Active Products ZE02 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SKU#: 39-8504-4
MODEL NO.: ZE02
CAUTION
BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND
RETAIN IT FOR FUTURE REFERENCE.
IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW
41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE
THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY. SEE PAGE 10 FOR
WINTERIZING PROCEDURE.
QUESTIONS, PROBLEMS, MISSING PARTS?
1-866-924-7626
Before returning to your retailer, call our customer service at
info@activeproducts.com
or email us at
PURCHASE DATE: _______________ SERIAL#: ___________________________________
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT.
ZE02-ManualE-v1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZE02 and is the answer not in the manual?

Questions and answers

Related Manuals for Active Products ZE02

Summary of Contents for Active Products ZE02

  • Page 1 SKU#: 39-8504-4 MODEL NO.: ZE02 CAUTION BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE REFERENCE. IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Technical Specifications ........................i Precautions............................1 Safety Features and Electrical Power Information ................2 Replacement Parts and Diagram ......................3 Assembly and Operating Instructions ....................4 Using the Accessories .........................8 Working with Detergent ........................9 Shut Down and Clean-up ........................10 Taking a Break ...........................10 Winterizing and Long-term Storage ....................

  • Page 3: Precautions

    IMPORTANT SAFETY INSTRUCTIONS - READ FIRST! SAFETY WARNINGS WARNINGS When using this product, basic precautions • Do not use with flammable liquids and toxic chemicals. should always be followed: • Injection Hazard: Equipment can cause serious injury if • Read all the instructions before using the product. the spray penetrates the skin.

  • Page 4: Safety Features And Electrical Power Information

    SAFETY FEATURES AND ELECTRICAL POWER INFORMATION Extension Cords The pressure washer is equipped with a stop de- vice that will sense when the trigger on the gun is If possible, do not use extension cords with this released. It will open the power circuit to the motor product.

  • Page 5: Replacement Parts And Diagram

    REPLACEMENT PARTS AND DIAGRAM Parts List Item No. Quantity Part Name Parts No. Water filter ZE01-000-0003 Quick-connect coupling & inlet adaptor ZE01-050-0000 Gun assembly ZE01-090-0001 High-pressure hose ZE01-090-0002 Adjustable wand ZE01-090-0003 Turbo wand ZE01-090-0004 Gun/wand holder ZE01-000-0001 User manual ZE01-900-0002 Needle ZE01-900-0001...

  • Page 6: Assembly And Operating Instructions

    ASSEMBLY AND OPERTATING INSTRUCTIONS Assembly Time: 2 minutes / Tools Required: None Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects which could create a hazard. Remove from the workarea which could be tripped over, such as toys or outdoor furniture. Ensure that all doors and windows are closed tight.
  • Page 7 ASSEMBLY AND OPERTATING INSTRUCTIONS Fig. 4 Step 4 Attach the high-pressure hose to the water outlet. Twist tightly to avoid leakage. Fig. 5 Fig. 6 Step 5 Step 6 Attach garden hose to water supply and turn water on. Plug the unit into an outlet. Press “TEST”. Then press “RESET”...
  • Page 8 ASSEMBLY AND OPERTATING INSTRUCTIONS Fig. 7 Step 7 Insert the wand (A or B) into spray gun, and twist 1/4 turn until rectangular tab appears. Fig. 8 Step 8 Start the pressure washer by turning ON/OFF switch to ON.
  • Page 9 ASSEMBLY AND OPERTATING INSTRUCTIONS Fig. 9 Adjusting The Spray CAUTION The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet Jet spray adjustment is very aggressive. Do to fan spray by turning the nozzle as shown not adjust while spraying.

  • Page 10: Using The Accessories

    USING THE ACCESSORIES Fig. 10 Adjusting the spray CAUTION The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet to fan Jet spray adjustment is very aggressive. Do spray by turning the nozzle as shown in Fig. 10. not adjust while spraying.

  • Page 11: Working With Detergent

    WORKING WITH DETERGENTS Using the detergent Important notice To enhance the efficiency of the pressure washer, When you have finished using detergent, always sometimes it is necessary to use detergents to help follow the “Cleanup Instructions”. Failure to clean loosen tough dirt and grime. properly will cause the injection system to become clogged and inoperable.

  • Page 12: Shut Down And Clean-Up

    SHUTTING DOWN AND CLEANING UP Step 1 Step 4 Turn the switch to “OFF” (0) position and unplug Disconnect the garden hose from the water inlet on cord from outlet. the unit. Step 2 Step 5 Turn off the water supply. Disconnect the high-pressure hose from the high- pressure outlet and engage the gun safety lock.

  • Page 13: Winterizing And Long-Term Storage

    WINTERIZING AND LONG-TERM STORAGE Optimum Winterizing Procedure Alternative Procedure If you cannot perform the Optimum Winterizing proce- Material required: Pump saver dure, you can still protect your pressure washer from Winterizing your pressure washer will help protect winter-damage: and prolong its life. It is strongly recommend you follow the below steps using a pump saver.

  • Page 14: Maintaining Your Pressure Washer

    USER MAINTENANCE Connections Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated with non-water soluable grease. Fig. 13 Fig. 14 Adjustable Nozzle Water Filter Screen The pressure washer is equipped with a water inlet When the nozzle is clogged, it will cause the pump to filter (L) that prevents debris going into the pump.

  • Page 15: Troubleshooting

    TROUBLESHOOTING Problem Cause Solution Motor will not start On/Off switch is in the “OFF” (O) position. Turn switch to the “ON” ( | ) position. Power cord is not plugged in. Plug in power cord. Extension cord is too long. Replace extension cord with one no Extension cord is not proper gauge.
  • Page 16 TROUBLESHOOTING - CONTINUED Problem Cause Solution Garden hose Loose fittings. Tighten fittings. connection leaks. Missing/worn rubber washer. Insert new washer. Spray wand, or Spray nozzle not properly attached. Insert the spray nozzle into the trigger extension, or gun. Carefully press in against the nozzle leaks.

  • Page 17: Warranty

    WARRANTY LIMITED 1-YEAR WARRANTY This pressure washer is warranted to be free of defects in materials and workmanship under normal resi- dential use for one (1) year. Specific warranty applies to: • Electric motor and pump are warranted for one (1) year. •...
  • Page 18 Printed in China...
