Summary of Contents for Daewoo FRAQ19DC Series
- Page 1 FRAQ19DC.. Code : Q501-5...
-
Page 2: Table Of Contents
Refrigerant Information Disposal of Used Electrical & Electronic Equipment Refrigerant R-600a Charge 0.064kg The meaning of the symbol on the product, Blowing Agent C-pentane its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at your applicable collection point for the recycling Observe Ambient Temperature of electrical &... -
Page 3: Be Sure To Keep For Safety
Never use a damaged power cord or plug, or Be sure to keep for safety! loose main socket. Read these safety instructions thoroughly and There is a risk of fire, electric shock or serious carefully before using. Please keep this user guide on injury. - Page 4 Never store any flammable gas or liquid in the Connect to portable water supply only. refrigerator. Never use flammable gas, benzene, thinners, Do not let children step on the cabinet shelves gasoline, spray etc. near the refrigerator. or vegetable cases. There is a risk of fire, explosion and personal Keep Children away from packaging or injury or damage.
-
Page 5: Installation Guide
Accessories Installation Guide Read these safety instructions carefully before use and follow precautions for your safety. Precautions in installation and User guide Egg tray power connection To prevent fire, electric shock or leakage. Never install the refrigerator on a wet, watery floor Filter Box Water supply Kit or where water can gather easily. -
Page 6: Installation Preparation
Avoid direct sunlight. Installation Preparation Check if the refrigerator can pass a doorway or enter a door first. Dimensions (including Door Handles) 912mm x 741.3mm x 1771mm (Width*Depth*Height) Once the installation place is ready, follow Note the installation instructions. If the surrounding temperature of the refrigerator is low (below 5°C), foods can be frozen or the refrigerator can function abnormally. -
Page 7: Door Removal/Replacement
Removing Freezer Door Door removal/Replacement Pull out bending tube guide and the left water tube. If the refrigerator can not pass (Dispenser Models Only) through a door during installation, follow these steps. (This guide refers to several models. The real features are model dependent.) Removing Refrigerator Door Unscrew top hinge cover with a screw driver. -
Page 8: Replacing Refrigerator Door
Replacing Refrigerator Door Replacing Freezer Door Insert the bottom hole of the refrigerator door Insert the water tube into the hole of the bottom straight into the bottom hinge pin. hinge pin first(Dispenser Models Only). Insert the bottom of freezer door into the bottom hinge pin. Let the top of the door close and insert the top hinge pin to the top hole of the refrigerator door. -
Page 9: Refrigerator Leveling & Door Adjustment
In case refrigerator door is lower Refrigerator Leveling & than freezer door... Door Adjustment (If needed) Insert a screw driver (flat tip) into a groove of the The refrigerator must be level in order to maintain right wheel (bottom of refrigerator) and turn it optimal performance and desirable front appearance. -
Page 10: How To Install Water Line
Installation Procedure (Dispenser How to install Water Line models only) (Dispenser models only) 1. Join Connector to the tap water line The water pressure should be 2.0~12.5 kgf/cm² (1.96 Figure A ~12.26 Bar) or more to run the automatic icemaker. Check your tap water pressure;... - Page 11 6. Fasten the Water Tube. Connector Water tube 1) Fasten the Water Tube with the [Fastener A] . 2) Check if the tube is bent or sqeezed. If so, set it right to prevent any water leak. Water Fastener A 4.
-
Page 12: Control Panel
To unlock, press for more than 3 seconds. The Control Panel display goes out. ■ Indicators for water/ice dispenser Dispenser Models A orange LED above the icon will light up to indicate your selection for dispenser. You can choose 'water' -> 'cubed ice' -> 'crusher ice(option)' ->... -
Page 13: Temperature Control
Temperature Control When this refrigerator is first plugged in, the temperature mode is set to 19°C / 4°C. ■ Dispenser Models Freezer Compartment Push the FRZ SET. button and the setting temperature changes as the figure shows. >>> Sequential Temperature Change <<< Faster Freezing... -
Page 14: How To Use The Interior Parts
How to use the interior parts ■ Dispenser Models NOTE: This guide covers several different models. The refrigerator you have purchased may have some or all of the items listed below. The locations of the features shown below may not match your model. Freezer Pocket Fruit Case For storing frozen foods (Do not store ice cream or... -
Page 15: Food Storage Tips
Food Storage Tips Wash foods before storing. Divide and separate foods into smaller pieces. Place watery foods or foods with a lot of moisture in front shelves (close to door side). If they are placed close to the cold air spout, they can be frozen. -
Page 16: How To Use The Dispenser
Edited by Foxit PDF Editor Copyright (c) by Foxit Software Company, 2004 For Evaluation Only. How to use the Dispenser How to use the Automatic Icemaker (For Dispenser models) (For Dispenser models) Select WATER / CUBED ICE / CRUSHED ICE(Optional) and press the cup on the PUSH pad for your convenience. -
Page 17: How To Adjust The Automatic Ice Maker
Push the dispenser lever and receive water until it How to adjust the stops. automatic ice maker water supply Please ensure that water supply is adjusted to make the appropriate sized ice (80~85% of ice tray) If the ice is too small or too large, ice-making and ice- tranferring malfunctions may occur. -
Page 18: Water Supply
If the measured water supply is less or more than the proper water supply, take action as below. 7-1) If less than the minimum of proper water supply Change the water supply set value to greater than '5' by pressing the dispenser button. 7-2) If less than the maximum of proper water supply Change the water supply set value to lesser than '5'... -
Page 19: Care & Cleaning
Care & Cleaning Be sure to unplug first ! * Full - option models illustrated. Dispenser Water Shelf Icecubes storage Case • Remove the water shelf and clean it. (The spill shelf • Removing: Pull the case assembly forward to is not self-draining.) remove. -
Page 20: How To Clean
Freezer & Refrigerator Shelves How to Clean • Open the doors fully, then pull the shelves forward Interior Parts to remove. • Use cloth with water and mild detergent to clean. Vegetable Case & Fruit Case • Pull forward and lift up a little to remove. Door Packing •... -
Page 21: Before You Call For Service
Problem Before You Call for Strange sounds from the Service... refrigerator. Please check the following troubleshooting tips before you call for service! Checkup Point Is the floor beneath the refrigerator uneven? Problem Is the space between the refrigerator back and the It never gets cold inside. -
Page 22: Something Strange
Something strange? Don’t worry. Here is the answer. Case Explanation Front and side of refrigerator • Pipes (refrigerant vessel) are placed beneath Heat feels warm or hot. the surface to prevent moisture forming on it. • When you close the door and then open it again immediately, the door is not easy to Door is Doors do not open easily.
