- Page 1 Hikvision Technical Manual DS-2CC197P(N)-A Analog Camera Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or...
- Page 3 Hikvision Technical Manual Contents 1. Key Features 2. Specifications 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 4: Key Features
Auto iris with DC / video driver Auto white balance, auto gain control, electronic shutter control and backlight compensation CS mount lens (provide adapter for C mount lens) Internal or Power Synchronization ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 5: Specifications
Auto White Auto trace WB1/ Auto trace WB2 / Manual / Auto Balance Private Mask On / Off, Maximum 8 Zones Motion Detection Mode 1 / Mode 2 / Mode 3 / Off Menu Flicker Proof On / Off RS‐485 Address / Protocol / Baud Rate Language English / Chinese Gama Amendment, Digital Zoom, Digital Noise Reduction, Video POS/NEG ,Mirror, Resolution, Sharpness, Y, C, Blemish Detection Power Supply 24VAC / 20VA ±10%, 12VDC / 300Ma ±10% Working Temperature ‐10 ~ 60 (14°F ~ 140°F) Power Consumption 4W (10W MAX With ICR Working) Dimension 68mm × 57mm × 133.2mm (2.7” × 2.2” × 5.2”) Weight 500g (1.1lbs) ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 Hikvision Technical Manual 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
