- Page 1 Hikvision Technical Manual DS-2CC194P(N)-A(-C) Analog Camera Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or...
- Page 3 Hikvision Technical Manual Contents 1. Key Features 2. Specifications 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 4: Key Features
Auto iris with DC / video driver Auto white balance, auto gain control, electronic shutter control and backlight compensation CS mount lens (provide adapter for C mount lens) Internal or Power Synchronization ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 5: Specifications
Iris Auto / Electronic Auto Gain Low / Middle / High / Off D / N Mode Auto1 / Auto2 / Color / B&W White Balance Auto trace WB1 / Auto trace WB2 / Manual/Auto Menu Privacy Protection On / Off BLC AREA / INTENSION / OFF Language CN / EN GAMMA, Eclipse, Motion Detection, , Mirror Function, POS / Special Function NEG, Resolution, Sharp, RS485, System Information Power Supply 24VAC / 12VDC, ±10% AC110V～AC240V Working Temperature ‐10℃ ~ 60℃ Power Consumption 4W MAX (10W with ICR Working) Dimension 65mm × 55mm × 118mm (2.6” ×2.2” ×4.6”) Weight 500g (1.1lbs) ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 Hikvision Technical Manual 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
