Electrical Service; Fuse/Circuit Breaker; Total Circuit Ampacity - Manitowoc ECS018A Installation Instructions Manual

Section 1

Electrical Service

GENERAL
All wiring must conform to local, state and national codes.
VOLTAGE
The maximum allowable voltage variation is ± 6% of the rated
voltage on the ice machine model/serial number plate at start-up
(when the electrical load is highest).
All ice machines are factory pre-wired with a 2 meter (6 ft)
power cord, no plug is supplied.
Ice Machine
EC018 &
230/1/50
EC020
(without a
230/1/60
Timer)
230/1/50
EC020
(with a Timer)
230/1/60
EC030
230/1/50
After Serial
230/1/60
Number -
EC030
230/1/50
Before Serial
230/1/60
Number -
230/1/50
EC040
230/1/60
230/1/50
EC050
230/1/60
230/1/50
EC065
230/1/60
230/1/50
EC080
230/1/60
WARNING
Air-Cooled
Maximum
Total Amps
Fuse/Circuit
Breaker
10 Amp 2.2
10 Amp 2.2
10 Amp 2.5
10 Amp 2.5
10 Amp 2.5
10 Amp 2.5
10 Amp 3.4
10 Amp 3.4
10 Amp 3.4
10 Amp 3.4
10 Amp 4.0
10 Amp 4.0
10 Amp 4.2
10 Amp 4.2
10 Amp 4.4
10 Amp 4.4
Installation Instructions
The ice machine must be grounded in accordance with
national and local electrical codes.

FUSE/CIRCUIT BREAKER

A separate fuse/circuit breaker must be provided for each ice
machine. An electrical disconnect switch must be provided if the
ice machine is hard wired (wired without a plug).

TOTAL CIRCUIT AMPACITY

The total circuit ampacity is used to help select the wire size of
the electrical supply.
The wire size (or gauge) is also dependent upon location,
materials used, length of run, etc., This must be determined by a
qualified electrician.
Maximum
KW
Fuse/Circuit
Breaker
.506 N/A
.506 N/A
.575 10 Amp
.575 10 Amp
.575 10 Amp
.575 10 Amp
.782 10 Amp
.782 10 Amp
.782 10 Amp
.782 10 Amp
.92 10 Amp
.92 10 Amp
.99 10 Amp
.99 10 Amp
1.45 10 Amp
1.45 10 Amp
WARNING
Water Cooled
Total Amps KW
N/A N/A
N/A N/A
2.3 .529
2.3 .529
2.3 .529
2.3 .529
3.2 .736
3.2 .736
3.1 .713
3.1 .713
3.7 .851
3.7 .851
3.8 .874
3.8 .874
4.0 .92
4.0 .92
1-3
