Troubleshooting and Maintenance
Product Name
Model
Power Supply
Supplier of Adaptor
Adaptor Input
Model Number of Adaptor
Adaptor Input
Adaptor Output
Battery Life
Frequency Generation
Power Consumption
Maximum Output Voltage
Maximum Output Current
Operating Temperature and Humidity
Storage Temperature and Humidity
Main Unit Dimensions
Weight Approx.
Package Contents
Accessories:
17
ElectroVit a - Circulation Massager Electrical Stimulator
BE109
4.5V DC or 3 x 1.5V Alkaline Batteries Type C*
Golden Pro t Electronics Ltd.
230V~ 50Hz 100mA
SY-04010-BS
230V~ 50Hz 100mA
4.5V DC 100mA 0.45VA
Approx 1 Month:
When used 25 minutes a day continuously
Approx. 1Hz to 80Hz
0.45W
U < 50V (during 1kΩ load)
I < 10mA (during 1kΩ load)
10 C to 40 C, 30% to 90% RH
-10 C to 60 C, 10% to 95% RH
430 (L) x 430 (W) x 150 (H)mm
1900g
Quantity Parts
1
ElectroVita - Circulation Massager Electrical Stimulator
1
AC/DC Adaptor
1
Sole Massage Roller
2
Cable Wire for Electrode Gel Pads
4
Electrode Gel Pads
2
Plastic Gel Pad Protectors
1
Instruction Manual
