Pressure
Washer
Operator's Manual
Record All Information
for future reference:
Brand:
Purchase Date:
Model #:
Serial #:
Questions? 1-800-888-2468
Register your product online
www.devap.com
READ AND SAVE THESE INSTRUCTIONS
CONSUMER INFORMATION . . . . . . . . . . .2
CARTON CONTENTS . . . . . . . . . . . . . . . . .6
ASSEMBLY INSTRUCTIONS . . . . . . . . .7-8
OPERATING INSTRUCTIONS . . . . . . .8-12
MAINTENANCE . . . . . . . . . . . . . . . . . .13-14
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . .15
TROUBLE SHOOTING GUIDE . . . . . .16-17
WARRANTY . . . . . . . . . . . . . . . . . . . . . . .18
QUICK FACTS . . . . . . . . . . . . . . . . . . . . . .19
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . .21-40
FRANÇAIS . . . . . . . . . . . . . . . . . . . . . .41-60
Part No. D25689 Rev. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D25689-E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeVilbiss D25689-E

Summary of Contents for DeVilbiss D25689-E

  • Page 1: Table Of Contents

    Pressure Washer Operator’s Manual CONSUMER INFORMATION ...2 CONSUMER SAFTEY INFORMATION . . .2 Record All Information SAFETY GUIDELINE/DEFINITIONS ..3 for future reference: IMPORTANT SAFETY INSTRUCTIONS .3-5 CARTON CONTENTS .

  • Page 2: Consumer Information

    CONSUMER GENERAL AND SERVICE INFORMATION DO NOT RETURN THIS PRODUCT TO THE RETAILER! FOR SERVICE OPTIONS CALL: 1-800-888-2468, EXT. 2. • Congratulations! You have purchased a high quality product from America’s leading manufacturer of pressure washers. This pressure washer, when properly used and maintained, will provide trouble free service.

  • Page 3: Safety Guideline/Definitions

    SAFETY GUIDELINES / DEFINITIONS This manual contains ndicates an imminently hazardous situation which, if not information that is im- avoided, will result in death or serious injury. portant for you to know and understand. indicates a potentially hazardous situation which, if not This information re- avoided, could result in death or serious injury.
  • Page 4 HOW TO PREVENT IT HAZARD WHAT CAN HAPPEN • Breathing exhaust fumes will cause • Operate pressure washer in a well serious injury or death! ventilated area. Avoid enclosed RISK TO areas such as garages, basements, BREATHING etc. • Never operate unit in a location occupied by humans or animals.
  • Page 5 HOW TO PREVENT IT HAZARD WHAT CAN HAPPEN • Do not use chlorine bleach or any • Unsafe operation of your pressure washer could lead to serious injury other corrosive compound. RISK OF or death to you or others. • Become familiar with the operation UNSAFE and controls of the pressure washer.

  • Page 6: Carton Contents

    The powerful spray from your pressure washer is capable of causing damage to surfaces such as wood, glass, automobile paint, auto striping and trim, and delicate objects such as flowers and shrubs. Before spraying, check the item to be cleaned to assure yourself that it is strong enough to resist damage from the force of the spray.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place handle assembly onto frame and connect handle to frame. Attach high pressure hose to gun. Tighten securely. Connect wand to gun. Tighten securely. Assemble grommet kit and quick-connect nozzles as described in instructions supplied. Add engine oil (supplied) to engine. Refer to engine manual supplied by engine manufacturer for correct procedure.

  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS READ THIS OWNER’S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustrations with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Spray High Pressure Hose Quick Connect Wand...

  • Page 9: Basic Elements Of Engine

    BASIC ELEMENTS OF ENGINE Refer to the engine manual for location and operation of engine controls. Choke Control: Opens and closes carburetor choke valve Throttle Control Lever (if equipped): Controls engine speed. Starter Grip: Pulling starter grip operates recoil starter to crank engine. Fuel Valve Lever (if equipped): Opens / closes connection between fuel tank and carburetor.
  • Page 10 HOW TO USE WAND Risk of injection or injury to person. Do not direct discharge stream toward persons, unprotected skin, eyes, or with any pets or animals. Serious injury can occur. DO NOT attempt to change nozzles while pressure washer is running.
  • Page 11 HOW TO SIPHON CHEMICALS AND CLEANING SOLVENTS Siphoning chemicals or cleaning solvents is a low pressure operation. NOTE: Use only soaps and chemicals designed for pressure washer use. Do not use bleach. To siphon chemicals: Barbed Fitting Press chemical hose onto barbed fitting located near high pressure hose connection of pump as shown.

  • Page 12: Shutting Down

    STARTING Prior to starting, refer to your engine manual for proper starting procedures for your engine type. In a well ventilated outdoor area Add fresh high quality unleaded gasoline with a pump octane rating of 86 or higher. Do not overfill. Wipe up spilled fuel before starting the engine.

  • Page 13: Maintenance

    MAINTENANCE When performing maintenance, you may be exposed to hot surfaces, water pressure, moving parts, or fire that can cause serious injury or death! Before performing any maintenance or repair, disconnect spark plug wire, let engine cool and release all water pressure. The engine contains flammable fuel.
  • Page 14 HOW TO CLEAN THE WATER INLET FILTER Filter Screen This screen filter should be checked periodically and cleaned if necessary. Remove filter by grasping end and removing it from water inlet of pump as shown. Clean filter by flushing it with water on both sides. Re-insert filter into water inlet of pump.

  • Page 15: Storage

    STORAGE It is recommended that you follow these steps to protect the internal seals of the pressure washer when STORING THE UNIT FOR AN EXTENDED PERIOD and/or WHEN FREEZING TEMPERATURES ARE EXPECTED. ENGINE Consult the Engine Owners Manual for the manufacturer's recommendations for storage.

  • Page 16: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE CAUSE CORRECTION PROBLEM Add Fuel. No fuel. Engine will not Add required amount of oil. Low oil (if equipped with low oil start (see Engine shutdown). Manual for further engine Pressure builds up after two pulls Squeeze gun trigger to relieve troubleshooting) on the recoil starter or after initial pressure.
  • Page 17 CAUSE CORRECTION PROBLEM See How to Use Wand paragraph Wand not in low pressure. Will not draw in the Operation Section. chemicals Chemical filter clogged. Clean filter. Insure end of chemical hose is Chemical screen not in chemical fully submerged into chemical. Dilute chemical.

  • Page 18: Warranty

    WARRANTY DeVilbiss Air Power Company warrants to the original purchaser who uses the product in a consumer application (personal, residential or household usage) that all products covered under this warranty are free from defects in material and workmanship for one year from the date of purchase. All products covered by this limited warranty which are used in commercial applications (i.e., income producing) are...

  • Page 19: Quick Facts

    QUICK FACTS 1-800-888-2468 CALL TO FIND A LOCAL AUTHORIZED SERVICE CENTER NEAR YOU FOR REPAIRS AND SERVICE PART PURCHASES Use fresh high quality gas. Add stabilizer to fuel tank and run engine for 5 minutes before storage. Engine oil: Refer to engine manual supplied with this unit. Some units are equipped with a low oil sensor and adequate oil must be added or the unit will not start.
  • Page 20 NOTES 20- ENG D25689...
