Pressure
Washer
Operator's Manual
Record All Information
for future reference:
Brand:
Purchase Date:
Model #:
Serial #:
Questions? 1-800-888-2468
Register your product online
www.devap.com
READ AND SAVE THESE INSTRUCTIONS
CONSUMER INFORMATION . . . . . . . . . . .2
CONSUMER SAFTEY INFORMATION . . .2
SAFETY GUIDELINE/DEFINITIONS . . . . .3
CARTON CONTENTS . . . . . . . . . . . . . . . . .6
ASSEMBLY INSTRUCTIONS . . . . . . . . .7-8
OPERATING INSTRUCTIONS . . . . . . .8-12
MAINTENANCE . . . . . . . . . . . . . . . . . .13-14
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . .15
TROUBLE SHOOTING GUIDE . . . . . .16-17
WARRANTY . . . . . . . . . . . . . . . . . . . . . . .18
QUICK FACTS . . . . . . . . . . . . . . . . . . . . . .19
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . .21-40
FRANÇAIS . . . . . . . . . . . . . . . . . . . . . .41-60
Part No. D25617 Rev. 1
Advertisement
Table of Contents
Related Manuals for DeVilbiss D25617
Summary of Contents for DeVilbiss D25617
-
Page 1: Table Of Contents
ESPAÑOL ..... . .21-40 Register your product online FRANÇAIS ..... .41-60 www.devap.com Part No. D25617 Rev. 1 READ AND SAVE THESE INSTRUCTIONS... -
Page 2: Consumer General And Service Information
4442, and maintained in effective working order. Spark arrester are also required on some U.S. Forest Service land and may also be legally required under other statutes and ordinances. Engine exhaust contains chemicals known, in certain quantities, to cause can- cer, birth defects or other reproductive harm. 2- ENG D25617... -
Page 3: Safety Guideline/Definitions
• Use of acids, toxic or corrosive • Do not spray flammable liquids. chemicals, poisons, insecticides, or any kind of flammable solvent with this product could result in serious injury or death. 3- ENG D25617... - Page 4 CHEMICAL household detergents, cleaners and this product could result in serious BURN degreasers recommended for use injury or death. in pressure washers. • Wear protective clothing to protect eyes and skin from contact with sprayed materials. 4- ENG D25617...
- Page 5 • Never point wand at, or spray people or animals. • Always secure trigger lock when wand is not in service to prevent accidental operation. • Never permanently secure trigger in pull back (open) position. 5- ENG D25617...
-
Page 6: Carton Contents
Accessories Panel Engine Manual Bagged Accessories Panel Engine Frame and Handle Wheel Assembly Knobs English/ Spanish/ French Saddle Bolts Operator’s Manual Nozzle Cleaning High Pressure Chemical Hose Hose Bagged Parts Multi-Reg Wand Spray Gun Engine Oil 6- ENG D25617... -
Page 7: Assembly Instructions
Place handle assembly onto frame and connect handle to frame. Connect wand to gun. Tighten securely. Attach high pressure hose to gun. Tighten securely. To Assemble Accessories Panel Remove top screws on handle assembly. Loosen bottom screws on handle assembly. Remove Loosen 7- ENG D25617... - Page 8 Do not overtighten. Add engine oil (supplied) to engine. Refer to engine manual supplied by engine manufacturer for correct procedure. NOTE: There will be a slight amount of oil in the engine from factory testing. 8- ENG D25617...
-
Page 9: Operating Instructions
See Operation section. Chemical Hose: Allows cleaners or cleaning solvents to be mixed with the pres- surized water stream. See How To Siphon Chemicals/Cleaning Solvents in Operation section of this manual. 9- ENG D25617... -
Page 10: Basic Elements Of Engine
Back away from the surface to be cleaned. The further away you are, the less the pressure will be on the surface to be cleaned. DO NOT attempt to increase pump pressure. A higher pressure setting than the factory set pressure may damage pump. 10- ENG D25617... - Page 11 40º fan shape, as shown. Markings have been placed on the nozzle to help you select the spray pattern. narrow jet stream For low pressure operation, extend the nozzle of the multi-reg wand as shown. 40º fan spray 11- ENG D25617...
- Page 12 If pump is left in bypass mode for more than two minutes internal components of the pump can be damaged. If you do not understand these precautions please call 1-800-888-2468 to speak to a service representative for further instructions. 12- ENG D25617...
- Page 13 Turn engine off. See Engine Owner’s Manual. NOTE: NEVER turn the water off with the engine running. Turn water source off. Pull trigger on spray gun to relieve any water pressure in hose or spray gun. See Storage section in this manual for proper storage procedures. 13- ENG D25617...
-
Page 14: Maintenance
Reconnect spark plug wire Reassemble the nozzle to the wand. Tighten securely to prevent leaks. 10. Reconnect wand to gun and turn on water supply. 11. Start pressure washer and place wand into high pressure setting to test. 14- ENG D25617... - Page 15 This screen filter should be checked periodically and cleaned if necessary. Remove filter by grasping end and removing it from Filter Screen water inlet of pump as shown. Clean filter by flushing it with water on both sides. Re-insert filter into water inlet of pump. 15- ENG D25617...
-
Page 16: Storage
10. Drain all water from spray gun and wand by holding spray gun in a vertical position with nozzle end pointing down and squeezing trigger. Store in gun/hose holder. 11. Store chemical hose, high pressure hose, spray gun, and wand so they are protected from damage, such as being run over. 16- ENG D25617... -
Page 17: Trouble Shooting Guide
Choke lever in the “Choke” position. Move choke to the “No Choke” position. Throttle control lever is not in the Move throttle control lever to the “Fast” position. (if equipped) “Fast” position. High pressure hose is too long. Use high pressure hose under 100 feet. 17- ENG D25617... - Page 18 Loose hose connection. Check and replace. Water leaking Loose connections. Tighten. at pump Piston packings worn. Have replaced by AWSC. Worn or broken o-rings. Have replaced by AWSC. Pump head or tubes damaged Have replaced by AWSC. from freezing. 18- ENG D25617...
-
Page 19: Warranty
WARRANTY DeVilbiss Air Power Company warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for one year from the date of purchase. All products cov- ered by this limited warranty which are used in commercial applications (i.e., income producing) are war-... -
Page 20: Quick Facts
Add stabilizer to fuel tank and run engine for 5 minutes before storage. STORAGE OR Don't allow water to freeze in pump, gun, wand or hoses. WINTERIZING Siphon RV antifreeze into pump for cold weather storage or long term storage. ALWAYS REFER TO THE MANUALS SUPPLIED WITH THIS UNIT 20- ENG D25617...
