Section 1
Dimensions
W
H
152.4 mm
(6 in)
MODEL H
MM 635
EC018
INCH 25.0
EC020
MM 650
&
INCH 25.59
EC030
EC040
MM 800
&
INCH
31.5
EC050
EC065
MM 902
&
INCH
35.5
EC080
D
10
9
8
7
6
Condenser Water
Inlet
W D 1
343 420 NA
13.5 16.5 NA
450 475 100.5
17.72 18.7 3.96
550 550 108
21.65 21.65 4.25
700 600 114.3
27.5 23.5 4.5
Installation Instructions
WATER COOLED
CONDENSER OUTLET
WATER COOLED
CONDENSER INLET
1
2
Condenser Water
Outlet
6 2 7
NA NA NA
NA NA NA
53.4 45.5 138.4
2.1 1.79 5.45
77.5 68 123
3.05 2.68 4.82
82.6 76.2 120.7
3.25 3.0 4.75
ELECTRICAL
POTABLE WATER
INLET
DRAIN
5
4
3
Potable Water Inlet Drain
4 9 5
63.5 88.9 50.8
2.5 3.5 2.0
125.5 118.4 45.3
4.94 4.66 1.78
87.5 221 68
3.44 8.71 2.68
95.25 222.25 82.6
3.75 8.75 3.25
Electrical
10 3 8
140 76.2 38.1
5.5 3.0 1.5
225 125.5 183.4
8.86 4.94 7.22
275 108 168
10.83 4.25 6.59
279.4 120.7 171.5
11.0 4.75 6.75
1-5
