Samsung RL-55 series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

This manual is made with 100% recycled paper.
Free Standing Appliance
DA99-02116A (EN)-12.indd 01
DA99-02116A (EN)-12.indd 01
Refrigerator

user manual

imagine
the possibilities
Thank you for purchasing a Samsung product.
English
2014. 8. 14.
2014. 8. 14.
1:26
1:26

Advertisement

Table of Contents
loading

Related Manuals for Samsung RL-55 series

Summary of Contents for Samsung RL-55 series

  • Page 1: User Manual

    Refrigerator user manual English This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing a Samsung product. Free Standing Appliance DA99-02116A (EN)-12.indd 01 DA99-02116A (EN)-12.indd 01 2014. 8. 14. 2014. 8. 14. 1:26 1:26...

  • Page 2: Safety Information

    find manual. This appliance is not help and information online at intended for use by persons www.samsung.com. (including children) with • This appliance can be used reduced physical, sensory by children aged from 8 years...
  • Page 3 Important safety symbols and CE Notice precautions : This product has been determined to be in Hazards or unsafe compliance with the Low practices that may result Voltage Directive (2006/95/ WARNING in severe personal EC), the Electromagnetic injury or death. Compatibility Directive (2004/108/EC), RoHS Directive Hazards or unsafe...
  • Page 4 any naked flames or potential SEVERE WARNING WARNING sources of ignition and air the SIGNS FOR room in which the appliance is INSTALLATION standing for several minutes. • Do not install the • In order to avoid the creation refrigerator in a damp of a flammable gas-air mixture place or place where it if a leak in the refrigerating...
  • Page 5 cracks or abrasion damage accessible after installation. along its length or at either • The refrigerator must be end. grounded. • Do not bend the power cord - You must ground the excessively or place heavy refrigerator to prevent any articles on it.
  • Page 6 CAUTION SIGNS FOR or electric shock. CAUTION INSTALLATION • Do not let children hang on the door. • Keep ventilation - Failure to do so may cause opening in the appliance serious personal injury. enclosure or mounting • Do not leave the doors of the structure clear of refrigerator open while the obstruction.
  • Page 7 - Products that require strict tightly together so that they temperature controls must not do not fall out. be stored in the refrigerator. • If a gas leak is detected, avoid • Do not place or use electrical any naked flames or potential appliance inside the sources of ignition and air the refrigerator, unless they are of...
  • Page 8 3rd party on - There is a risk of fire. this completed appliance is neither covered under Samsung warranty service, nor is Samsung responsible CAUTION SIGNS FOR for safety issues and damages CAUTION USING that result from 3rd party modifications.
  • Page 9 introduced food for freezing • Remove any foreign near to already frozen food. matter or dust from the • Please observe maximum power plug pins. storage times and expiry But do not use a wet dates of frozen goods. or damp cloth when •...
  • Page 10 flammable gas (Refrigerant become trapped inside. R600a), contact your local Leave the shelves in place so authority in regard to safe that children may not easily disposal of this product. climb inside. Cyclopentane is used as an Children should be supervised insulation blowing gas.
  • Page 11 children and not in vicinity of compartment (compartments) the appliance. which have two star symbol ) is slightly higher than • The appliance might other freezer compartment not operate consistently (compartments). The two (possibility of temperature star section (sections) or becoming too warm in compartment (compartments) refrigerator) when sited for an...
  • Page 12 when putting food in or taking - For the most efficient use food out. of energy, please keep the The shorter time for which the all inner fittings such as door is open, the less ice will baskets, drawers, shelves form in the freezer.

  • Page 13: Getting Ready To Install The Refrigerator

    GETTING READY TO INSTALL 600mm THE REFRIGERATOR Congratulations on your purchase of this Samsung 560mm at least at least 50mm Refrigerator. We hope you enjoy state-of-the-art 50mm features and effi ciencies that this new appliance offers.

