. 2. Press the [a] or [d] button to change to the [FILTER E] display. 3. Press the [ENT] button to display the adjustment item. DVH940...
  • Page 9 • SURROUND L: left rear (surround) speaker • SUB-WOOFER: rear subwoofer 5. Turn the [ROTARY] knob clockwise or counterclockwise to adjust the gain. • The adjustment range is –10 dB to +10 dB. 6. Press the [ADJ] button to return to the original mode. DVH940...
  • Page 10 2. Press the [a] or [d] button to show the [PL II CONT E] display. 3. Press the [ENT] button to display the adjustment item. 4. Press the [a] or [d] button to select the item. DVH940...

  • Page 11: Wiring Techniques

    7 Cable clip hole Insert cable clip to hold optical digital cable in place. 8 RESET switch Press to reset circuitry if no sound is produced. Note: • Be sure the CeNET cable is connected when pressing the [RESET] switch. DVH940...

  • Page 12: How To Wire This Unit

    [RESET] switch • Following completion of wiring, press the [RESET] switch to return to default settings. Cable clip Squeeze right/ left tabs Note: • Always turn the main [POWER] switch [OFF] before connecting or disconnecting digital fiber- optic cables. DVH940...

  • Page 13: Installation

    2. Position the unit on the floor mat, then mark and open holes in the floor mat so they are aligned with the mounting bracket’s holes. 3. Press the accessory canoe clips from the underside upward through the mat and into the mounting bracket holes. Mounting screws Mounting bracket Mounting bracket Mounting screws Floor mat Canoe clips Canoe clips DVH940...

  • Page 14: System Expansion

    Powered center speaker * Connect properly in accordance Built-in amplifier with color of connectors RCA pin cable (sold separately) Amplifier Powered sub-woofer Set the 5.1ch surround decoder’s Built-in amplifier [STAND-ALONE / SLAVE] switch to the [SLAVE] position. STAND SLAVE ALONE DVH940...
  • Page 15 DVH940 CeNET Cable (furnished with STANDALONE SLAVE Monitor...

  • Page 16: In Case Of Difficulty

    DSF effect to ON (see P. 7). center channel (music CD, linear PCM stereo, etc.). Dolby Pro Logic II or DSF is set to OFF. The center speaker setting Set center speaker (SP-SEL) to ON (see P. 8) is OFF (default setting is ON). DVH940...
