Lacanche VOUGEOT - VOLNAY Installer Manual

Hide thumbs Also See for VOUGEOT - VOLNAY:

Advertisement

Quick Links

Download this manual
Vougeot - Volnay
«
WARNING : If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS.
 Do not try to light any appliance.
 Do not touch any electrical switch.
 Do not use any phone in your building.
 Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
 If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
- In the Commonwealth of Massachusetts, the appliance must be
installed by a licensed plumber or gas fitter.
F
ourneau
!WARNING!
THIS RANGE CAN TIP
INJURY TO PERSONS COULD RESULT
INSTALL ANTI-TIP DEVICE PACKED
WITH RANGE
SEE INSTALLATION INSTRUCTIONS
»

Advertisement

loading
Need help?

Need help?

Do you have a question about the VOUGEOT - VOLNAY and is the answer not in the manual?

Questions and answers

Related Manuals for Lacanche VOUGEOT - VOLNAY

Summary of Contents for Lacanche VOUGEOT - VOLNAY

  • Page 1 Vougeot - Volnay « » WARNING : If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 GENERAL MANUAL VOUGEOT - VOLNAY 800 mm-31 ’’ 34 mm 727.5 mm-28 ’’ ’’ 1000 mm - 39 ’’ 650 mm-25 ’’ 914 mm 768 mm 671 mm-26 36’’ ’’ 940 mm Vougeot 37’’ 1065 mm Fig. 2 ’’ 399 mm ’’...
  • Page 3 GENERAL MANUAL VOUGEOT - VOLNAY Vougeot with gas oven Vougeot with electric oven 450 mm ’’ 315 mm ’’ 60 mm ’’ Note: To allow for warming Fig. 4 oven door swing radius, cabinet depth must be a maximum of 24 ¾”, to within 3 ½”...
  • Page 4 GENERAL MANUAL VOUGEOT - VOLNAY Layout : 5-burner cook’s stove, oven and storage cupboard GN 1/1 (Figure 1 & 3). Description : Enamelled steel or stainless body panels AISI 430. Pressing cooking surface (stainless steel AISI 304) (Figure 4 and 5). 5- burners of different size and power individually controlled by a safety valve.
  • Page 5 GENERAL MANUAL VOUGEOT - VOLNAY Gas connection : 1/2” ID NPT (Sch 40) inlet, on male coupling (Figures 1, 3, 4 & 5). Sealant on all pipe joints must be resistive to LP gas. If used, a flex gas line for the gas supply must be metal of at least 1/2” ID NPT approved by an approved certifying agency (A.G.A., C.G.A,.
  • Page 6 Page 6 of 43...

  • Page 7: Installer's Manual

    ourneau Vougeot « » Volnay « » INSTALLER'S MANUAL Appliances must be installed in a workmanlike manner in accordance with the instructions in this manual and locally applicable regulations. In the Commonwealth of Massachusetts, the appliance must be installed by a licensed plumber or gas fitter. This manual will be handed over to the user after installation.
  • Page 8 INSTALLER’S MANUAL VOUGEOT - VOLNAY  Cabinet preparation (VOUGEOT) This diagram depicts the actual location of gas and electrical connections on the range. Place gas stub-out or electrical receptacle outside of this area in accordance with local regulations. Electrical Fig. 7a...
  • Page 9 INSTALLER’S MANUAL VOUGEOT - VOLNAY  Cabinet preparation (VOLNAY) This diagram depicts the actual location of gas and electrical connections on the range. Place gas stub-out or electrical receptacle outside of this area in accordance with local regulations. Electrical connection Fig.
  • Page 10 INSTALLER’S MANUAL VOUGEOT - VOLNAY  Must be installed under an exhaust hood. In the Commonwealth of Massachusetts, the exhaust hood must be equipped with an "interlock" system. Check local codes.  Do not install this unit near combustible walls, partitions,...
  • Page 11 INSTALLER’S MANUAL VOUGEOT - VOLNAY Unscrew the screws C near the burners openings (Figures 10 and 11). Remove the pan supports and burners, pull and raise the top after having loosened the 2 screws D (Figure 12), wedge the cooking surface.

  • Page 12: Top Burners

    INSTALLER’S MANUAL VOUGEOT - VOLNAY In case of use with a gas other than that for which the appliance was initially set up, it is crucial to replace the orifices and modify the adjustments as defined below. TOP BURNERS Clé de 12...