  • Page 14: Required Tools

    REVERSING THE 2. Remove the Top cover. Make sure to disconnect the wire underneath the Top cover. REFRIGERATOR DOOR Samsung recommends that reversing of the door opening is only completed by WARNING Samsung approved Service providers. This will be on a chargeable basis and at the customers expense.
  • Page 15 10. Switch the side of bottom hinge cap and then REVERSING THE attach the Front leg cover on the bottom of the REFRIGERATOR DOOR refrigerator. (CONT’D) Bottom hinge cap Bottom hinge cap 6. Separate the Front leg cover after removing 2 screws.
  • Page 16 18. Use 11 mm wrench to separate the Top hinge REVERSING THE shaft. Flip the Top hinge and reattach the Top REFRIGERATOR DOOR hinge shaft. (CONT’D) 14. Carefully put the Freezer door back on. Assemble the Middle hinge with 2 bolts on the left side.

  • Page 17: Reversing The Door

    REVERSING THE 25. Detach the Fridge and the Freezer REFRIGERATOR DOOR door gaskets and (CONT’D) then attach them after rotating them 21. Carefully put the Fridge door back on. 180˚. Then tighten 3 bolts to assemble the Top hinge. After reversing the doors, make sure the Fridge and Freezer door gaskets are properly arranged.

  • Page 18: Levelling The Refrigerator

    3. Assemble the handles after switching the side of 3. Change the positions of the Handle slider and the Fridge handle and the Freezer handle. spring from the left side to the right side. Make sure to change position of the Handle slider cap from the right side to the left side.

  • Page 19: Operating Your Refrigerator

    operating your refrigerator CHECKING THE CONTROL PANEL When the temperature setting is done, the set temperature is displayed initially for 5 seconds and (TYPE A) (TYPE B) then indicator will display the actual temperature of the freezer. Fridge or Freezer temp indicator will blink when temperature in the fridge or freezer compartment goes up dramatically by storing warm food or frequent door opening.
  • Page 20 USING THE CONTROL PANEL Vacation (TYPE B) Touch the Vacation button to activate the Vacation function. Coldest Vacation indicator will light up and the refrigerator will set the temperature to Press the Coldest button one or 15 °C to minimize the power consumption when you more times to lower the temperature are going on a long vacation or business trip or you of the refrigerator.
  • Page 21 CHECKING THE CONTROL FRIDGE LIGHT FRIDGE LIGHT PANEL (TYPE C) DAIRY GUARD DAIRY GUARD GLASS SHELF GLASS SHELF VARIETY VARIETY FOLDABLE SHELF FOLDABLE SHELF GUARD GUARD WATER WATER EGG TRAY EGG TRAY DISPENSER DISPENSER FRESH SAFE FRESH SAFE DRAWER DRAWER BOTTLE BOTTLE GUARD...

  • Page 22: Using Cool Select Zone

    Danger of explosion USING COOL SELECT ZONE™ CAUTION • The coldest parts of the refrigerator is the You can store various foods such as cheese, meat, rear panel. poultry fi sh and other foods at ideal temperature to This is the best place to store delicate preserve the taste of food.
  • Page 23 Getting water from the dispenser When the water dispenser is not used 1. Place a glass underneath the 1. Fix the Dispenser cock tightly into the dispenser water outlet. hole. Push 2. Push it gently against the water • When the Dispenser cock is pulled out for a dispenser lever with your glass.

  • Page 24: Cleaning The Refrigerator

    • Photosynthetic Fresh LED is always on when the Cooler zone fridge door is opened. Press the locking device on the rear left and right LED will turn on and off repeatedly when the door side of the cooler zone cover and pull the cooler is closed.

  • Page 25: Troubleshooting

    troubleshooting PROBLEM SOLUTION The appliance is not • Check if the power plug is correctly connected. operating at all or the • Is the temperature control on the front panel correctly set? temperature is too high. • Does sun shine on the appliance or are there any heat sources nearby? •...
  • Page 26 memo DA99-02116A (EN)-12.indd 26 DA99-02116A (EN)-12.indd 26 2014. 8. 14. 2014. 8. 14. 1:27 1:27...
  • Page 27 memo DA99-02116A (EN)-12.indd 27 DA99-02116A (EN)-12.indd 27 2014. 8. 14. 2014. 8. 14. 1:27 1:27...
  • Page 28 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY...