  • Page 13: Oven Burners

    INSTALLER’S MANUAL VOUGEOT - VOLNAY Table 3 Table 4 Burners Burners Pressure Pressure Opening / inches Natural gas 6" WC 0.90 1.30 1.45 1.70 Natural gas 6" WC 2.5 / 2.5 / L.P. propane 10" WC 3.5 / L.P. propane 10"...
  • Page 14 INSTALLER’S MANUAL VOUGEOT - VOLNAY Fig. 24 Fig. 23   Adjustment of oven primary airflow : Remove the base, loosen the screw L that secures the air ring and then adjust (Table 6, Figure 24). Table 6 Opening in mm /...
  • Page 15 INSTALLER’S MANUAL VOUGEOT - VOLNAY   ELECTRICITY  ALL WORK ON OR REPAIR OF AN APPLIANCE MUST BE CARRIED OUT BY A QUALIFIED INSTALLER.  THE APPLIANCE WHEN INSTALLED, MUST BE ELECTRICALLY GROUNDED IN ACCORDANCE WITH THE LOCAL CODES OR The National Electrical Code, ANSI/NFPA 70-1996 or latest edition.
  • Page 16 INSTALLER’S MANUAL VOUGEOT - VOLNAY Fig. 28 Fig. 29 Fig. 30 Fig. 31 Fig. 32 120/240 V ; 3-Pole ; 4-wire BACK SPACER VENT FITTING : It is MANDATORY to mount the back spacer vent R supplied with the appliance (or equivalent) to the wall, this allows for ventilation and reduces the risk of heat damage.
  • Page 17 INSTALLER’S MANUAL VOUGEOT - VOLNAY 70 mm ’’ Figure 34 Figure 33 535 mm ’’ 772 mm 93 mm Fig. 35 ’’ ’’ Vougeot Volnay 319 mm ’’ 60 mm 319 mm ’’ ’’ 206 mm ’’...
  • Page 18 INSTALLER’S MANUAL VOUGEOT - VOLNAY SERVICE INSTRUCTIONS : - Lubricating gas valve. If the gas taps tends to stick slightly, you may follow this procedure :  1 - Shut off the valve and / or the main electrical supply of the unit.
  • Page 19 INSTALLER’S MANUAL VOUGEOT - VOLNAY GAS CIRCUIT DIAGRAM Designation Part number Burner cap 1.5 kW 65.330005 Burner cap 3.0 kW 65.330006 Burner cap 4.0 kW 65.330007 Burner cap 5.0 kW 65.330008 Burner bowl 1.5 kW 65.640003 Burner bowl 3.0 kW 65.640004...
  • Page 20 INSTALLER’S MANUAL VOUGEOT - VOLNAY 65.330006 65.330008 65.330005 65.226006 65.330007 1.5 kW = 65.064007 3.0 kW = 65.064007 4.0 kW = 65.064007 5.0 kW = 65.064007 65.080005 65.033018 65.103023 65. 430007 65.103021 65.222002 65.224005 80.903277 65.226003 65.103022 65 222003...

  • Page 21: Electric Circuit Diagrams

    INSTALLER’S MANUAL VOUGEOT - VOLNAY ELECTRIC CIRCUIT DIAGRAMS LG 1051 G LG 1051 E LG 1051 CT LG 1051 CT ETL 001 + grill Item n° Designation Part number Three pole limiting 65.39942 65.39942 65.39942 thermostat Oven thermostat 65.53670 65.53670 65.53670...
  • Page 22 INSTALLER’S MANUAL VOUGEOT - VOLNAY 240 V 60 Hz 120 V 60 Hz Reig UL / LG-LCF 1051 G Réf. S001028 – 00 Page 22 of 43...
  • Page 23 INSTALLER’S MANUAL VOUGEOT - VOLNAY 240 V 60 Hz 120 V 60 Hz UL / LG 1051 E Réf. S001029 – 00 Page 23 of 43...
  • Page 24 INSTALLER’S MANUAL VOUGEOT - VOLNAY 240 V 60 Hz 120 V 60 Hz UL / LG 1051 CT Réf. S001030 – 00 Page 24 of 43...
  • Page 25 INSTALLER’S MANUAL VOUGEOT - VOLNAY 240 V 60 Hz 120 V 60 Hz UL / LG 1051 CT Réf. S001031– 00 Page 25 of 43...
  • Page 26 240 V 60 Hz Hot cupboard - ETL 001 Réf. S001036 – 00 Page 26 of 43...
